a) Straighten the tab washers (see figure 1) securing the mounting bolts.
b) Remove the mounting bolts and tab washers.
c) Remove the bracket pins using a large screwdriver or pry bar.
d) Lift the topplate from the tractor. (Use extreme care whenever lifting and moving heavy
objects.)
The right to alter specifications is reserved.
REPLACEMENT PROCEDURES
Step 1: Remove Topplate
Pivot Collar
1770 Hayes Street
Grand Haven, MI 49417
www.jostinternational.com
For Outboard Slide Bracket
FIGURE 1
Ph. (616) 846-7700 (800) 253-5105
Fax (616) 846-0310
Topplate
Bracket Pin
Tab Washer
Mounting
Bolts
Page 1 of 2
LT JSK37-13 Rev.E
