APPENDIX C
7 15
O 2.5
5.8 ±0.1
O 3.2 (1m)

Digital Hall Module - UF

Induced voltage moving in cable direction
2
Phase 1 (+) - Phase 2 (-)
A
1
C
0
-1
3-1
2-3
-2
0 2 4 6 8 10 12 14
MOVEMENT OF ONE POLEPITCH IN CABLE DIRECTION (mm)
3 DIGITAL OUTPUTS A,B,C:
- SINK-TYPE 20mA max.
- PERIOD 24mm (UF SERIES)
- SIGNAL DEFINITION ACCORDING TO FIGURE (HIGH=SINK)
- MAXIMUM VOLTAGE DROP 0.4V + 120 * Isink (in A)
- TYPICAL VOLTAGE DROP 0.1V + 120 * Isink (in A)
- SHORT CIRCUIT SAFE @5V SUPPLY
POWERSUPPLY
- +4.5 .. + 28V DC
- 40mA
CABLE CONNECTIONS
WHITE BROWN GREEN YELLOW GREY
0 V +4.5 .. 28V GND HALL B HALL A GND
Only one ground wire needs to be connected for proper grounding.
AP C DIGITAL HALL MODULE
Tecnotion | www.tecnotion.com | sales@tecnotion.com
B
1-2
16 18 20 22 24
PINK BLUE RED SHIELD
GND HALL C GND
