Bison FH200 Instruction Manual

—— Instruction Manual ——
It is imperative that all Portable Field Hockey Goals be used in accordance with the safety guidelines
contained in these instructions as well as those found on the safety warning labels attached to the goals.
1. Check for structural integrity and proper connection hardware before every use. Replace damaged or
missing parts or fasteners immediately.
2. Ensure safety/warning labels are clearly visible (placed under the crossbar).
3. Securely anchor or counterweight movable field hockey goals at ALL times.
4. Always instruct players, managers, coaches, trainers, teachers, maintenance and all other personnel
who might come into contact with the goal on the safe handling of and potential dangers associated
with movable field hockey goals.
5. Always exercise extreme caution when moving goals and allow adequate manpower to move goals of
varied size and weights. Movable field hockey goals should only be moved by authorized and trained
personnel.
6. NEVER allow anyone to climb on the net or goal framework.
7. Most tip over injuries occur when goals are unattended. Unless area is secure fully disassemble or
store in a place where children cannot have access to them.
♦
Inspect all contents prior to installation. Report any missing parts to dealer immediately.
♦
Read all instructions before proceeding.
P A R T S L I S T F
OR
Item Qty Description
A 2 Crossbar
B Goal Side
4
C 2 Spreader Frame
D 4 Crossbar Bracket
E 12 3/8" X 3" Hex Bolt
F 4 3/8" X 4" Hex Bolt
G 20 3/8" Hex Nut
H 20 3/8" Lock Washer
Date: 1.24.08 Rev: I.R.
FH200
Official Outdoor Field Hockey Goal
Failure to do so can cause serious injury or death.
IMPORTANT SAFETY INSTRUCTIONS!
O P G
NE AIR OF OALS
B.A. N.J.C.
Warning!
Item Qty Description
I 24 3/8" Flat Washer
J 2 Net (Packaged Separately)
K 50 Net Clips
L 2 Hook and Loop Fastening Strap (Roll)
M 4 3/8" X 4" Eyebolt
N 4 Washer Plate
O 4 Ground Anchor (Packaged Separately)
File: \pub\fh200inst
1
Customer Service
(800) 247-7668
Ref#: 840025
