Setup Items
Retry
Wait To Send
Device Setting
To display the setting screen, touch [Device/PLC Settings] from [Peripheral Equipment Settings]. Touch the
External Device you want to set from the displayed list, and touch [Device].
Setup Items
Device/PLC Name
Series
GP-Pro EX Device/PLC Connection Manual
In case of no response from the External Device, use an integer from "0 to 255" to enter
how many times the Display retransmits the command.
Use an integer from "0 to 255" to enter standby time (ms) for the Display from receiving
packets to transmitting next commands.
Select the External Device to set. Device name is a title of the External Device set with GP-
Pro EX.
(Initial value [PLC1])
Display a model of the External Device.
Setup Description
Setup Description
11
SIMATIC S5 CPU Direct Driver
