User Manual
GREYHOUND Switch GRS1042/GRS1142
GREYHOUND Power supply module GPS1-C/GPS1-K/GPS3-P
GREYHOUND Media module GMM20/30/32/40/42
Installation GREYHOUND Switch
Technical support
Release 07 10/2020
https://hirschmann-support.belden.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hirschmann GREYHOUND GRS1042 and is the answer not in the manual?

Questions and answers

Related Manuals for Belden Hirschmann GREYHOUND GRS1042

Summary of Contents for Belden Hirschmann GREYHOUND GRS1042

  • Page 1 User Manual Installation GREYHOUND Switch GRS1042/GRS1142 GREYHOUND Power supply module GPS1-C/GPS1-K/GPS3-P GREYHOUND Media module GMM20/30/32/40/42 Installation GREYHOUND Switch Technical support Release 07 10/2020 https://hirschmann-support.belden.com...
  • Page 2 The naming of copyrighted trademarks in this manual, even when not specially indicated, should not be taken to mean that these names may be considered as free in the sense of the trademark and tradename protection law and hence that they may be freely used by anyone. ©...
  • Page 3 Contents Important information Safety instructions About this Manual Legend Description General device description Device name and product code 1.2.1 Basic device 1.2.2 Power supply modules 1.2.3 Media modules Device views 1.3.1 GRS1042 1.3.2 GRS1142 1.3.3 Power supply modules 1.3.4 Media modules 1.3.5 Port assignments Power supply Signal contact...
  • Page 4 1.9.1 V.24 interface (external management) 1.9.2 USB interface 1.9.3 SD card interface Installation Checking the package contents Installing the SD card (optional) Installing a power supply module Installing a media module (optional) Installing a cover panel (optional) Installing and grounding the device Connecting the terminal blocks 2.7.1 Supply voltage 2.7.2 Signal contact...
  • Page 5 7.1.3 Media modules Dimension drawings EMC and immunity Network range Power consumption/power output Scope of delivery, order numbers and accessories Underlying technical standards Further support Installation GREYHOUND Switch Release 07 10/2020...
  • Page 6 Important information Note: Read these instructions carefully, and familiarize yourself with the device before trying to install, operate, or maintain it. The following notes may appear throughout this documentation or on the device. These notes warn of potential hazards or call attention to information that clarifies or simplifies a procedure.
  • Page 7 Safety instructions WARNING UNCONTROLLED MACHINE ACTIONS To avoid uncontrolled machine actions caused by data loss, configure all the data transmission devices individually. Before you start any machine which is controlled via data transmission, be sure to complete the configuration of all data transmission devices. Failure to follow these instructions can result in death, serious injury, or equipment damage.
  • Page 8 Correct usage  Only use the device for those purposes specified in the catalog and in the technical description. Only operate the device with external devices and components that are recommended and permitted by the manufacturer. The proper and safe operation of this product depends on proper handling during transport, proper storage, assembly and installation, and conscientious operation and maintenance procedures.
  • Page 9 Requirements for connecting the supply voltage  Device variant Prerequisites: All variants All of the following requirements are complied with:  The supply voltage corresponds to the voltage specified on the type plate of the device.  The power supply conforms to overvoltage category I or II. ...
  • Page 10 Device variant Prerequisites: Power supply All of the following requirements are complied with: module  Supply with DC voltage: Install a fuse suitable for DC voltage in the plus conductor of the power characteristic value K supply. Connect the minus conductor to the ground potential. If the minus conductor is not connected to the ground potential, also install an external fuse in the minus conductor.
  • Page 11 Relevant for use in explosion hazard areas (Hazardous  Locations, Class I, Division 2) Ordinary Location, Explosive Atmosphere Class I Non-Hazardous Area, Division 2, Groups A, B, C, D Non-Explosive Atmosphere Hazardous Location Explosive Atmosphere Class I, Division 2, Groups A, B, C, D Hazardous Location Signal Contact Pin 1 and 4 (Maintenance only)
  • Page 12 Capacitance and inductance of the fi eld wiring from the non-incendive circuit to the asso- ciated apparatus shall be calculated and must be included in the system calculations as shown in Table 1. Cable capacitance (C ) plus non-incendive equipment capacitance (C ) must be less than cable the marked capacitance (C...
  • Page 13 ATEX directive 2014/34/EU – specific regulations for safe  operation II 3G Ex nA IIC T4 Gc Ta: −40 °F ... +158 °F (−40 °C ... +70 °C) for temperature range characteristic value T and E Ta: +32 °F ... +140 °F (0 °C ... +60 °C) for temperature range characteristic value S DEKRA 17ATEX0024X List of...
  • Page 14 Device casing  Only technicians authorized by the manufacturer are permitted to open the casing.  Keep the ventilation slits free to ensure good air circulation.  Make sure there is at least 3.94 in (10 cm) of space in front of the ventilation slits of the casing.
  • Page 15 CE marking  The labeled devices comply with the regulations contained in the following European directive(s): Device variant Directive All variants 2011/65/EU and 2015/863/EU (RoHS) Directive of the European Parliament and of the Council on the restriction of the use of certain hazardous substances in electrical and electronic equipment.
  • Page 16 47 CFR § 2.1077 Compliance Information GREYHOUND Switch GMM20-... U.S. Contact Information Belden – St. Louis 1 N. Brentwood Blvd. 15th Floor St. Louis, Missouri 63105, United States Phone: 314.854.8000 This device complies with part 15 of the FCC Rules. Operation is subject...
  • Page 17 About this Manual The “Installation” user manual contains a device description, safety instructions, a description of the display, and the other information that you need to install the device. Documentation mentioned in the “User Manual Installation” that is not supplied with your device as a printout can be found as PDF files for downloading on the Internet at: https://www.doc.hirschmann.com Installation GREYHOUND Switch...
  • Page 18 Legend The symbols used in this manual have the following meanings:  Listing Work step   Subheading Installation GREYHOUND Switch Release 07 10/2020...
  • Page 19 Supply voltage range  Certifications You have numerous options of combining the device characteristics. You can determine the possible combinations using the configurator which is available in the Belden Online Catalog https://catalog.belden.com on the web page of the device. Installation GREYHOUND Switch...
  • Page 20 Power supply modules  GPS1-C GPS1-K GPS3-P Figure 2: Power supply modules: Power supply module variants You have the option to select either 1 or 2 power supply modules with different input voltages:  Low Voltage / Power over Ethernet PoE(+) ...
  • Page 21 Media modules  Power Power Power Power Power Power 2 Power Figure 3: Media modules: Media module variants You have the option to select either 1 or 2 media modules. By using a media module, you obtain up to 8 additional Fast and/or Gigabit Ethernet ports.
  • Page 22 Device name and product code The device name corresponds to the product code. The product code is made up of characteristics with defined positions. The characteristic values stand for specific product properties. 1.2.1 Basic device Item Characteristic Characte- Description ristic value 1 ...
  • Page 23 Item Characteristic Characte- Description ristic value Cover panel for Not present media module slot 1 × Cover panel for slot 2 2 × Cover panel for slots 1 and 2 18 ... 19 Certificates and You will find detailed information on the certificates and declarations declarations applying to your device in a separate overview.
  • Page 24 1.2.2 Power supply modules Item Characteristic Characte- Description ristic value 1 ... 3 Product GREYHOUND Power supply module Type Standard Power supply for basic device PoE (+) basic device Power supply for basic device and PoE(+) (hyphen) – Rated voltage Rated voltage range range 24 V DC ...
  • Page 25 1.2.3 Media modules Item Characteristic Characte- Description ristic value 1 ... 3 Product GREYHOUND Media Module Data rate 100 Mbit/s 100 Mbit/s and (10)/100/1000 Mbit/s (10)/100/1000 Mbit/s PoE support without PoE(+) support PoE(+) support (hyphen) – 7 ... 8 Configuration 2 ×...
  • Page 26 Application case Certificates and declarations Characteristic value Standard applications ATEX (2014/34/EU) EN 60950-1 EN 61131-2 ISA-12.12.01 – Class I, Div. 2 cUL 60950-1 Substation applications IEC 61850-3 IEEE 1613 Navy applications DNV GL Railway applications EN 50121-4 (trackside) Table 4: Assignment: application cases, certificates and declarations, characteristic values a.
  • Page 27 Device views 1.3.1 GRS1042 11 11 Front view - characteristic value 6T6Z LED display elements for device status Display elements for power supply module status Out-of-band management port SFP slot for 1/2.5 Gbit/s F/O connections SFP slot for 100/1000 Mbit/s F/O connections Cover panel for media module slot Cover panel for media module slot Oblong hole...
  • Page 28 Rear view - characteristic value 6T6F and AT2Z Cover panel for power supply module slot 1 Cover panel for power supply module slot 2 2-pin terminal block for the supply voltage, characteristic value L Connection for the signal contact 3-pin terminal block for the supply voltage, characteristic value H Grounding screw 1.3.2 GRS1142...
  • Page 29 11 11 Rear view - characteristic value 6T6Z Grounding screw 2-pin terminal block for the supply voltage, characteristic value L SFP slot for 1/2.5 Gbit/s F/O connections SFP slot for 100/1000 Mbit/s F/O connections Cover panel for media module slot Cover panel for media module slot Oblong hole Screw...
  • Page 30 1.3.3 Power supply modules GPS1-C GPS1-K GPS3-P Figure 4: Power supply modules: Power supply module variants Installation GREYHOUND Switch Release 07 10/2020...
  • Page 31 1.3.4 Media modules The specified media module configurations are examples. Other configurations are possible. See “Media modules” on page 25. GMM20-VVUUMMNN Port Port description 1, 3 2 × DSC singlemode socket 5, 7 2 × ST singlemode socket 2, 4 2 ×...
  • Page 32 GMM40-TTTTTTTT / GMM42-TTTTTTTT Port Port description 1, 3 2 × RJ45 socket 5, 7 2 × RJ45 socket 2, 4 2 × RJ45 socket 6, 8 2 × RJ45 socket GMM40-OOOOOOOO Port Port description 1, 3 2 × SFP slot 5, 7 2 ×...
  • Page 33 GMM40-OOOOTTTT / GMM42-OOOOTTTT Port Port description 1, 3 2 × SFP slot 5, 7 2 × SFP slot 2, 4 2 × RJ45 socket 6, 8 2 × RJ45 socket Installation GREYHOUND Switch Release 07 10/2020...
  • Page 34 1.3.5 Port assignments Basic device  0.5669 pt V.24 Status MGMT MAC-ADDRESS Figure 5: Port assignments: Basic device port assignments Note: The port assignment pictured is exemplary. The sequence of the port numbering is identical for every device variant. Media modules ...
  • Page 35 Power supply You have the following options to supply your device with voltage: GRS1042 GRS1142 Figure 7: Power supply: Supply voltage characteristic value LL  via 2-pin terminal blocks Device variants with characteristic value LL GRS1042 GRS1142 Figure 8: Power supply: Supply voltage characteristic value HH ...
  • Page 36 GRS1042 GRS1142 Figure 9: Power supply: Supply voltage characteristic value HL  via one 2-pin and one 3-pin terminal block Device variants with characteristic value HL You will find information on connecting the supply voltage here: “Connecting the terminal blocks” on page Installation GREYHOUND Switch Release 07 10/2020...
  • Page 37 Signal contact GRS1042 GRS1142 Figure 10: Signal contact: 2-pin terminal block with screw locking The signal contact is a potential-free relay contact. The device allows you to perform remote diagnosis via the signal contact. In the process, the device signals events such as a line interruption. When an event occurs, the device opens the relay contact and interrupts the closed circuit.
  • Page 38 1.6.2 100/1000 Mbit/s F/O port This port is an SFP slot. The 100/1000 Mbit/s F/O port allows you to connect network components according to the IEEE 802.3 100BASE-FX/1000BASE-SX/1000BASE-LX standard. This port supports:  1000 Mbit/s full duplex  100 Mbit/s half-duplex mode, 100 Mbit/s full duplex mode Delivery state: ...
  • Page 39 1.6.4 10/100/1000 Mbit/s twisted pair port This port is an RJ45 socket. The 10/100/1000 Mbit/s twisted pair port allows you to connect network components according to the IEEE 802.3 10BASE-T/100BASE-TX/ 1000BASE-T standard. This port supports:  Autonegotiation  Autopolarity  Autocrossing (if autonegotiation is activated) ...
  • Page 40 1.6.6 Out-of-band management port This port is an RJ45 socket. The port allows you to connect network components according to the IEEE 802.3 10BASE-T/100BASE-TX standard. This port supports:  Autonegotiation  100 Mbit/s half duplex, 100 Mbit/s full duplex,10 Mbit/s half duplex, 10 Mbit/s full duplex The port allows you to manage the device and upload configurations via the following protocols:...
  • Page 41 Media modules  RJ45 10/100 Mbit/s 1000 Mbit/s MDI-X mode BI_DB+ Negative V RX− BI_DB− Negative V BI_DA+ Positive V — BI_DD+ — — BI_DD− — TX− BI_DA− Positive V — BI_DC+ — — BI_DC− — a. Exclusively on PoE-capable media modules. Display elements After the supply voltage is set up, the Software starts and initializes the device.
  • Page 42 1.8.1 Device state These LEDs provide information about conditions which affect the operation of the whole device. V.24 MGMT GRS1142 V.24 MGMT GRS1042 P1 V.24 Display Color Activity Meaning Status Device Status — none Device is starting and/or is not ready for operation.
  • Page 43 Display Color Activity Meaning Storage medium — none ACA storage medium not connected ACA22 green lights up ACA storage medium connected ACA31 flashes 3 times Device writes to/reads from the storage a period medium yellow lights up ACA storage medium inoperative Supply voltage —...
  • Page 44 1.8.2 Port status These LEDs provide port-related information. GRS1142 GRS1042 Slot 1 Slot 2 GRS1142 V.24 MGMT GRS1142 V.24 MGMT GRS1042 MGMT Figure 11: Port status: Location of the display elements on the basic device LED Display Color Activity Meaning Link state/ —...
  • Page 45 Switching LEDs  LED display Position on the device Service panel Only device variants GRS1142 Port panel GRS1042 GRS1142 With device variants GRS1142 the port status is displayed on the service panel by default. You have the option of changing between the LED displays using the command line interface (CLI).
  • Page 46 1.8.3 Media module status GMM20/GMM30/GMM40  Power Power Power Power Power Figure 12: Media module status: location of the display elements on the module Display Color Activity Meaning Power Supply — none Media module is inoperative voltage green lights up Voltage supply to the media module is Link state/ —...
  • Page 47 GMM32/GMM42  Power Power Power Power Power Power Figure 13: Media module status: Location of the display elements on the PoE module Display Color Activity Meaning Power Supply — none Media module is inoperative voltage green lights up Voltage supply to the media module is on Voltage supply to the PoE port is on yellow lights up PoE voltage is missing or is too low...
  • Page 48 Management interfaces 1.9.1 V.24 interface (external management) GRS1042 GRS1142 Figure 14: V.24 interface: Location on the device A serial interface is provided on the RJ45 socket (V.24 interface) for the local connection of an external management station (VT100 terminal or PC with corresponding terminal emulation).
  • Page 49 1.9.2 USB interface GRS1042 GRS1142 Figure 15: USB interface: Location on the device The USB interface allows you to connect the AutoConfiguration Adapter ACA22 storage medium. This is used for saving/loading the configuration data and diagnostic information, and for loading the software. See “Accessories”...
  • Page 50 1.9.3 SD card interface Prerequisite: Only use Hirschmann SD cards. See “Accessories” on page 91. GRS1042 GRS1142 Figure 16: SD card interface: Location on the device The SD card interface allows you to connect the AutoConfiguration Adapter ACA31 storage medium. This is used for saving/loading the configuration data and diagnostic information, and for loading the software.
  • Page 51 Installation The devices have been developed for practical application in a harsh industrial environment. On delivery, the device is ready for operation. Perform the following steps to install and configure the device:  Checking the package contents  Installing the SD card (optional) ...
  • Page 52 Installing a power supply module Hirschmann supplies the power supply modules in a ready-to-operate state. The power supply modules are hot-swappable. Figure 17: Installing a power supply module: Installation sequence Proceed as follows:  Remove the cover panel (if mounted) from the power supply module slot on the device (1).
  • Page 53 Installing a media module (optional) Hirschmann supplies the media modules in a ready-to-operate state. By using a media module, you obtain up to 8 additional Fast and/or Gigabit Ethernet ports. You have the option of mounting the media modules while the device is operating.
  • Page 54  Lock the media module in place by pressing the locking levers inwards (3).  Fasten the media module with the screws in the front panel of the basic device. You find the prescribed tightening torque in chapter: “General technical data” on page 74 Installing a cover panel (optional) Prerequisite: To comply with the EMC requirements, seal unused open slots with a cover...
  • Page 55 CAUTION OVERHEATING OF THE DEVICE Verify that all ventilation slots are clear when installing the device. Avoid touching the device while it is operating. Failure to follow these instructions can result in minor injury or equipment damage. Mounting in a switch cabinet ...
  • Page 56 Figure 19: Assembly in a switch cabinet with sliding/mounting rails 1 - device 2 - sliding/mounting rail 3 - 19" switch cabinet Proceed as follows:  Assemble the sliding or mounting rails in the 19" switch cabinet as specified by the manufacturer. ...
  • Page 57 Mounting on a vertical flat surface  WARNING FIRE HAZARD Install the device in a fire enclosure according to EN 60950-1 if you install the device vertically. Failure to follow these instructions can result in death, serious injury, or equipment damage. Figure 20: Mounting on a vertical flat surface Proceed as follows: ...
  • Page 58 Grounding the device  The device variants have a connection for protective grounding. Proceed as follows:  Ground the device via the ground screw. You find the prescribed tightening torque in chapter: “General technical data” on page 74 Note: Applies to device variants featuring supply voltage characteristic value P: With redundant power supply with 2 power supply modules GPS3-P (supply voltage characteristic value P): The use of power sources with a...
  • Page 59 Connecting the terminal blocks 2.7.1 Supply voltage WARNING ELECTRIC SHOCK Start connecting electrical wires only if all safety requirements listed in chapter “General safety instructions” are fulfilled. Failure to follow these instructions can result in death, serious injury, or equipment damage. WARNING ELECTRIC SHOCK Never insert pointed objects (narrow screwdrivers, wires, etc.) into the...
  • Page 60 The supply voltage is electrically isolated from the casing. Note: The supply voltage is connected to the device casing through protective elements exclusively. Note: The supply voltage for the power supply modules is provided at terminal blocks P1 and P2 for the corresponding slots P1 and P2. For every supply voltage to be connected, perform the following steps: ...
  • Page 61 Supply voltage with characteristic value LL  GRS1142 GRS1042 RELAY Figure 21: Supply voltage characteristic value LL: Location of the supply voltage connections Type of the voltages Specification of the supply Pin assignment that can be voltage connected DC voltage Rated voltage range Plus terminal of the supply voltage ...
  • Page 62 Supply voltage with characteristic value HH  GRS1142 GRS1042 Figure 22: Supply voltage characteristic value HH: Location of the supply voltage connections Type of the voltages Specification of the supply Pin assignment that can be connected voltage DC voltage Rated voltage range Plus terminal of the supply 60 V DC ...
  • Page 63 Supply voltage with characteristic value HL  GRS1142 GRS1042 RELAY Figure 23: Supply voltage characteristic value HL: Location of the supply voltage connections Type of the voltages Specification of the supply Pin assignment that can be connected voltage DC voltage Rated voltage range Plus terminal of the supply 60 V DC ...
  • Page 64 2.7.2 Signal contact GRS1042 GRS1142 Figure 24: Signal contact: 2-pin terminal block with screw locking  Connect the signal contact lines with the terminal block connections.  Fasten the wires in the terminal block by tightening the terminal screws. Installation GREYHOUND Switch Release 07 10/2020...
  • Page 65 Installing an SFP transceiver (optional) Prerequisites: Exclusively use Hirschmann SFP transceivers. See “Accessories” on page 91. Figure 25: Installing SFP transceivers: Installation sequence Proceed as follows:  Take the SFP transceiver out of the transport packaging (1).  Remove the protection cap from the SFP transceiver (2). ...
  • Page 66 Operating the device Proceed as follows:  Use screws to secure the connectors to the device. You find the prescribed tightening torque in chapter: “General technical data” on page 74  Enable the supply voltage. 2.10 Connecting data cables Note the following general recommendations for data cable connections in environments with high electrical interference levels: ...
  • Page 67 Making basic settings Note: 2 or more devices configured with the same IP address can cause unpredictable operation of your network. Install and maintain a process that assigns a unique IP address to every device in the network. The IP parameters must be entered when the device is installed for the first time.
  • Page 68  Log on to the device again with your new password. Note: If you lost your password, then use the System Monitor to reset the password. For further information see: https://hirschmann-support.belden.com/en/kb/required-password- change-new-procedure-for-first-time-login Installation GREYHOUND Switch Release 07 10/2020...
  • Page 69 Monitoring the ambient air temperature Operate the device below the specified maximum ambient air temperature exclusively. See “General technical data” on page 74. The ambient air temperature is the temperature of the air at a distance of 2 in (5 cm) from the device. It depends on the installation conditions of the device, for example the distance from other devices or other objects, and the output of neighboring devices.
  • Page 70 Maintenance and service  When designing this device, Hirschmann largely avoided using high-wear parts. The parts subject to wear and tear are dimensioned to last longer than the lifetime of the product when it is operated normally. Operate this device according to the specifications. ...
  • Page 71 Disassembly De-installing a power supply module Figure 26: De-installing a power supply module: De-installation sequence Proceed as follows:  Remove the screws on the front panel of the power supply module (1).  Pull the power supply module out of the slot (2). ...
  • Page 72 Removing a media module Figure 27: De-installing a media module: De-installation sequence Proceed as follows:  Loosen the screws in the front panel of the media module.  Open the locking mechanism of the media module by pressing the locking levers outwards (1, 2).
  • Page 73 Removing an SFP transceiver (optional) Figure 28: De-installing SFP transceivers: De-installation sequence Proceed as follows:  Open the locking mechanism of the SFP transceiver (1).  Pull the SFP transceiver out of the slot via the open locking mechanism (2). ...
  • Page 74 Technical data General technical data 7.1.1 Basic device Dimensions See “Dimension drawings” on page 78. Weight 7.93 lb (3.6 kg) Power supply Rated voltage range 24 V DC ... 48 V DC Supply voltage with 48 V DC ... 54 V DC characteristic value L Back-up fuse for each Nominal rating:...
  • Page 75 Climatic conditions Ambient air Standard during operation temperature up to 6562 ft ASL +32 °F ... +140 °F (2000 m ASL) (0 °C ... +60 °C) above 6562 ft ASL +32 °F ... +122 °F (2000 m ASL) (0 °C ... +50 °C) Standard with Conformal Coating up to 6562 ft ASL...
  • Page 76 7.1.2 Power supply modules Dimensions See “Dimension drawings” on page 78. Weight GPS1-C 21.16 oz (600 g) GPS1-K 25.04 oz (710 g) GPS3-P 26.46 oz (750 g) Mounting of the Tightening torque 4.4 lb-in (0.5 Nm) power supply modules Mounting of the Tightening torque 4.4 lb-in (0.5 Nm) cover panel...
  • Page 77 7.1.3 Media modules Dimensions See “Dimension drawings” on page 78. Weight GMM20-MMMMMMMM 16.72 oz (520 g) additional 150 g for media modules with GMM20-NNNNNNNN temperature range characteristic value T GMM20-VVVVVVVV and E GMM20-UUUUUUUU GMM30-MMMMTTTT 19.4 oz (550 g) GMM30-NNNNTTTT GMM30-VVVVTTTT GMM30-UUUUTTTT GMM40-TTTTTTTT 17.28 oz (490 g)
  • Page 78 Dimension drawings Basic device  inch 18.35 17.5 0.39 Figure 29: Basic device: Dimension drawing device variant characteristic value 6T6Z with 2 × power supply module GPS3-P Installation GREYHOUND Switch Release 07 10/2020...
  • Page 79 inch 18.35 17.5 0.39 Figure 30: Basic device: Dimension drawing device variant characteristic value AT2Z with 2 × power supply module GPS1-C Note: The dimensions of the basic device is identical for every device variant. Differences result exclusively from the different dimensions of the power supply module variants.
  • Page 80 Power supply modules  inch 6.81 6.58 Figure 31: Power supply modules: Dimension drawing power supply module GPS1- C/GPS1-K 6.81 inch 6.58 Figure 32: Power supply modules: Dimension drawing power supply module GPS3- Installation GREYHOUND Switch Release 07 10/2020...
  • Page 81 Media modules  5.32 inch 5.08 Figure 33: Media modules: Dimension drawing media modules (exemplary) Installation GREYHOUND Switch Release 07 10/2020...
  • Page 82 EMC and immunity EMC interference Standard Merchant Navy Railway Substation emission applications applications applications (trackside) Radiated emission EN 55032 Class A Class A Class A Class A DNV GL Guidelines — EMC 1 — — FCC 47 CFR Part 15 Class A Class A Class A...
  • Page 83 EMC interference Standard Merchant Navy Railway Substation immunity applications applications applications (trackside) Electromagnetic field EN 61000-4-3 80 MHz ... 3000 MHz max. 10 V/m max. 10 V/m max. 20 V/m max. 10 V/m IEEE 1613 80 MHz ... 1000 MHz —...
  • Page 84 EMC interference Standard Merchant Navy Railway Substation immunity applications applications applications (trackside) Damped oscillation – DC supply connection EN 61000-4-12 line/ground — — — 2.5 kV IEEE C37.90.1 EN 61000-4-12 line/line — — — 1 kV IEEE C37.90.1 Damped oscillation – data line EN 61000-4-12 line/ground —...
  • Page 85 Network range Note: The line lengths specified for the transceivers apply for the respective fiber data (fiber attenuation and Bandwidth Length Product (BLP)/ Dispersion). Product code Mode Wave Fiber System Example for F/O cable length Fiber /Dispersion M-SFP-... length attenuation attenuation -SX/LC...
  • Page 86 Product code Mode Wave length Wave length Fiber System Example for F/O Fiber Dispersion M-SFP-BIDI... attenuation cable length attenuation Type A LX/LC EEC SM 1310 nm 1550 nm 9/125 µm 0 dB ... 11 dB 0 km ... 12.43 mi 0.4 dB/km 3.5 ps/(nm×km) (0 km ...
  • Page 87 Product code Mode Wave length Fiber System Example for F/O line Fiber BLP/Dispersion attenuation length attenuation SFP-FAST-MM/LC EEC 1310 nm 62.5/125 µm 0 dB ... 11 dB 0 mi ... 2.49 mi 1.0 dB/km 500 MHz×km (0 km ... 4 km) SFP-FAST-SM/LC 1310 nm 9/125 µm...
  • Page 88 a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul b. F/O connections using DWDM technology (Dense Wave Division Multiplexing) typically have filters which use up the remaining attenuation budget.For point-to-point connections without filters and with max. 1.5 dB of connector losses the max. F/O connection length is 59 mi (95 km). 10/100/1000 Mbit/s twisted pair port Length of a twisted pair segment max.
  • Page 89 Power consumption/power output Name Maximum Maximum power consumption power output Basic devices + 1 PSU GRS1042 AT2Z... 32 W 110 Btu (IT)/h GRS1142 AT2Z... GRS1042 6T6Z... GRS1142 6T6Z... Power supply modules GPS1-K + 2.5 W 9 Btu (IT)/h GPS1-C + 3.5 W 12 Btu (IT)/h GPS3-P + 5.5 W...
  • Page 90 Scope of delivery, order numbers and accessories Scope of delivery  Amount Article 1 × Device 1 × Safety and general information sheet 1 × 2-pin terminal block for signal contact 2 × Bracket 2 × 2-pin terminal block for the supply voltage (only for device variants featuring supply voltage with characteristic value LL) 2 ×...
  • Page 91 Accessories  Note that products recommended as accessories may have different characteristics to those of the device, which may limit the application range of the overall system. For example, if you add an accessory with IP20 to a device with IP65, the degree of protection of the overall system is reduced to IP20.
  • Page 92 Fast Ethernet SFP transceiver Order number M-FAST SFP-TX/RJ45 942 098-001 M-FAST SFP-TX/RJ45 EEC 942 098-002 The following operating conditions apply to twisted pair transceivers:  Usable with: - HiOS as of software version 03.0.00 - for PRP ports on RSP devices, as of software version 02.0.01 - for PRP ports on EES devices, as of software version 02.0.02 - Classic switch software as of software version 08.0.00 - HiSecOS as of software version 01.2.00...
  • Page 93 Underlying technical standards Name ATEX (2014/34/EU) ATEX – Intended use of equipment and protection systems in potentially explosive areas. Australian Regulatory Compliance Mark (RCM) Australian Radiocommunications Standard 2008, Radiocommunications Act 1992 FCC 47 CFR Part 15 Code of Federal Regulations DNVGL-CG-0339 Environmental test specification for electrical, electronic and programmable equipment and systems.
  • Page 94 The device has an approval based on a specific standard exclusively if the approval indicator appears on the device casing. If your device has a shipping approval according to DNV GL, you find the approval mark printed on the device label. You will find out whether your device has other shipping approvals on the Hirschmann website at www.hirschmann.com in the product information.
  • Page 95 A list of local telephone numbers and email addresses for technical support directly from Hirschmann is available at https:// hirschmann-support.belden.com. This site also includes a free of charge knowledge base and a software download section. Hirschmann Competence Center The Hirschmann Competence Center is ahead of its competitors on three counts with its complete range of innovative services: ...
