Motion CFT-004 C5m User Manaul

C5m/F5m Tablet PC Features
1 2
1 Web camera indicator light and web camera
2 Microphones
3 Function button
4
Tablet Center button
5 Directional pad
6 Battery gauge
7 B button
8 A button
9 Touchscreen display
10 Dock connector
C5m/F5m Tablet PC
11
3
4
5
24
6
23
7
22
8
21
9
20
19
18
10
11 Pen tether attach point
12 Volume buttons
13 Pen bay
14 Fan cover
15 Battery
16 Smart card reader (optional)
17
Micro-3FF SIM card slot
18 Docking guide
19 Battery latch
20 Battery gauge button
21 Battery gauge light
22 Documentation camera
23
Speaker
24 Illumination light for the documentation
camera
12
13
(must remove battery)
Model CFT-004
14
15
16
17
25 26
25 USB 3.0 port
26 Power adapter port
27 Windows® button
28
Security button—Lock and
Unlock (Ctrl+Alt+Del)
29 Fingerprint reader
30
Power button
31 Barcode scanner (optional)
27 28 29 30 31
