UG-291
SDP-S User Guide
0.87"
22.0 mm
USB
LED
POWER
2.36"
60.0mm
RESET
BUTTON
RESET
BUTTON
USB
0.17" / 4.3mm
0.238" / 6.05mm
CON A
0.152" / 3.86mm
CON A
Figure 7. SDP-S Board Mechanical Specifications
Rev. A | Page 12 of 16
