Advanced Setup - MACDEV Cyborg RX Owner's Manual

Replacing the battery
Remove all six screws holding the wrap around grip onto your grip frame.
Push the battery out of the frame by pushing the bottom right hand side of the
battery.
Place the replacement battery into the marker, NOTE: make sure you put the
bottom of the battery in first then push it onto the terminals. Only use high
quality alkaline 9V batteries, the best possible choice is to use a MacDev
Militia PowerPack (type 6LR61).

ADVANCED SETUP

About the tourney lock
The Cyborg board is equipped with a tourney lock system. When the tourney
lock system is activated, the gun cannot be reprogrammed on the field -
making it tournament legal.
Your marker has a tourney lock status indicator:
unlocked locked
When in unlocked mode, settings on the board my be changed, when in the
locked mode settings cannot be changed.
The lock status can be changed by opening the right hand side of the marker
wrap around grip to gain access to the back of your circuit board. The tourna-
ment lock is a black button. Hold the button until you see the tournament lock
status change.
Programming the Cyborg software
To program the board, first ensure that the tournament lock is off, then turn the
marker off. Hold down the trigger whilst turning the marker on. When done cor-
rectly, you will see a message on your display screen indicating that program-
ming mode is loading.
When in the programming mode, settings will be displayed ready to be adjusted.
If you would like to adjust the setting displayed, hold the trigger until the word
"Set" appears before the setting value. Press the scroll button (
the set value, and the power button (
value. When you are satisfied with the new setting, hold the trigger until the word "Set" is removed.
Push here to
remove battery
If you would like to advance to the next setting, press the scroll button. If you would like to go backwards,
press the power button.
When you are finished with the program mode, hold the power button until the display goes blank (marker
is powered down).
Each setting is described in detail below:
Fit bottom first
Debounce
then press top
The debounce setting of your marker is used to control the amount of "bounce" in your trigger. A very
down to replace
low debounce setting will result in a lot of bounce. In some tournaments or fields, it will be necessary to
reduce the amount of bounce by increasing the debounce setting. Always increase the debounce slowly,
because settings higher than 15 may result in your marker feeling unresponsive.
Contents
Know your Cyborg
Quick Setup
Using your Cyborg
Advanced Setup
Maintenance
Parts List
Troubleshooting
) to increase
) if you would like to decrease the set
