- Page 1 INSTALLATION AND OPERATION MANUAL Q.PEAK DUO BLK-G6+ / AC Solar Module Series Valid for North America...
-
Page 2: Table Of Contents
INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS... -
Page 3: Introduction
External dimensions in inch (mm) and components for Q.PEAK DUO BLK-G6+ / AC INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS... - Page 4 1 Nominal Voltage Range can be extended if required by the utility. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS...
-
Page 5: The Enphase Iq System
PV module is exported to the utility grid regardless of the performance of the other PV modules in the array. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS... -
Page 6: Requirements
UL 1703). • Installation using a mounting structure for solar modules. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS... -
Page 7: Microinverter Planning
*Limits may vary. Refer to local requirements to define the number Q-12-17-240 2.0m Landscape of microinverters per branch in your area. (120-cell) INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS... -
Page 8: Mounting Options
INSTALLATION Q.PEAK DUO BLK-G6+ / AC 15.0 15.0 ON MOUNTING including clamps has to be evaluated by the system supplier. The listed test load values for Q CELLS were determined with the (380) (380) POINTS 4 x mounting 4 × mounting following clamp parameters: clamp width = 1.58 in (40 mm) and clamp depth = 0.39 in (10 mm). -
Page 9: Electrical Layout
Store the modules securely in cool and dry rooms. The packaging is not weatherproof. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS... -
Page 10: Preparation Of Installation
Ä Only use electrical system components approved conditioning systems. for wet locations. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS... -
Page 11: Module Installation
This will void Enphase's warranty. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS... -
Page 12: Electrical Connection
INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS... -
Page 13: After Installation
Modules must be cleaned manually and only with Ä mechanical friction. sufficient water. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS... -
Page 14: Faults And Defects
Do not let IPA run down between the module and the frame or into the module edges. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS... -
Page 15: Appendix
INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS ... - Page 16 Use the terminator to seal the conductor end of the Enphase Q Cable; no other method is allowed. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS ...
- Page 17 Q.PEAK DUO BLK-G6+/AC 2020 Enphase Energy Inc. All rights reserved. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS 2020 Enphase Energy Inc. All rights reserved.
- Page 18 2020 Enphase Energy Inc. All rights reserved. 2020 Enphase Energy Inc. All rights reserved. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS...
- Page 19 12 cm (4¾ “) in diameter. 2020 Enphase Energy Inc. All rights reserved. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS...
- Page 20 2020 Enphase Energy Inc. All rights reserved. 2020 Enphase Energy Inc. All rights reserved. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS...
- Page 21 F. Click Reset DC Resistance Low - Power Off Sensor. 2020 Enphase Energy Inc. All rights reserved. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS...
- Page 22 6 of this manual. 2020 Enphase Energy Inc. All rights reserved. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS...
- Page 23 O. Ship the old microinverter to Enphase using the supplied return-shipping label. 2020 Enphase Energy Inc. All rights reserved. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS...
- Page 24 2020 Enphase Energy Inc. All rights reserved. 2020 Enphase Energy Inc. All rights reserved. INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK DUO BLK-G6+ / AC – Q CELLS...
- Page 25 HANWHA Q CELLS AMERICA INC. 400 Spectrum Center Drive Suite 1400 Irvine, CA 92618 +1 949 748 59 69 EMAIL inquiry@us.q-cells.com www.q-cells.us Subject to change without notice. © Q CELLS Installation manual solar modules Q.PEAK DUO BLK-G6+ _AC_2020-07_Rev02_NA...
