Summary of Contents for jost LubeTronic 1Point
- Page 1 LubeTronic 1Point Installation and operating instructions...
- Page 3 MUB 002 017 M01 REV-- 08/2024...
-
Page 5: Table Of Contents
8 Troubleshooting............... 20 2 General information............9 Disposal................21 3 Identification..............8 3.1 Fifth wheel coupling............ 3.2 LubeTronic 1Point............8 4 Safety instructions............4.1 Safety instructions for installation....... 9 4.2 Safety instructions for maintenance......9 5 Intended use..............10 6 Installation and commissioning........11 6.1 Fifth wheel coupling............ -
Page 6: Explanation Of Symbols
Explanation of symbols WARNING! Means that death, serious physical injury or significant material damage can occur if the relevant safety instruc- tions are not followed. ATTENTION! Means that minor physical injury or material damage can occur if the relevant safety instructions are not fol- lowed. -
Page 7: General Information
The JOST LubeTronic 1Point “LT1P” is an automatic lubricating system. It is used for lubricating the specially coated low-wear- ing locking hook of JOST fifth wheel couplings. The LT1P is also used for lubricating the lifting mechanism of the JSK dual height fifth wheel. -
Page 8: Identification
LT1P. ATTENTION! Take care not to damage the type plate. If the type plate is damaged, replace it. JOST fifth wheel couplings and their components have additional installation and operating instructions. These instructions remain valid and must be observed. IMPORTANT! -
Page 9: Safety Instructions
JOST LubeTronic 1Point. You can find operating instructions of the fifth wheel coupling in particular. repair manuals at www.jost-world.com... -
Page 10: Intended Use
Intended use ATTENTION! When equipping a fifth wheel coupling with the LT1P, make sure to use suitable lifting gear to place the fifth wheel coupling on the vehicle. Lifting a fifth wheel cou- pling with LT1P using a forklift truck, for example, can cause damage to the LT1P. -
Page 11: Installation And Commissioning
Fifth wheel coupling 6.1.2 Special tools JOST fifth wheel couplings are available with pre-installed LT1P. The LT1P is suitable for retrofitting on low-maintenance fifth wheel couplings of types JSK 34 W, JSK 37 W, JSK 40 W and JSK 42 W. -
Page 12: Installing The Lubricant Dispenser
Only use the template (1) appropriate for the type of fifth wheel coupling. JSK. This can be found at 3. Drill the holes at the drilling points (2) with a Ø 5 mm spiral www.jost-world.com . drill bit. 4. Cut an M6 thread. 5. Fit the left-hand liner. -
Page 13: Coating
LubeTronic is not directly exposed to the rays. Avoid continuous heating of the LubeTronic at over 80 °C. 6.1.5 Replacing the locking hook Follow the instructions in the repair manual of the JOST fifth wheel coupling. After the locking hook has been replaced, the Holder Button head screws locking mechanism needs to be readjusted. -
Page 14: Connecting The Lubricant Dispenser
Installation and commissioning 6.1.6 Connecting the lubricant dispenser Hose Connection piece Locking hook Holder Lubricant dispenser Clamp 1. Remove the protective cap from the hose (1) of the lubricant dispenser (3). 2. Connect the hose (1) of the lubricant dispenser (3) to the con- nection piece (4) of the locking hook (2), making sure it is con- nected properly. -
Page 15: Setting The Lubrication Interval
Installation and commissioning 6.1.7 Setting the lubrication interval 1. Take the unit out of the holder. 2. Move the switch to the ‘OFF’ position (red LED lights up for 2 seconds as confirmation). ADVICE! 3. Unscrew the cartridge as described in Chapter 7.4, "Replacing The dispensing interval of the LT1P is set as standard for the cartridge". -
Page 16: Putting The Lubricant Dispenser Into Operation
LT1P for lubricating the stay arm. It is put into operation as described in section 6.1.8 "Putting the lubricant dispenser into operation". Pay attention to the repair manual of the JOST JSK DH during instal- lation and removal. ADVICE! If an old lubrication unit (with metal housing) is fitted, all hoses must be replaced when converting to a unit with replaceable plastic cartridge filled with JHS202B. -
Page 17: Maintenance
The service life of the LT1P is factory-set to that of the locking hook Unit Cover and the wearing part, for use in JOST fifth wheel couplings. There- fore, the locking hook and wearing part should be replaced at the 1. Press the handle to open the clamp (1). -
Page 18: Replacing The Cartridge
Maintenance Replacing the cartridge ADVICE! 1. Remove the unit as per the instructions. IMPORTANT! Effective lubrication of the locking mecha- 2. Move the switch to the ‘OFF’ position. nism is vital for its service life. If the cartridge is replaced 3. -
Page 19: Replacing The Battery
Maintenance Replacing the battery Battery Plug connection Drive unit 1. Remove the battery (1). 2. Detach the plug connection (2). 1. Remove the unit as per the instructions. 3. Re-install the battery in reverse order to the above. 2. Move the switch to the ‘OFF’ position. 4. -
Page 20: Troubleshooting
Troubleshooting No. Problem Cause Remedy 5.0 The red LED Malfunction Switch the LT1P flashes off and on again. 1.0 The activated The lubricant line Check whether twice every 10 If the error is still lubricant dis- is damaged or lubricant line seconds. -
Page 21: 9 Disposal
Disposal Your product is made of high-quality materials and components that can be recycled and reused. If this product bears the adjacent symbol of a crossed-out wheelie bin, this means that it is covered by European Directive 2002/96/EC. Please find out about your local collection points for electrical and electronic products and appliances. - Page 24 Member of JOST World JOST, Germany, Tel. +49 6102 295-0, tkd-technik@jost-world.com, www.jost-world.com MUB 002 017 M01 REV-- 08/2024 • 1.0...
