MSA HUB Quick Start Manual page 3

1.2
Open the MSA A2 Software.
Click on the MSA Hub tile to access and/or change MSA HUB settings.
2
Connecting the MSA HUB to the internet:
Use one of the following options to connect the MSA HUB to the
2.0
Connect an Ethernet cable to the MSA HUB.
2.1
Insert a SIM card into the MSA HUB.
Open the HUB Insert the SIM card into the SIM indication Inside the HUB
2
a) Open the MSA A2 Software and click on the
MSA Hub tile.
MSA HUB QUICK START GUIDE
b) Once the HUB tile is open Search for the LTE
settings* and activate them by clicking the
button.
* Please check with your carrier if APN details are
required to activate data services. If so then enter
the APN details in the Con guration page.
2.2
Connect MSA HUB to the Wi network
a) Open the MSA A2 Software and click on the
MSA Hub tile.
MSA HUB QUICK START GUIDE
c) Click on Save ICON and the HUB restarts
MSA HUB is connected to the Internet.
b) Select the Wi network and enter the wi
key to connect
3
