Load clothes loosely into the dryer. Do not pack the dryer. Allow space for clothes to tumble freely. The following charts show examples
of balanced loads that would allow for proper tumbling.
ULTRA CAPACITY, SUPER CAPACITY and SUPER CAPACITY PLUS DRYERS
Heavy Work Clothes
4 pair of pants
4 pair of jeans
2 sweatshirts
2 sweatpants
4 shirts
Heavy Work Clothes
3 pair of pants
4 pair of jeans
2 pair of overalls
3 shirts
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from dryer.
Do not dry anything that has ever had anything
flammable on it (even after washing).
Failure to follow these instructions can result in death,
explosion, or fire.
This booklet covers several different models. Your dryer may
not have all of the cycles and features described.
Before using your dryer, wipe the dryer drum with a damp cloth to
remove dust from storing and shipping.
1. Load clothes loosely into the dryer and close the door. Do not
pack the dryer. Allow space for clothes to tumble freely.
2. Turn the Cycle Control knob to the recommended cycle for the
type of load being dried. Use the Energy Preferred setting to
dry most heavy to medium weight fabrics.
3. If your dryer has a Temperature selector, set it to the
recommended setting for the type of fabric being dried. See
"Dryer Cycle Descriptions" (separate sheet) for temperature
suggestions. On some models, temperature is included in the
cycle selections.
4

DRYER USE

Loading
Mixed Load
3 sheets (1 king, 2 twin)
4 pillowcases
9 T-shirts
9 pair of shorts
3 blouses
10 handkerchiefs
3 shirts
EXTRA LARGE CAPACITY DRYERS
Mixed Load
3 double sheets
4 pillowcases
8 T-shirts
6 pair of shorts
2 blouses
8 handkerchiefs
Towels
10 bath towels
10 hand towels
14 washcloths
1 bath mat
Towels
10 bath towels
10 hand towels
14 washcloths
1 bath mat
WARNING
No washer can completely remove oil.
Do not dry anything that has ever had any type of oil on
it (including cooking oils).
Items containing foam, rubber, or plastic must be dried
on a clothesline or by using an Air Cycle.
Failure to follow these instructions can result in death
or fire.
4. (OPTIONAL) Your dryer may have a WRINKLE SHIELD™
feature selector. When you are unable to remove a load from
the dryer as soon as it stops, wrinkles can form. This feature
periodically tumbles, rearranges and fluffs the load without
heat to help avoid wrinkling.
5. (OPTIONAL) Your dryer may have an END OF CYCLE SIGNAL.
The signal is helpful when drying items that should be
removed from the dryer as soon as it stops.
On some models, the volume of the End of Cycle signal
can be adjusted. Turn the selector to the desired volume.
On other models, the End of Cycle signal is part of the
Start button and is selectable. Turn the START button to
ON or OFF. The signal will sound only if the selector is set
to On.
Delicates
3 camisoles
1 robe
4 slips
8 undergarments
2 sets of sleepwear
1 child's outfit
Delicates
3 camisoles
1 robe
4 slips
6 undergarments
2 sets of sleepwear
1 child's outfit
Fire Hazard
