QUICK REFERENCE GUIDE
QUICK REFERENCE GUIDE
Front / Side View
Evaporator unit (fan coil unit)
Rear / Side View
Page 6 | 1-855-235-5271
Filter grille
R E A R V
I E W
Mounting keyholes (4)
THROUGH THE WALL
(Option 1)
Knockout for wiring
Line set knockout
Knockout for drain line
Thermostat wire routing for
optional 24V thermostat (NOT
INCLUDED)
INSIDE CELLAR (Option 2)
Knockout for drain line
Line set knockout
Knockout for wiring
040418
CWM
