- Page 1 Installation and User Manual ROCHER DET ELECTRIC SAUNA HEATER: 1118-701-040518 1118-1051-040518 CONTROL PANEL: 1601-27 (RA 27 (T-1) 314 SKLT 51-3 A...
-
Page 2: Table Of Contents
Installation and User Manual ROCHER DET Contents 1. Quick instructions for use of the sauna heater 1.1. Check before taking a sauna bath 1.2. Operation of the sauna heater controls 2. Information for users 2.1. Sauna room 2.2. Recommended sauna room ventilation 2.3. -
Page 3: Quick Instructions For Use Of The Sauna Heater
1.2. Operation of the sauna heater controls Refer to the specific control panel operating instructions. For additional information about enjoying a sauna bath, please visit our website at www.helo.fi 2. Information for users Persons with reduced physical and mental capacity, sensory handicap, or little experience and knowledge about how the device is operated (e.g. -
Page 4: Recommended Sauna Room Ventilation
Installation and User Manual ROCHER DET 2.2. Recommended sauna room ventilation 1000 mm 500 mm Image 1 Recommended sauna room ventilation 1. Sauna room 3. Electric sauna heater 5. Exhaust flue or channel 2. Washroom 4. Exhaust valve 6. Door to the sauna room 7. -
Page 5: Sauna Heater Stones
Installation and User Manual ROCHER DET 2.4. Sauna heater stones Quality stones meet the following requirements: - Sauna stones should withstand heat and heat variation caused by vaporisation of the water thrown on the stones. - Stones should be rinsed before use in order to avoid odour and dust. -
Page 6: Electric Heating Toggle
Installation and User Manual ROCHER DET 2.5. Electric heating toggle The electric heating toggle applies to homes with an electric heating system. Sauna heater has a connection (marked 55) for controlling the electric heating toggle. Connector 55 and the heating elements are simultaneously live (230V). -
Page 7: Preparing For Piling The Stones
Installation and User Manual ROCHER DET 2.9. Preparing for piling the stones Removing of the supporting bars to pile the stones Unscrew the bars' mounting screws (2 pcs). Lift the support bar's locking plate up from its normal position. Lift off the support bars. -
Page 8: Installing The Support For Heating Elements
Installation and User Manual ROCHER DET 2.10. Installing the support for heating elements Note that heating element support should always be used in order to prevent the heating elements from being bent into each other or out sideways. Installation of the heating element support: Pile in stones up to halfway of the provided space. -
Page 9: Sauna Heater Safety Clearances
Installation and User Manual ROCHER DET 2.11. Sauna heater safety clearances Saunaroom Safety clearances min. Adequate amount Power of stones Approx. kg 9 1900 10,5 9 15 1900 Table 1 Safety clearances 2.12. Connection of the sauna heater to the mains The sauna heater must be connected to the mains by a qualified electrician and in compliance with current regulations. -
Page 10: Locating The Connecting Box For The Connection Cable In The Sauna Room
Installation and User Manual ROCHER DET 2.13. Locating the connecting box for the connection cable in the sauna room Image 4 Location for the connection box 100 mm = Specified minimum safety clearance 1. Recommended location for the connecting box 2. -
Page 11: Safety Distances
Installation and User Manual ROCHER DET 2.14. Safety distances Corner and wall installation OLET 28 40 *) OLET 28 425 mm 1900 Absolute measurement! (must not be exceeded 1130 or undershot) Safety clearances between the bottom of the sauna heater and a wall. -
Page 12: Principle Image When T1 Is Used As Control Panel
Installation and User Manual ROCHER DET 2.15. Principle image when T1 is used as control panel Connector strip Limiter Heater Sensor cable 1 Blue 1 Blue 2 White 2 White 3 Red 3 Red 4 Yellow 4 Yellow Valk White... -
Page 13: Wiring Diagram
Installation and User Manual ROCHER DET 2.16. Wiring diagram Teho, Effekt Lämpövastukset, Värmeelement, Tennid, Input, Potencia Heating elements, Heizeelement, Resistores Térmicos Leistung, 230 V Vöimsus, SEPC 199 SEPC 200 2267 W 3500 W 1,2,3 10,5 1,2,3 230V - 240V 1N~ / 2~ Max. -
Page 14: Rocher Det Spare Part List
Installation and User Manual ROCHER DET 3. Rocher DET spare part list Part Part number Part name Rocher 701 Rocher 1051 6215793 Circuit board OLEA 98 6214036 Sensor OLET 28 7812550 Mains connector NLWD 1-1 5716203 Relay Finder 6119649 Rocker switch...
