Installation and Operator's Manual
(Aurora Wind Interface Rev 4.0)
1.1

WBI Operating Parameters

Description
Input voltage range (no damaging)
Input voltage range (operating)
Input frequency range
Max. operating input current
Input over current (fuse protected)
Max. output power
(@400Vac, PFC≥0.7)
Maximum output current + diversion
load current
Efficiency (@400Vac, PFC≥0.7)
Output Voltage range
Output Voltage range (@ full output
power)
Operating ambient temperature
Enclosure type
Relative Humidity
Audible Noise
Size (height x width x depth):
Table 1: Operating Parameters
* When using wind speed feedback, the frequency range by factory setting is 5-
200Hz; contact factory for different range shifting.
** The over current protection fuses shall be sized depending on the
generator/alternator short circuit current, this value shall be determined by the
generator/Alternator supplier.
Fuses have to trip by generator when embedded crowbar is activated.
PVI-7200-W-I and PVI-4000-W-I are equipped respectively with 15A and 6A fuses
by factory.
*** Limited by the maximum continuous output current (20Adc)
Value
Aurora WBI
0 Vac to 400 Vac
40 Vac to 400 Vac
0Hz to 600Hz *
Up to 16.6 A (rms)
Up to 20 A **
2500W-4000W-7200W
up to 20Adc continuous /
up to 30Adc peak
99.4%
0-600 Vdc
360-600Vdc (PVI-7200-W-I) ***
200-600Vdc (PVI-4000-W-I) ***
-25°C to +55°C (-13°F to 140°F)
Nema 4X
0 – 100 % condensing
< 40dBA
29 x 26 x 9.5 cm
Page 7 of 20
