AVF TGXS200PB-F Manual

Advertisement

Quick Links

TGXS200PB-F
Read through ALL instructions before commencing installation.
If you have any questions about this product or issues with installation
STOP
contact the customer services help line before returning this product to
the store.
Lisez toutes les instructions avant de débuter l'installation.
Si vous avez des questions sur ce produit ou des problèmes
ATTENTION
d'installation, contactez l'assistance client avant de ramener le produit
en magasin.
CUSTOMER SERVICES HELP LINE NUMBER:
NUMÉRO DE L'ASSISTANCE CLIENT:
1-800 667 0808 (USA)
AVF Incorporated. 3187, Cornerstone Drive, Eastvale, CA 91752, USA
English language/ Langue Française
Leaflet No. /
Notice n°
17lbs
Per Shelf
8kg
Par étagère
463847 rev 00

Advertisement

loading
Need help?

Need help?

Do you have a question about the TGXS200PB-F and is the answer not in the manual?

Questions and answers

Summary of Contents for AVF TGXS200PB-F

  • Page 1 Si vous avez des questions sur ce produit ou des problèmes ATTENTION d'installation, contactez l'assistance client avant de ramener le produit en magasin. CUSTOMER SERVICES HELP LINE NUMBER: NUMÉRO DE L'ASSISTANCE CLIENT: 17lbs Per Shelf 1-800 667 0808 (USA) Par étagère AVF Incorporated. 3187, Cornerstone Drive, Eastvale, CA 91752, USA...
  • Page 2 It is the responsibility of the installer to ensure that the mounting wall is of a suitable standard and void of any services (eg gas, electricity, water etc). AVF accept no responsibility for any damage or loss caused by installing this product in a sub standard wall.
  • Page 3 Boxed Parts Pièces empaquetées...
  • Page 4 Fitting the Wall Bracket Installer l'applique murale Solid Wall Wood Stud Mur solide Latte de Bois Concrete Béton Ø7mm (17/64") Ø3mm (1/8") 55mm (2 ") Remove dust from hole 55mm (2 ") Retirez la poussière du trou Ensure bracket is in the centre of the wood stud Assurez-vous que l'applique est au centre de la latte de bois...
  • Page 5 Fitting the Shelf Support Fixer le support de l'étagère Screw Cover Cache-vis Lock at your desired height. Verrouillez à la hauteur désirée...
  • Page 6 Fitting Glass Shelf and End Caps Étagère en verre et embouts assortis DO NOT over tighten screws. Tighten by hand only. Ne serrez pas trop les vis. Visser à la main seulement. Ensure your shelf is a minimum of 100mm from the top of the wall bracket Assurez-vous que l'étagère du haut est à...
  • Page 7 Optional Cable Management Gestion de câble optionnel...
  • Page 8 Optional Cable Management Gestion de câble optionnel...
