- Page 1 User Manual 2.1 DOLBY ATMOS SOUNDBAR WITH WIRELESS SUBWOOFER P64172...
-
Page 2: Table Of Contents
Contents Overview ..................3 Use ....................4 Device parts ..................6 About these operating instructions ..........9 Proper use ..................11 Safety information .................12 Package contents ................15 Inserting the batteries into the remote control ......16 Mounting the Soundbar ..............16 Connecting audio devices .............19 Setting up the Soundbar ...............21 Establishing a Bluetooth connection ........... -
Page 3: Overview
Overview a u x 8 9 10 11 15 16... -
Page 4: Use
720 mm 720 mm Remove the screws Install the wall mounting screws... - Page 5 HDMI (ARC) HDMI OUT HDMI IN AV equipment...
-
Page 6: Device Parts
Device parts Device parts Connecting socket for power Indicator light cord Establish connection between Display PAIR subwoofer and speaker Fixing point for wall Subwoofer connection mounting bracket display Switch on/off OPT/COA Select audio source Select audio source TREBLE Increase/decrease treble Set volume Mute/set volume Connecting socket for po-... - Page 7 Contents Contents Overview ......................3 Use ........................4 Device parts ..................... 6 About these operating instructions ............... 9 Proper use ...................... 11 Safety information ..................12 Safely setting up the device ................12 Power supply ......................13 Handling batteries .....................14 Repair ........................15 Package contents ...................15 Inserting the batteries into the remote control ..........16 Mounting the Soundbar .................16...
- Page 8 Contents Trademark information ..................27 Disposal ......................28 Technical data ....................29 Privacy statement ..................30 Service information ..................31 Legal Notice ....................32 Warranty Details .................... 34 Repair and Refurbished Goods or Parts Notice ..........35...
-
Page 9: About These Operating Instructions
About these operating instructions About these operating instructions Thank you for choosing our product. We hope you enjoy using it. Read the safety instructions carefully before using the device for the fi rst time. Note the warnings on the device and in the operating instructions. Always keep the operating instructions close to hand. - Page 10 About these operating instructions This symbol gives you useful additional information on assembly or operation. Protection class II Electrical appliances in protection class II are electrical appliances that permanently have double and/or reinforced insulation and do not have any connection options for a protective earth. The housing of an electrical appliance in protection class II that is enclosed in insu- lated material can partially or fully act as the additional or reinforced insulation.
-
Page 11: Proper Use
Proper use Proper use The device is used for playback of audio signals. The Soundbar is intended to be connected to televisions; other devices such as port- able CD or MP3 players, computers/notebooks, smartphones and stereo systems can also be connected. The device is only intended for private use and not for industrial/ commercial use. -
Page 12: Safety Information
Safety information Safety information WARNING! Risk of injury due to improper handling. − This device is not intended to be used by people (including children) with reduced physical, sensory or mental capacity or with a lack of experience and/or knowledge unless they use the device under the supervision of a person responsible for their safety or if they have been given instructions about how to use the device safely. -
Page 13: Power Supply
Safety information − Do not place any objects on the cords because they may be damaged. − Place and operate all components on a stable, level and vibra- tion-free surface to prevent the device falling over. − All multimedia devices that are connected to the device must meet the requirements of the EU Low Voltage Directive. -
Page 14: Handling Batteries
Safety information NOTICE! In the event of a storm or if you do not intend to use the device for some time, disconnect it from the mains power supply. − When the device is not in use, switch off the power point and pull out the plug or use a master/slave power board to avoid using electricity when the device is turned off. -
Page 15: Package Contents
Package contents − Never expose the batteries to excessive heat (such as sunlight, fi re or similar). − Store batteries in a cool and dry place. Extreme direct heat can damage the batteries. Do not expose the device to extreme sources of heat. -
Page 16: Inserting The Batteries Into The Remote Control
Inserting the batteries into the remote control DANGER! Risk of choking and suffocation! There is a risk of choking and suffocation from packaging! − Keep the plastic packaging away from children. Inserting the batteries into the remote control Before using the device for the fi rst time, if the device does not respond to the remote control or does not respond well, the batteries must be replaced. -
Page 17: Option (A) Horizontal Soundbar
Mounting the Soundbar Option (A) horizontal Soundbar − Position the Soundbar and the subwoofer on a stable and level surface near power points. Ensure that the devices cannot fall down. Option (B) Soundbar mounted on the wall − First connect the Soundbar to the power cord. −... - Page 18 Mounting the Soundbar − Drill 4 holes into the wall in a parallel 720 mm line (5.5–6 mm diameter depending on the wall type). The distance between the holes must be 720 mm. − Insert wall plugs into each of the holes. Screw the wall mounting bracket fi...
-
Page 19: Connecting Audio Devices
Connecting audio devices Connecting audio devices − Follow the operating instructions for the device that you would like to connect to the Soundbar. − Switch all devices off before connecting them to one another. You can connect a number of different audio devices to this device such as MP3 and CD players, receivers, computers, televisions or even USB fl... -
Page 20: Connecting Devices Via The Optical Connection
Connecting audio devices Connecting devices via the optical connection You can connect digital amplifi ers or televisions via the OPTICAL connection. You need a digital optical cable (fi bre optic cable, not included with delivery, available in spe- cialist shops). −... -
Page 21: Setting Up The Soundbar
Setting up the Soundbar ARC not only enables audio signals to be received via HDMI when two devices are con- nected but also allows them to be sent back via the same cable. CEC (Consumer Electronics Control) enables communication with all devices connect- ed via HDMI. - Page 22 Setting up the Soundbar If manual pairing is required, proceed as follows: − Ensure that all required devices are connected. − If necessary, switch the Soundbar off by pressing the button on the remote control or on the Soundbar − Press and hold down the PAIR button on the back of the subwoofer.
-
Page 23: Establishing A Bluetooth Connection
Establishing a Bluetooth connection Setting the volume Using the +/– buttons on the Soundbar or on the remote control set the de- sired volume: + Increase volume – Decrease volume Using the button on the remote control, set the volume to mute. −... -
Page 24: Establishing A Usb Connection
Establishing a USB connection The pairing of the two devices is complete when you hear the PAIRED message and BT is shown on the display If the connection is disrupted, you hear the the DISCONNECTED message − Hold the button on the remote control down for about 3 seconds to dis- connect the current Bluetooth connection. -
Page 25: Setting Sound Effects
Setting sound effects Select the desired title using the buttons on the remote control. • Press for the next title • Press for the previous title Changing folder − Pause the audio playback using the button on the remote control. −... -
Page 26: Maintenance
Maintenance Maintenance WARNING! Risk of injury due to electric shock! − Never try to open or repair the device yourself. There is a risk of electric shock. Please contact our Service Centre if you are having technical problems with your de- vice. -
Page 27: Troubleshooting
Troubleshooting Troubleshooting − If the device malfunctions, please check fi rst whether you can fi x the problem yourself using the following troubleshooting guide. − Do not under any circumstances try to repair the device yourself. Contact our Service Centre or another suitably qualifi ed workshop if repairs are necessary. Cause Troubleshooting Connections and cable... -
Page 28: Disposal
Disposal Disposal PACKAGING The product has been packaged to protect it from damage during trans- port. The packaging is made of materials that can be recycled in an envi- ronmentally friendly manner. DEVICE Old devices must not be disposed of with normal household waste. If you can no longer use your electrical device, dispose of it in accordance with the legal provisions applicable in your country. -
Page 29: Technical Data
Technical data Technical data General data Mains connection 220–240 V ~ 50/60 Hz Connections: 1 × 3.5 mm jack audio input 1 × digital audio input (optical) 1 × digital audio input (coaxial) 1 × HDMI (ARC) with CEC 2 × HDMI Mains cable connection Supported Dolby formats: Dolby Digital, Dolby Digital Plus, Dolby... -
Page 30: Privacy Statement
Privacy statement Bluetooth® Specifi cation: V4.2, Class II Profi les: A2DP, AVRCP Max. transmission power: -8 dBm Frequency: 2402 MHz ~ 2480 MHz Range: Max. 8 m (depending on ambient conditions) Privacy statement Dear customer We wish to inform you that we, MEDION AG, Am Zehnthof 77, 45307 Essen, Germany process your personal data as a data controller. -
Page 31: Service Information
Service information Service information Please contact our Customer Service team if your device ever stops working the way you want or expect it to. There are several ways for you to contact us: • In our Service Community, you can meet other users, as well as our staff, and you can exchange your experiences and pass on your knowledge there. -
Page 32: Legal Notice
Legal Notice Legal Notice Copyright © 2020 Date: 03.01.2020 All rights reserved. These operating instructions are protected by copyright. Mechanical, electronic and any other forms of reproduction are prohibited without the written permission of the manufacturer. Copyright is owned by the distributing company: MEDION AG Am Zehnthof 77 45307 Essen... -
Page 33: Warranty Details
2.1 DOLBY ATMOS SOUNDBAR WITH WIRELESS SUBWOOFER Warranty Details REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion. -
Page 34: Repair And Refurbished Goods Or Parts Notice
2.1 DOLBY ATMOS SOUNDBAR WITH WIRELESS SUBWOOFER Repair and Refurbished Goods or Parts Notice REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION Unfortunately, from time to time, faulty products are manufactured which need to be returned to the Supplier for repair. - Page 35 Customer Service Hotline. Made in China BAUHN is a registered trademark of ALDI Stores DISTRIBUTED BY: ALDI STORES 1 SARGENTS ROAD MINCHINBURY NSW 2770 www.aldi.com.au...
