3
Example of Communication Setting
Examples of communication settings of the Display and the External Device, recommended by Digital
Electronics Corp., are shown.
3.1
Setting Example 1
Settings of GP-Pro EX
Communication Settings
To display the setting screen, select [Device/PLC Settings] from [System setting window] in workspace.
Device Setting
To display the setting screen, click
Settings] of [Device/PLC Settings].
Settings of External Device
The communication setting of the External Device is fixed.
You need not set it.
GP-Pro EX Device/PLC Connection Manual
([Setting]) of the External Device you want to set from [Device-Specific
7
SIMATIC S5 CPU Direct Driver
