™ PD6060 Dual Analog Input Process Meter
P
V
RO
U
Instruction Manual
1/8 DIN Digital Panel Meter with NEMA 4X, IP65 Front
Dual 0-20 mA, 4-20 mA, 0-5 V, 1-5 V, and ±10 V Inputs with Math Functions
Addition, Difference, Average, Multiplication, Div, Min, Max, Ratio, & More
Dual-Line 6-Digit Display, 0.6" (15 mm) & 0.46" (12 mm)
Isolated 24 VDC @ 200 mA Transmitter Power Supply
Easy Field Scaling in Engineering Units without Applying an Input
2 or 4 Relays with Interlocking Capability + Isolated 4-20 mA Output Options
Free PC-Based, On-Board, MeterView Pro USB Programming Software
No Assembly Required
Optional SunBright Display Models for Outdoor Applications
Operating Temperature Range: -40 to 65°C (-40 to 149°F)
UL & C-UL Listed. E160849; 508 Industrial Control Equipment
Input Power Options: 85-265 VAC / 90-265 VDC or 12-24 VDC / 12-24 VAC
Display Input in Two Different Scales Simultaneously - Great for Level Applications
Multi-Pump Alternation Control
Round Horizontal Tank Function; Just Enter Diameter & Length
32-Point Linearization, Square Root Extraction and Programmable Exponent Function
Programmable Display, Function Keys & Digital Input
External 4-Relay, Dual 4-20 mA Outputs & Digital I/O Expansion Modules
Password Protection
RS-232 & RS-485 Serial Communication Options with Modbus RTU
Wide Assortment of NEMA 4X Enclosures for up to Ten Meters
Light / Horn & Reset Button Accessory
Control Station Accessory for Remote Operation of P
3-Year Warranty
PRECISION DIGITAL CORPORATION
233 South Street • Hopkinton MA 01748 USA
Tel (800) 343-1001 • Fax (508) 655-8990
www.predig.com
MeterView Pro
USB Install
V
RO
U
