PRODELIN CORPORATION
PARTS LIST - CIRCULAR FEED, SUPPORT BRACKET INSTALLATION
ITEM # PART #
1 0181-714
1 0181-720
2 0211-420
3 0225-601
4 8032-008
5 8032-010
6 8201-042
7 8202-042
8 8102-007
9 8031-026
10 8201-041
11 8202-041
12 8101-009
DESCRIPTION
BRACKET, ODU SUPPORT (1.8M)
BRACKET, ODU SUPPORT (2.4M)
FEED MOUNTING BRACKET
ANGLE, DISC MOUNTING
3/8-16 X 1.00" BOLT
3/8-16 X 1.25" BOLT
3/8" FLATWASHER
3/8" LOCKWASHER
3/8-16 HEX NUT
5/16-18 X 3.25" BOLT
5/16" FLATWASHER
5/16" LOCKWASHER
5/16-18 HEX NUT
4
4096-417
C-BAND Rx/Tx
ODU FEED INSTALLATION
QUANTITY
1
1
2
1
6
4
4
10
10
1
2
1
1
