SIMATIC S5 CPU

Direct Driver

System Configuration....................................................................................................... 3

Selection of External Device ............................................................................................ 7

Example of Communication Setting ................................................................................. 8

Setup Items ...................................................................................................................... 9

Cable Diagram ............................................................................................................... 14

Supported Device........................................................................................................... 16

Device Code and Address Code.................................................................................... 17

Error Messages.............................................................................................................. 18

Siemens AG

Need help?

Do you have a question about the SIMATIC S5 CPU Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Siemens SIMATIC S5 CPU Series

Page 1: Table Of Contents
Siemens AG SIMATIC S5 CPU Direct Driver System Configuration....................... 3 Selection of External Device .................... 7 Example of Communication Setting ................. 8 Setup Items ........................9 Cable Diagram ....................... 14 Supported Device......................16 Device Code and Address Code..................17 Error Messages......................18...
Page 2 SIMATIC S5 CPU Direct Driver PREFACE This manual describes how to connect the Display and the External Device (target PLC). In this manual, the connection procedure will be described by following the below sections: System Configuration "1 System Configuration" (page 3) This section shows the types of External Devices which can be connected and SIO type.
Page 3: System Configuration
SIMATIC S5 CPU Direct Driver System Configuration The system configuration in the case when the External Device of Siemens AG and the Display are connected is shown. Setting Cable Series Name Link I/F SIO Type Example Diagram CPU 90U CPU 95U...
Page 4 SIMATIC S5 CPU Direct Driver IPC COM Port When connecting IPC with an External Device, the COM port used depends on the series and SIO type. Please refer to the IPC manual for details. Usable port Usable Port Series RS-232C RS-422/485(4 wire) RS-422/485(2 wire) COM1...
Page 5 SIMATIC S5 CPU Direct Driver When setting up communication between an External Device and the RS-232C/422/485 interface module, use the IPC (RS-232C) or PS5000 (RS-422/485) cable diagrams. However, when using PFXZPBMPR42P2 in a RS-422/485 (4-wire) configuration with no flow control, connect 7.RTS+ and 8.CTS+, and connect 6.RTS- and 9.CTS-.
Page 6 SIMATIC S5 CPU Direct Driver RS-422/485 (4 wire) DIP Switch Setting Description Reserved (always OFF) SIO type: RS-422/485 Output mode of SD (TXD) data: Always output Terminal resistance (220Ω) insertion to SD (TXD): None Terminal resistance (220Ω) insertion to RD (RXD): None Short-circuit of SDA (TXA) and RDA (RXA): Not available Short-circuit of SDB (TXB) and RDB (RXB): Not available RS (RTS) Auto control mode: Disabled...
Page 7: Selection Of External Device
Enter an integer from 1 to 4 to define the number of Devices/PLCs to connect to the display. PLCs Manufacturer Select the manufacturer of the External Device to connect. Select "Siemens AG". Select the External Device model (series) and the connection method. Select "SIMATIC S5 CPU Direct".
Page 8: Example Of Communication Setting
SIMATIC S5 CPU Direct Driver Example of Communication Setting Examples of communication settings of the Display and the External Device, recommended by Digital Electronics Corp., are shown. Setting Example 1 Settings of GP-Pro EX Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC]. Device Setting To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC] window, select the external device and click [Settings]...
Page 9: Setup Items
SIMATIC S5 CPU Direct Driver Setup Items Set communication settings of the Display with GP-Pro Ex or in offline mode of the Display. The setting of each parameter must be identical to that of External Device. "3 Example of Communication Setting" (page 8) Setup Items in GP-Pro EX Communication Settings To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC].
Page 10 SIMATIC S5 CPU Direct Driver Setup Items Setup Description You can switch RI/VCC of the 9th pin if you select RS232C for SIO type. RI/VCC It is necessary to change RI/5V by changeover switch of IPC when connect with IPC. Please refer to the manual of the IPC for more detail.
Page 11 SIMATIC S5 CPU Direct Driver Settings in Offline Mode • Refer to the Maintenance/Troubleshooting guide for information on how to enter offline mode or about the operation. Maintenance/Troubleshooting Guide "Offline Mode" • The number of the setup items to be displayed for 1 page in the offline mode depends on the Display in use.
Page 12 SIMATIC S5 CPU Direct Driver Setup Items Setup Description In case of no response from the External Device, use an integer from "0 to 255" to enter Retry how many times the Display retransmits the command. Use an integer from "0 to 255" to enter standby time (ms) for the Display from receiving Wait To Send packets to transmitting next commands.
Page 13 SIMATIC S5 CPU Direct Driver Option To display the setting screen, touch [Device/PLC Settings] from [Peripheral Equipment Settings]. Touch the External Device you want to set from the displayed list, and touch [Option]. Setup Items Setup Description You can switch RI/VCC of the 9th pin if you select RS232C for SIO type. RI/VCC It is necessary to change RI/5V by changeover switch of IPC when connect with IPC.
Page 14: Cable Diagram
SIMATIC S5 CPU Direct Driver Cable Diagram The cable diagram shown below may be different from the cable diagram recommended by Siemens AG. Please be assured there is no operational problem in applying the cable diagram shown in this manual.
Page 15 SIMATIC S5 CPU Direct Driver Display side External Device side Terminal block Shield D-sub 9 pin (plug) Signal Signal name name Display RD(RXD) RD(RXD) External Device CA6-CBLTTY/5M-01 SD(TXD) SD(TXD) ER(DTR) ER(DTR) RS(RTS) RS(RTS) CS(CTS) CS(CTS) User-created cable GP-Pro EX Device/PLC Connection Manual...
Page 16: Supported Device
SIMATIC S5 CPU Direct Driver Supported Device Range of supported device address is shown in the table below. Series 90U-115U : This address can be specified as system data area. Device Bit Address Word Address 32 bit Remarks Input Relay I000.0 - I127.7 IW000 - IW126 Output Relay...
Page 17: Device Code And Address Code
SIMATIC S5 CPU Direct Driver Device Code and Address Code Use device code and address code when you select "Device Type & Address" for the address type in data displays. Series 90U-115U Device Code Device Device Name Address Code (HEX) Value of (Data Block No.
Page 18: Error Messages
SIMATIC S5 CPU Direct Driver Error Messages Error messages are displayed on the Display screen as follows: "No. : Device Name: Error Message(Error Occurrence Area)". Each description is shown below. Item Description Error No. Name of the External Device where error occurs. Device name is a title of the External Device Name Device set with GP-Pro EX.
