NovaTec NovaWheel NWDC Series Instruction Manual page 22

9
9
0
10
0
7
7
7
Press Gray button at bottom of screen to enable changes.
8
Enter Dryer Start Time by pressing the Day Button and choose day from Dropdown menu.
9
In first row, press Hours Button, enter start time and then press
Same procedure for Minutes Button
10
Enter Dryer Stop Time by choosing the Day and entering the hours
and minutes using the second row.
7
Press "Disabled Press to Enable" to activate Start/Stop function.
Press button, then Quick Start Menu to see drying temp and dew point. It usually takes 2-4 hours
for first hopper-load of material to be sufficiently dry for processing.
Hopper Receiver Screen
NOTE: If material is flowing too fast or too slowly through hopper receiver,
using the factory pre-sets, PRESS & HOLD the Hopper Loader icon
on the Quick Op screen (see
Load or Dump time and adjust to obtain smooth flow of material.
Changes will be effective on next cycle. Press
This screen can also be accessed by pressing the Convey Menu button on the Dryer Setup screen
(page 25)
Load Time
Turn
Receiver
ON/OFF
Dump
Time
Number of
cycles of
failure to
load before
an alarm
NWDC IM 26 MAR 2014
8
Mode
0
0
Mode
3
on page 21) then the appropriate blue box for
Hopper Receiver
30
2
0
10
3
0
© 2014 Novatec, Inc. All Rights Reserved
to return to QuickOp screen.
NOTE: These settings should
be adjusted to optimal values
after starting to run material.
Press each function button to
enter or change value,
including Blowback and
Proportioning if either or both
those options was supplied.
See page 23 for Proportioning.
Number of
Blow Back
Pulses
(If enabled)
NWDC IM 26 MAR 2014
Page 22
