Motion R12 Series Getting Started

Tablet pc
Hide thumbs Also See for R12 Series:
1
2
3
4
5
6
7

Advertisement

Table of Contents

Power on and off
Shut down your R12 from Windows
side of the screen to open the Charms menu, tap
Settings, tap Power, then tap Shut down. If Windows doesn't
respond, force the tablet PC to shut down by pressing the
power button
for about five seconds.
Sleep
Place your R12 in Sleep mode when you go away for a short
period of time to conserve battery power. When you
return, the Tablet PC quickly resumes activity and your desk-
top is the same as you left it.
To put the Tablet PC in Sleep mode, press and release the
power button
. To wake up the tablet from Sleep mode,
press the power button again.
N
The power button blinks when the tablet is in Sleep
oTe
mode.
Locking and unlocking
To lock and unlock your R12, press the Security
button
on the left side of the Tablet PC.
Using the fingerprint reader
The R12 is equipped with a fingerprint reader so that you can
log on to your Tablet PC by scanning your fingerprint instead
of entering a password. This provides an added level of secu-
rity and is a fast and convenient way to log on to your tablet.
R12 Getting Started
Getting Started with the Motion
. Swipe from the right
®
Using the pen
An important difference between traditional PCs and Tablet
PCs is that you frequently use a digitizer pen instead of a
mouse and keyboard. The R12 pen has a pressure-sensitive
tip and a function button. Pressing the function button is
equivalent to right-clicking a mouse.
function button
(right-click)
pen tip
Using touch
Your R12 is equipped with touch, which means you can use
your fingers to select items and open files, zoom in and out,
scroll through browser windows and documents, and more.
Touch works like a mouse. Tap to select an item and double-
tap to open it.
T
To open a right-click menu using touch, press your
ip
finger on the display until a square appears, then lift
your finger and the shortcut menu appears.
Calibrate the pen and your finger so that they can be detect-
ed more accurately on the touchscreen display. You should
do so when you first start using your Tablet PC and whenever
the pointer doesn't align with your pen or finger. To start the
application, tap the Motion Tablet Center tile, then tap
Tablet, and then tap Pen and Touch.
Model R001
®
R12 Tablet PC
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R12 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Motion R12 Series

Summary of Contents for Motion R12 Series

  • Page 1 Tablet PC and whenever the pointer doesn’t align with your pen or finger. To start the application, tap the Motion Tablet Center tile, then tap Tablet, and then tap Pen and Touch.

  • Page 2: Checking Battery Power

    Press a function button to perform certain actions. To perform a different set of actions, press and hold the function button. These actions are listed in the table below. You can also customize the buttons to perform actions that suit your needs. Press Press and hold Button 1 Motion Tablet Center Windows ® Journal™ Button 2...

  • Page 3: Using The Documentation Camera

    To take a photograph: 1. Hold the camera steady and point the lens at the object. 2. Press the LED function button 2 once to activate Motion SnapWorks. 3. Press the camera icon to take the picture.

  • Page 4: Motion Tablet Center

    Motion Dashboard Motion Tablet Center Tap the Dashboard icon to open the Motion Dash Motion Tablet Center provides a central location for board application. Use the Motion Dashboard to change accessing and configuring the most commonly used common tablet settings.

  • Page 5: Set Up Wireless

    Set up wireless Step 3. Set up Mobile Broadband with GPS (optional) The R12 includes built-in Wi-Fi® and Bluetooth®. Your Tablet PC may also be equipped with mobile If you purchased your R12 with the optional mobile broad- broadband. To set up available wireless networks, follow band module, you can connect to high-speed cellular net- these steps: works worldwide.
  • Page 6 Enter text with the input panel or on-screen keyboard You can use different methods to enter text with your R12 to fit your needs. You can use an on-screen touch keyboard or the handwriting panel. To open the on-screen keyboard, either: Use your digitizer pen to begin writing in the handwriting panel.

  • Page 7: Learn More

    Tablet PC. Motion Computing and Motion are registered trademarks of Motion Computing, Inc. in the United States and other countries. All other trademarks are properties of their respective owners. Microsoft, Windows, and Windows Journal are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.
