NovaTec NovaWheel NWDC Series Instruction Manual page 5

10.1 Commonly Used Screens ............................................................................... 25
9.2 Other Helpful Screens ........................................................................... 28
10.3 Rarely Used Screens ...................................................................................... 31
11 MAINTENANCE INSTRUCTIONS ......................................................................... 32
11.1 Suggested Maintenance Schedule* ................................................................ 32
11.2 Filters .............................................................................................................. 33
11.2.1 Process and Regeneration Filters ............................................................ 33
11.2.2 Conveying Air Filter - Loosen the clips on the Conveying Air Filter and
remove it from the canister. Clean it with compressed air or replace as necessary
and re-install........................................................................................................... 33
11.2.3 Draining Plasticizer .................................................................................. 33
11.3 Chain and Sprockets ....................................................................................... 34
11.4 Desiccant Rotor .............................................................................................. 34
11.5 Motor Rotation Signal ..................................................................................... 35
11.6 Rotor Replacement ......................................................................................... 35
11.7 Seal Replacement ........................................................................................... 36
11.8 Drive Motor Replacement ............................................................................... 36
12 TROUBLE SHOOTING and ERROR MESSAGES ............................................... 37
13 WARRANTY - NOVATEC, INC. - Effective Date 6-12-2012 ................................. 39
This manual is dedicated to the principle that any engineered system will have many
elements contributing to the smooth operation of the system, and that these must be
understood in order that installation and operation can proceed successfully.
The electrical and mechanical components in the NWDC Series dryers have been
manufactured, selected and assembled with care to give you excellent service. A wide
range of NWDC series dryers have been introduced to enable our valued customers to
select the right model for their application. These NWDC (NovaWheel™ Dry/Convey)
series dryers have been designed for beside-the-press drying applications. All
components of your NWDC series dryers have been carefully engineered and
manufactured and have been thoroughly inspected for quality, function and
performance.
Before installing this system, please read this manual, review the diagrams and the
safety information. This should save valuable installation and operation time later and
will help ensure safe operation and long life.
NWDC IM 26 MAR 2014
FOREWORD
© 2014 Novatec, Inc. All Rights Reserved
NWDC IM 26 MAR 2014
Page 5
