Tyco Power Series Installation Manual

To download the full installation and user manuals and register your product, please visit:
www.DSC.com/m/29010134 or scan the QR code to the right.
PowerSeries Pro is a feature-rich, scalable alarm system designed for commercial use. It features integrated phone line and Ethernet (IP) communicators,
and supports both hardwired and wireless devices. Three models are available: HS3248 (248 zones), HS3128 (128 zones), and HS3032 (32 zones).
Quick Setup
Plan the installation including all alarm detection devices, zone
1 Plan
expanders, keypads and other required modules.
2 Mount Decide on a location for the alarm panel and secure it to the
wall using suitable mounting hardware.
3 Wire Complete all wiring including modules, zones, bells/sirens,
telephone line connections and ground connections. Record
module serial numbers on page 24.
4 Power Connect the battery and power up the system. The battery must
be connected.
5 Enroll First Hardwired: Wire the keypad to the Corbus, power up the alarm
Keypad panel then press any button on the keypad. Wireless: Wire the
HSM2Host to the Corbus, then power up the alarm panel and a
wireless keypad. Press any button on the keypad to enroll it. The
HSM2Host is then enrolled on the alarm panel. Alternately,
enroll an RF keypad.
Enroll [*][8][Installer Code][902] subsection [000]. Press [*] to begin
6
auto-enrollment. Module slots are automatically assigned. Use
modules
scroll keys to view slots. Change slot by typing a 2-digit number.
7 Enroll [*][8][Installer Code][804] subsection [000]. Note: An
wireless HSM2HOST or RF keypad must be enrolled first.
devices
8 Program Basic programming: [*][8][installer code] [001]/[002]> Zone
Type/Zone Attribute [005]>[001] Partition 1 Timers: – Entry
Delay 1 – Entry Delay 2 – Exit Delay [301]>[001] Phone #1
[310]>[000] System Account Code.
Test Test the panel completely to ensure that all features and
9
functions operate as programmed. – [901] Walk Test – [904]
[000] Wireless Placement Test.
Compatible Devices
Throughout this document, x in the model number represents the operating
frequency of the device as follows: 9 (912-919 MHz), 8 (868 MHz), 4
(433 MHz).
Note: Only models operating in the band 912-919 MHz are UL/ULC
listed where indicated. For UL/ULC certified installations, use only
UL/ULC listed devices. Only models marked with xxx
listed.
Table 1-1 Compatible Devices
Modules
Wireless keypads:
Hardwired keypads with PG host
Hardwired keypads:
Touchscreen keypad:
Note: For ULC-s559 Listed applications the HS2TCHPRO(BLK) touchscreen keypad is for supplementary
use only.
2-way wireless transceiver:
8-zone expander:
PowerSeries Pro Alarm Control Installation Guide
UL
are UL/ULC
HS2LCDWFPROx UL HS2LCDWFVPROx UL
HS2LCDRFPROx UL
HS2LCDPRO UL
HS2TCHPRO(BLK) UL
HSM2HOSTx UL
HSM2108 UL
WARNING: This manual contains information on limitations regarding product use and function and information on the
limitations as to liability of the manufacturer. The entire manual should be carefully read.
8 low current output expander:
8-zone expander:
1 A Power supply:
3 A power supply:
4 high current output expander:
Audio verification module:
Power supply/relay output/Corbus repeater
module:
USB to WiFi adapter:
Alternate communicator:
Hardwired Devices
2-wire smoke detectors:
y= A, B, or C
A: ULC listed models
B: UL listed models
C: European and Australian models
4-wire smoke detectors:
y= A, B, or C
A: ULC listed models
B: UL listed models
C: European and Australian models
CO detectors:
Wireless Devices
PowerG wireless short range ceiling mount detector with temperature
monitoring
PowerG wireless long range ceiling mount detector with temperature
monitoring
PowerG wireless outdoor curtain PIR
PowerG wireless PRI motion detector with optional animal resistance
PowerG wireless PIR motion detector with temperature monitoring
PowerG wireless curtain PIR motion detector
PowerG wireless PIR motion detector with camera
PowerG wireless outdorr PIR motion detector with camera and with anti-
masking
PowerG wireless mirror optic PIR motion detector
PowerG wireless dual technology (PIR and MW) with anti-masking
PowerG wireless outdoor PIR motion detector with anti-masking
PowerG wireless recessed door/window contact
PowerG wireless outdoor contact with auxiliary input, temperature
monitoring, and anti-masking
PowerG wireless door/window contact with auxiliary input
PowerG wireless vanishing door/window contact
PowerG wireless glassbreak detector
PowerG wireless shock detector with auxiliary input
PowerG wireless flood detector
PowerG wireless temperature detector
PowerG wireless temperature probe extender (requires PGx905)
PowerG wireless CO detector (US only)
PowerG wireless CO detector with temperature monitoring
PowerG wireless smoke and heat detector
PowerG wireless smoke and heat detector with temperature monitoring
PowerG wireless smoke detector
PowerG wireless indoor siren
PowerG wireless outdoor siren
PowerG wireless repeater
PowerG wireless 1-button securtiy panic keyfob
PowerG wireless 2-button securtiy panic keyfob
HSM2208 UL
HSM3408 UL
HSM2300 UL
HSM3350 UL
HSM2204 UL
HSM2955(R) UL
HSM3204CX UL
HSM3WIFI
LE9080 UL
GS9080
TL880LT UL
3G9080-EU
3G9080 UL TL8803G UL
3H9080 UL
FSA-210x UL FSA-210xR UL
FSA-210xT UL FSA-210xRT UL
FSA-210xS UL FSA-210xRS UL
FSA-210xST UL FSA-210xRST UL
FSA-210xLST UL FSA-210xLRST UL
FSA-410x UL FSA-410xR UL
FSA-410xT UL FSA-410xRT UL
FSA-410xS UL FSA-410xRS UL
FSA-410xST UL FSA-410xRST UL
FSA-410xLST UL FSA-410xLRST UL
CO-12/24 UL
FW-CO1224
12-24SIR UL
CO1224
FW-CO12
PGx862 UL
PGx872 UL
PGx902 UL
PGx904(P) UL
PGx914(P) UL
PGx924 UL
PGx934(P) UL
PGx944 UL
PGx974(P) UL
PGx984(P) UL
PGx994
PGx307
PGx312 UL
PGx945 UL
PGx975 UL / PGx303 UL
PGx912 / PGx922 UL
PGx935 UL
PGx985 UL
PGx905 UL
PGTEMP-PROBE
PGx913 UL
PGx933 UL
PGx916 UL
PGx936 UL
PGx926 UL
PGx901 UL
PGx911 UL
PGx920 UL
PGx938 UL
PGx949 UL
