OWNER'S OPERATING MANUAL
INVERTER GENERATOR
AC output.................................................................................................................................... 230V~50Hz
Rated power........................................................................................................................................1750W
Peak power.........................................................................................................................................2100W
Rated current.......................................................................................................................................... 7.6A
Phase................................................................................................................................................... Single
Power factor....................................................................................................................................... cosø=1
Displacement..........................................................................................................................................80cc
DC output (Cigarette socket)..............................................................................................................12V/5A
DC output (USB socket)............................................................................................................ 5V/Max 2.1A
Engine.......................................................................................... Single Cylinder, OHV 4 stroke, Air cooled
No load speed (low)....................................................................................................................... 3300min
No load speed (high)...................................................................................................................... 4300min
Continuous operating time...............................................................................................3.5hrs (100% load)
Fuel tank capacity...................................................................................................................................... 4L
Fuel type............................................................................................................................... Unleaded petrol
Oil type...................................................................................................................................... SAE 10W-30
Oil capacity..............................................................................................................................................0.4L
Ignition system...................................................................................................................................... C.D.I.
Starting system......................................................................................................................... Recoil starter
Spark plug type.................................................................................................................................... ER6C
Protection class/Quality class/Performance class......................................................................IP23M/A/G1
Max. temperature.................................................................................................................................... 40
Max. altitude........................................................................................................................................1000m
Weight.................................................................................................................................................... 20kg
Sound @7m...................................................................................................................................... 58dB(A)
THANK YOU FOR BUYING A RYOBI
Your new inverter generator has been engineered and manufactured to Ryobi's
high standard of dependability, ease of operation and operator safety. Properly
cared for, it will give you years of rugged, trouble free performance. If you use
your inverter generator properly and only for what it is intended, you will enjoy
years of safe, reliable service.
CAUTION: Carefully read through this entire owner's
KEEP THIS MANUAL FOR FUTURE REFERENCE
MODEL RG-2100I
SPECIFICATIONS
INVERTER GENERATOR
manual, paying close attention to the general
safety rules and rules for safe operation,
before using.
1
-1
-1

Advertisement

Table of Contents
loading

Related Manuals for Ryobi RG-2100I

Summary of Contents for Ryobi RG-2100I

  • Page 1 THANK YOU FOR BUYING A RYOBI INVERTER GENERATOR Your new inverter generator has been engineered and manufactured to Ryobi’s high standard of dependability, ease of operation and operator safety. Properly cared for, it will give you years of rugged, trouble free performance. If you use your inverter generator properly and only for what it is intended, you will enjoy years of safe, reliable service.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS The purpose of safety rules is to attract your DANGER: CARBON MONOXIDE. attention to possible dangers. The safety symbols Using a generator indoors CAN KILL and the explanations with them, require your YOU IN MINUTES. careful attention and understanding. The safety Generator exhaust contains high levels of carbon warnings do not by themselves eliminate any monoxide (CO), a poisonous gas you cannot see...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS Do not operate generator when you are tired or To prevent an electric shock, never operate the under the influence of drugs, alcohol, or machine in rain, snow or touch with wet hands. medication. Check the fuel system periodically for leaks. Seals The electrical output load must not exceed the and hoses should be checked for signs of maximum load stated on the rating plate.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS For power outages, permanently installed Inspect the unit before each use for loose stationary generators are better suited for providing fasteners, fuel leaks, etc. Replace damaged parts. back-up power to the home. Even a properly Use only recommended or equivalent replacement connected portable generator can become parts and accessories.

  • Page 5: Specific Safety Rules

    SPECIFIC SAFETY RULES WARNING: Do not use the generator in To avoid a fire if you spill fuel while refuelling, clean areas where there is a risk of explosion up before starting the generator. or fire from combustible materials. The Never operate or store the generator on its side, sparks possibly caused when using this generator ALWAYS operate or store in an upright manner on...
  • Page 6 SPECIFIC SAFETY RULES Always observe normal safety precautions with ALL PERSONAL SAFETY appliances used with this generator. CLOTHING Never transport the generator with fuel in the tank. Do not wear loose clothing, jewellery or anything ALWAYS empty the fuel tank. that could get caught in moving machinery.
  • Page 7 DESCRIPTION 14 15 1. Handle 12. Overload indicator (red) 2. Fuel cap 13. Output indicator (green) 3. Fuel cap vent 14. Economy switch 4. Oil container 15. Engine restart button 5. Spark plug socket 16. DC circuit breaker 6. Screw driver 17.

  • Page 8: Unpacking And Assembly

    UNPACKING & ASSEMBLY UNPACKING Do not throw the packaging away, keep it safe Caution! This packaging contains sharp objects. throughout the guarantee period, then recycle if Carefully unpack your generator. This generator is possible, otherwise dispose of it by the proper heavy (20kg) and may require two (2) people to lift.

  • Page 9: Filling The Fuel Tank

    FILLING THE FUEL TANK ONLY USE UNLEADED PETROL - NO ETHANOL Fuel tank capacity – 4 litres (4 L) Use of incorrect fuel and/or oil may damage the generator and will not be covered under warranty. Do not use E10 or any type of ethanol fuel as this will damage the generator and will not be covered under warranty.

  • Page 10: Operation

    GENERATOR ‘EARTHING’ Before using this generator it must be prepared correctly before use. Locate the generator on firm level ground away from buildings or other structures ensuring that the exhaust is not obstructed. Earth Point Your generator must be properly connected to an appropriate ground to help prevent electric shock.
  • Page 11 OPERATION ECONOMY SWITCH (FIG.10) AC OUTLET When this switch is turned on your generator will Your generator is equipped with two 230V AC use less fuel, however only switch on when loads power sockets. These will run a range of devices of less than 900W are attached.
  • Page 12 OPERATION USING THE AC OUTLET SAFETY DEVICES Check that the only illuminated light is the AC OUTLET green output power. Your generator is equipped with an output indicator Lift the flap and plug your appliance into the light. When this light goes out and the red light AC outlet socket on the face plate.
  • Page 13 OPERATION DC BATTERY CHARGING FUNCTION This function is applicable to 12V battery charging only. Disconnect the leads from the battery. Loosen the vents on the battery. 12V DC Socket Make sure the battery fluid level is correct Using a hydrometer measure the specific gravity of the battery fluid and calculate the charging time in accordance with the table shown, Fig 12.
  • Page 14 MAINTENANCE GENERAL MAINTENANCE Keep the generator in a clean and dry environment where it is not exposed to dust, dirt, moisture, or corrosive vapours. Do not allow the cooling air slots in the generator to become clogged with foreign material such as leaves, snow, etc.
  • Page 15 MAINTENANCE CHECKING/CLEANING THE AIR FILTER For proper performance and long life, keep air filters clean. 1. Remove the 4 access panel screws with a screwdriver and then remove panel. 2. Loosen the air filter screw and remove the air filter panel (Fig.18 & 19). 3.
  • Page 16 MAINTENANCE DRAINING THE CARBURETOR Store the generator in a dry well ventilated place 1. Place a container underneath the generator under a cover to prevent any dust or debris from accumulating on the generator. 2. Unscrew the draining bolt of the carburetor and let the fuel pour into the container.

  • Page 17: Maintenance Chart

    MAINTENANCE CHART Item Remark Pre-operation Initial 1 month Every 3 month Every 6 month Every 12 month check (daily) or 20hours or 50 hours or 100 hours or 300 hours Spark plug Check condition Adjust gap and clean Replace if required Engine oil Check oil level Replace...

  • Page 18: Fault Chart

    FAULT CHART CONDITION PROBABLE CAUSE CORRECTIVE ACTION No oil/ Low oil level Fill sump with correct oil Loose spark plug Tighten plug Insufficient Loose cylinder Tighten bolt compression head bolt Damaged gasket Replace gasket FUEL SYSTEM PROBLEMS Insufficient pulling Pull rope sharply speed for starting rope Foreign matter in...
  • Page 19 FAULT CHART CONDITION PROBABLE CAUSE CORRECTIVE ACTION Tripped circuit breaker Reset Poor connection or faulty lead Check and repair Indicator light ON. No AC output Broken recepticle Faulty circuit breaker Check and repair Indicator light OFF. Generator problem No AC output Output power too Engine RPM set too No load speed set...
  • Page 20 SYMBOLS Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOLS DESIGNATION/EXPLANATION Do not expose to rain or use in damp locations. To reduce the risk of injury, the user must read and understand the operator’s manual before using this product.
  • Page 21 Now that you have purchased your tool, should a need ever exist of repair or service, simply contact your nearest Ryobi Authorised Service Centre or other qualified service organistion. Be sure to provide all pertinent facts when you call or visit.
  • Page 22 NOTES...
  • Page 23 NOTES...
