SPRAY-GUN WASHER INOX LINE AQUA Mod. ILA
1.4 IDENTIFICATION (See fig. A).
Every Spray-gun washer has a CE identification plate that shows:
A- Manufacturer's brand.
B- Manufacturer's name and address.
C- CE Mark.
D- Danger Group, Class, Type in compliance with the "ATEX" Directive
E - Amount of washing product.
F - Year of construction.
G- Serial number.
H- Model.
I - Maximum Pressure.
N.B.: The H - G - F data listed in the identification plate must be always specified when calling for service and/or supply
of spare parts.

1.5 TECHNICAL SPECIFICATIONS.

Description
Mass (Weight).
Height
Width
Depth
Maximum operating pressure
Feeding air operating pressure.
Recommended pressure when the spray-gun washer is working
Diameter of the 3 holes in the suction nozzle (pos.15 fig.1).
Air consumption (average) at 8 bar.
Fume chute diameter (pos.16 fig.1).
Air speed at the hood entry ( 8 bar).
Air capacity from the chute ( 8 bar).
Number of pump strokes (pos.32 fig.1).
Water stainless steel tank capacity (pos.52W fig.1).
Lower container capacity (pos.W53 fig.1).
8
Figure A
Measuring unit
mm
mm
mm
bar
bar
bar
mm
Nm
mm
m/sec
m
N° strokes/minutes
dm 3
dm 3
Quantity
kg
3
/h
3 /h
60÷70
(litres)
(litres)
53
1490
600
700
10
6÷10
8
0.8
9
120
0.35
366
50
70
