Lafayette PARKE Faux Wood Shutters Installation Instructions

L-frame, z-frame

Advertisement

Thank You

Before Installing

Carefully unwrap your frames. Your frames will be labeled Left Top and Right Top, Top and Bottom.
Pencil
Step 1
Prep Frame
Lay out your frame to begin building it
Line up rout on frame piece with
Hoffman key and press firmly until
seated to build frame
Installation Instructions
L-Frame and Z-Frame
Additional fasteners may be needed on your specific mounting surface.
Tools
Screw
Measuring
Level
Driver
tape
2"
Thank you for choosing Parke Faux Wood
With proper installation and care, your
new shutters will provide many years of
beauty and performance.
Drill
Pre-drill holes 2" down from the top of the Side pieces
Inside Mount
2 "
Pre-drill holes 2" in from each side on the Bottom Piece
Faux Wood Shutters
Shutters.
Fasteners
2 1/2" - 3" Wood Screw
(not provided)
Outside Mount
2"
2 "

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PARKE Faux Wood Shutters and is the answer not in the manual?

Questions and answers

Summary of Contents for Lafayette PARKE Faux Wood Shutters

  • Page 1 Faux Wood Shutters Installation Instructions L-Frame and Z-Frame Thank You Thank you for choosing Parke Faux Wood Shutters. With proper installation and care, your new shutters will provide many years of beauty and performance. Before Installing Carefully unwrap your frames. Your frames will be labeled Left Top and Right Top, Top and Bottom. Additional fasteners may be needed on your specific mounting surface.
  • Page 2 Faux Wood Shutters Installation Instructions Step 2 Install Frame Secure frame to window opening using the top two screws only Outside Mount Inside Mount Additional screws may be needed along the sides depending on the size of your window size If installing the Shutter in an inside mount location, shims (not provided) may be required to accomodate an uneven surface Step 3...
  • Page 3 Faux Wood Shutters Installation Instructions Step 4 Check for Squareness If either gap on top or bottom of the Shift bottom of Frame left and right Shutter Panel is uneven, your frame until the gap is even on top and bottom may need adjusted Mark position and hold in place Step 5...
