PRODELIN CORPORATION
SECTION II
LINEAR FEED SUPPORT BRACKET INSTALLATION
Refer to the following table for item and part numbers used in these steps:
STEP 1: Attach the bottom feed mounting bracket (item #2) and ODU support plate
(item 1) to the feed support arm with [4] 3/8-16 x 1.25" bolts, [4]
lockwashers, and [4] 3/8-16 hex nuts (item# 5,7,8), as shown in figure 1.
Tighten securely. NOTE: For Insat installations, use the back set of
holes and for standard c-band , use the front set as shown in figure
3.
STEP 2: Attach the disc mounting angle (item# 3) to ODU support plate with 3/8 x
1.00 bolts, flatwashers, lockwashers, and nuts (item# 4,6,7,8). Leave
loose to allow for adjustment.
PARTS LIST - INSAT LINEAR FEED, SUPPORT BRACKET INSTALLATION
ITEM #
1 0156-125
2 0211-420
3 0225-601
4 8032-008
5 8032-010
6 8201-042
7 8202-042
8 8102-007
PART #
PLATE, ODU SUPPORT
FEED MOUNTING BRACKET
ANGLE, DISC MOUNTING
3/8-16 X 1.00" BOLT
3/8-16 X 1.25" BOLT
3/8" FLATWASHER
3/8" LOCKWASHER
3/8-16 HEX NUT
DESCRIPTION
9
4096-417
C-BAND Rx/Tx
ODU FEED INSTALLATION
