Seresco NP Series Operation And Maintenance Manual

Indoor/outdoor model

Advertisement

OPERATION AND
MAINTENANCE MANUAL
NP SERIES
DEHUMIDIFIERS
NP-018 to NE-128
Indoor/Outdoor Model
serescodehumidifiers.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NP Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Seresco NP Series

  • Page 1 OPERATION AND MAINTENANCE MANUAL NP SERIES DEHUMIDIFIERS NP-018 to NE-128 Indoor/Outdoor Model serescodehumidifiers.com...
  • Page 2: Table Of Contents

      B –Table of Content        Table of Content      Chapter C ‐ General Information   C – 1   C – 1    Operating Safety  C – 2    Reference and Additional Information   Contact Us C – 2   C – 3    Basic Information Dehumidifier View and Options  C – 3    Dehumidifier External Systems Connection C – 5  Dehumidifier Optional Arrangement  C – 5  Air Conditioning Options – Outdoor Air Fluid Coolers  C – 6    Equipment Specific Data C – 8  Chapter D ‐ Layout and Components   D – 1   D – 1 ...
  • Page 3   B –Table of Content                This page is left blank              B‐    ...
  • Page 4: Chapter C - General Information

    C – General Information  General Information  This manual provides basic information about the applicable Seresco dehumidifier and its operation.   Important information regarding installation, maintenance, and start up as well as additional and auxiliary systems  and devices (outdoor condenser, communication interfaces, etc.) is normally provided with the dehumidifier and  can also be obtained from the manufacturer (see Contact Us below).  Operating Safety (Warnings, Cautions, and Notes)    FOR YOUR SAFETY: READ BEFORE PERFORMING ANY OPERATIONS, MAINTENANCE OR SERVICE TASKS!    Only qualified technicians should install, operate, maintain or service mechanical equipment  including current dehumidification system.    Make sure to read this manual before performing any tasks to familiarize yourself with the  equipment as well as with any potential hazards. Always exercise caution!    Beware of electrical power and high electrical voltage! • Follow proper safety procedures – lockout, tagout, and other respective procedures • Failure to follow safety procedures can result in serious injury or death       Beware of moving parts and hot surfaces! • Make sure to stop all moving parts (fans, blowers, etc.) before accessing the equipment’s  internal space • Be aware of hot surfaces (hot refrigeration, space heating pipes, coils, heaters, etc.)       Beware of high pressures and chemicals! • Dehumidifiers, equipped with compressors, contain refrigerant under high pressure; oil is  also contained in the compressor and refrigeration circuit(s) • Some dehumidifiers may also contain other liquids such as glycol mixtures and pool water    ...
  • Page 5: Reference And Additional Information C

        Attention: Maintenance Team   CAUTION.  To ensure equipment longevity and proper and efficient operation, the dehumidifier and its  auxiliary systems and devices (outdoor condenser, fluid cooler, boiler package, etc.) should be maintained  properly and regularly. Failure to do so could negatively affect premise comfort levels and people’s health. It  could also lead to equipment damage, malfunction, premature tear and ware and may void equipment warranty.      Contact Us      For immediate assistance: 1‐833‐DAS‐POOL (327‐7665)  Seresco     1071 Ages Drive   Start‐up Requests:  Start‐ups@dehumidifiedairservices.com  Ottawa, ON K1G 6L3  Miscellaneous Inquiries:  Support@dehumidifiedairservices.com  Canada  Parts Requests:    Parts@dehumidifiedairservices.com  http://serescodehumidifiers.com  Warranty:    Warranty@dehumidifiedairservices.com         ...
  • Page 6: Basic Information

    C – General Information  Basic Information   Dehumidifier View and Options    Pic. C.1   C‐   February   OMM.C.S.AA.01  2020...
  • Page 7 C – General Information  Standard NP series dehumidifiers are semi‐custom: while basic concept and layout is the same, options and  specific systems and components layout and location may vary from one dehumidifier to another. One of the  typical dehumidifier arrangement is shown on Pic.C.1.    Dehumidifier Options     Indoor or outdoor installation.  Note: Pic. C.1. shows outdoor model, equipped with louvers (to protect air intake and discharge  openings from elements). Indoor model would have ducts connected to respective openings, no  louvers would be needed.   Capacity (number of compressors) – two to four compressors (see Dehumidifier Optional Arrangement below  for more details):  Two‐compressor dehumidifier option (18 to 80 tons, models NP018 to NP080).  Three‐compressor dehumidifier option (90 to 100 tons, models NP090 to NP100).  Four‐compressor dehumidifier option (128 tons, model NP128).   Airflow/ductwork connection *. Pic. C.1 shows some options only; each option location availability depends on  the dehumidifier installation (indoor or outdoor) and other options:  Return Air (RA) ductwork connection ‐  top, bottom, end, sides.  Supply Air (SA) ductwork connection – top, bottom, sides.   Optional Min Outdoor Air (OA) ductwork connection/termination – top, sides.  Optional Min Exhaust Fan (EF) and Purge Fan (PF) ductwork connections/terminations – end, sides.  Optional Purge Outdoor Air (POA) ductwork connection/termination ‐ top, sides.    Optional Pool Water Heating **.  Dehumidifier can accommodate up to two pool water heating circuits   Optional Space Heating ‐ hot water coil, electric or gas heater ***.   Optional Heat Recovery (HR) circuit.   Air Conditioning (AC)* – external water cooling or fluid cooler (packaged or separate).  Note: Pic. C.1 shows outdoor model with “packaged” fluid cooler (mounted with the dehumidifier).  “Packaged’ AC option is available for outdoor models only; alternatively, indoor and outdoor models  could be fitted for separate/remote AC option – remote fluid cooler or other external cooling media  source.       *  Some available options (tonnage, ductwork connections, AC options etc.) are shown. Refer to the submittal ...
  • Page 8: Dehumidifier External Systems Connection C

    C – General Information    Dehumidifier External Systems Connection Pic. C.1 shows provisions for external systems connections, including ductwork, electric power and control wires  and various piping connections.   CAUTION!  Current manual shows general/default connections’ location. For details regarding specific  dehumidifier’s connections (actual location, piping sizes and position dimensions, circuit type and flow direction  etc.), refer to the dehumidifier’s submittal documentation as well as dehumidifier’s labels and stickers.    Except for the condensate, all other piping systems are optional and may not be present in each  dehumidifier   Condensate Drain Line – bottom, side (through the dehumidifier base).   NOTE.  Dehumidifier MUST be equipped with a P‐trap at the condensate connection for proper operation! If  dehumidifier is requested from the factory without P‐trap, one MUST be installed on site prior to dehumidifier  being commissioned. Refer to the Installation Manual for details.    Air Conditioning (AC) Connection.   Packaged AC option (outdoor dehumidifier with outdoor fluid cooler (OAFC) incorporated with the  dehumidifier), does not require piping connection to external AC system or device.    Pic 1.C. shows packaged outdoor model with OAFC mounted at the end of the dehumidifier;  alternatively, if requested, OAFC could be mounted on the roof of the dehumidifier.   Remote (“split”) AC option (indoor or outdoor dehumidifier, connected to external cooled  water/glycol system or remote fluid cooler) – side or end (through the compressor compartment  wall) connection.   Pool Water Heating – bottom, side.   Space heating (Hot Water connection) – bottom, side.  Some connection location options for both, pool and space, heating pipe lines, are limited to indoor  installation only – refer to submittal documentation   Space Heating (Gas Heater connection, gas line). If the dehumidifier is equipped with a gas heater (boiler, gas  furnace etc.) for space heating purposes, the gas line connection is to be brought to the gas heater directly.  WARNING!  Gas Line. The gas line must be installed in accordance with respective device documentation  (boiler, furnace, etc.) and local codes and regulations.   ...
  • Page 9 C – General Information  For two‐compressor dehumidifier, compressor compartment may have side (Fig.1; same as dehumidifier, shown  on Pic. C.1) or end (Fig.2) location. End location is mostly used in higher capacity dehumidifiers.  Three‐ and four‐compressor dehumidifiers (Fig.3 and Fig.4, respectively) normally have end location of the  compressor compartment.      Pic. C.2 Air Conditioning Options – Outdoor Air Fluid Coolers (OAFC).    Basic views of standard air conditioning options are shown on Pic.C.4 (below); standard combinations of the  dehumidifier and respective fluid cooler (based on their capacities) are shown in Table C.1. Note, that depending  on number of factors, dehumidifier may have different cooler provided with it ‐ refer to the dehumidifier’s  submittal documentation for more details.  Table C.1  Standard fluid coolers used with this model of dehumidifier is NG‐V series,  Dehumidifier  Fluid Cooler  composed of number of “two‐coils‐two‐fans” blocks, based on required  NP018 – NP024  NG‐V‐12  capacity of the cooler:   NP018 – NP045  NG‐V‐22  NP036 – NP070  NG‐V‐32   Fluid cooler NG‐V‐12 (Pic.C.4, Fig.1) is composed of one such block;  NP064 – NP100  NG‐V‐42  NG‐V‐22 (Fig.2) composed of two such blocks etc. largest single  NP080 – NP128  NG‐V‐52  fluid cooler, NG‐V‐62 (Fig.3) composed of six of them.  NP090 – NP128  NG‐V‐62  NP090 – NP100  2*NG‐V‐32  As an option, each block of fluid cooler could be equipped with the pump  NP100 – NP128  2*NG‐V‐42 ...
  • Page 10 C – General Information  Attention! Equipment Clearances!  Proper clearances should be maintained for adequate airflow and heat rejection! Generally, up to 36” side and  96” top clearances are required. For more information on clearances as well as equipment dimensions and other  details, refer to the submittal documentation.    Pic. C.4      C‐   February   OMM.C.S.AA.01  2020...
  • Page 11: Equipment Specific Data C

    C – General Information  Equipment Specific Data   Specific information for individual dehumidifiers is    provided in the following methods:     Main Label (Pic. C.5): the manufacturer tag attached  to the front of the dehumidifier includes the  dehumidifier’s most critical data:   General data including:  Serial number   Dehumidifier model (nomenclature)  Design room conditions (air temperature  and humidity)   Operational data, including:  Refrigeration (refrigerant type, charge,  etc.)  Electrical/airflow (dehumidifier voltage,  CFM, etc.)  Other applicable data (pool heating,  space/auxiliary heating features, etc.)    Labels and Stickers: attached when applicable to the  exterior and interior of the dehumidifier to show:   External systems connections location/direction   (pool/space heating, cooling circuits, condensate)   Air filter locations, quantity, and size.    Pic. C.5  Additional Info (warning, caution stickers, etc.)      Wiring Diagrams: attached to the interior side of the  Note:  The main label shown above is just an example. ...
  • Page 12: Chapter D - Layout And Components

      D – Layout and Components  Layout and Components  The general layout and components location is the same for all dehumidifiers of current type, however some may  vary, based on the dehumidifier’s specific options – refer to submittal documentation. Pic. D.1 below shows  all/most available options, some of which may not be present on your dehumidifier.  Dehumidifier Main Components     Main Blower (1) is in the main blower compartment behind or next to the Compressor Compartment (3) with  Main Electric Panel (2). Based on airflow requirements, number of main blowers may vary (up to four).  Two blowers could be installed either side by side or stacked on a top of each other (Pic. D.1A); four  blowers’ arrangement would have two stacks, shown on Pic. 1.DA, installed side by side.   Min Outdoor Air (OA) Opening (4) has a motorized damper and filter(s). The Manual OA Damper (5) is usually  used to set proper amount of outdoor air intake; in some cases, it could be equipped with modulating  actuator for automatic adjustment of outdoor air intake.  Outdoor‐installed dehumidifier would have louver(s) (76) installed at the OA opening.   Min Exhaust Fan(s) (EF) Assembly (6) (fan and motorized damper) is located on the dehumidifier’s return air  side; Exhaust Air opening in outdoor‐installed dehumidifier is equipped with louver(s) (76) also.  Min Exhaust Fan Assembly is hinged and could be opened for better access to the fan electric box.   Dehumidifier, equipped with Heat Recovery (HR) option, would have HR glycol coils (71), installed at the Min  Exhaust (EF) and Min Outdoor Air (OA) openings, and HR pump (72), installed in return air compartment.  If HR option is present, Min Exhaust Fan Assembly would normally be equipped with a filter rack.   If dehumidifier is equipped with Purge option, additional Purge‐exhaust fan(s) (PF) (73) with motorized  damper would be installed on dehumidifier’s return air side, as well as additional (“Purge”) Outdoor Air (POA)  (74) opening(s), equipped with motorized dampers, would be located directly upstream of Main Filter Rack  (9). Motorized Return Air (RA) damper (75) would be located between return air side and POA opening(s).  Outdoor‐ installed dehumidifier would have louvers (76) installed at the Purge‐exhaust fan and Purge  Outdoor Air openings.   Refrigeration Evaporator coils (7) and water/glycol Reheat coils (8) are located directly downstream of the  Main Filter Rack (9).   Motorized Evaporator Bypass Damper (10) is  located next to the evaporator coils; it by‐passes  portion of air around evaporator, thus adjusting  compressor circuit operation. Some dehumidifiers,  based on airflow requirement, could be equipped ...
  • Page 13   D – Layout and Components        11b  2    24    3              1        4    5      22          71      11a        76  10   ...
  • Page 14   D – Layout and Components  Compressor Compartment and Main Electric Panel (detailed; see Pic.D.1C).  15  17  25, 26  18  80  78  79  27  14  77  28  13  13    Pic. D.1C 16a  16     Compressor(s) (13), Receiver(s) (14) and other components are located within the Compressor Compartment  (3):  Each compressor circuit has glycol‐to‐refrigerant plate heat exchanger (16) and, common to both  circuits, glycol pump (16a), that circulates water/glycol to reject compressor‐generated heat.   Motorized water/glycol Reheat (79) and AC (80) valves’ opening position determines how much fluid  is diverted to respective coil(s) (reheat and fluid cooler or external heat sink).    If the dehumidifier has the standard pool water heating option, the compressor circuit additionally  includes the coaxial pool water heat exchangers (15) and refrigeration pool water heating solenoid  valves. Number of pool water heat exchanger varies based on dehumidifier type and capacity.  Control sub‐panel with Main Control  Board (17) and Operator Panel (18) is  normally mounted on the compressor  stand frame.   Main Electric Panel (2) contains main  blower(s) VFD (variable frequency drive)  (78), main Disconnect (77), if one is  installed, and other electrical and control  components (contactors, fuses, control ...
  • Page 15: Control System D

      D – Layout and Components    Control System  The dehumidifier control system is composed of sensors, spread throughout the dehumidifier, Main Control  Board, Operator Panel and other electric components, located in the Main Electric Panel.   Temperature Sensors (Pic. D.2):   b  a) Temperature sensors (thermistors) are used to monitor  various temperatures (air, water, compressor, etc.);  Combo sensor is used to monitor air temperature and  humidity.        d  a    Pic. D.2   Compressor operation is monitored with pressure sensors (Pic. D.3):       Pressure Transducers (as main operational control and safety) and      Pressure Switches (fast‐reacting backup safety).     c  Note.  Sensors and safeties approximate location is shown on Pic. D.1B and    Pic.D.3 D.1C – refer as needed.   RA Combo Sensor (21) measures temperature and humidity of the pool room air (Return Air) entering the  dehumidifier. It is located at the return air ductwork connection to the dehumidifier.   OA Temperature Sensor (22) measures outdoor air temperature; it’s located at the OA filter rack.  As an option, the combo sensor (instead of regular thermistor) can be installed at the OA intake to ...
  • Page 16: Outdoor Air Fluid Cooler Layout And Components D

      D – Layout and Components  Outdoor Air Fluid Coolers Layout and Components .  The general layout of AC options (air‐and water‐cooled) is shown on Pic.D.5 below with the outdoor fluid cooler  NG‐V‐12, equipped with additional pump package (Fig.1) and NG‐V‐32 (Fig.2) as an example. While layout and  main components are similar for all applicable AC options, there are some deviations (number of fans,  composition, etc.). Refer to AC Options Basic View (Basic Information chapter) for additional information.    32  33  35  31  33  36  37  31      Pic. D.5    Cooling (AC) coils (31) (where heat from glycol mixture is rejected to the ambient air) is mounted onto metal  frame, upstream (before) the fans (32), that pulls the air through the coils to absorb the heat.  Normally, fluid cooler would have multiple coils and fans. Cooler NG‐V‐12 (Fig.1), comprised of two  coils, mounted on the angle to each other, and two fans, presents a single block. Depending on the  capacity, cooler could be comprised of up to six such single blocks, stacked side by side on the same  frame and manifolded together – NG‐V‐32 is comprised of three such blocks.   Cooler piping connections (33) are identified respectively (IN – OUT);  In some cases, fluid cooler piping connection(s) may be located within pump package box (37), if fluid  cooler is provided with one.  Piping connection location may vary – refer to particular cooler labels, stickers, submittal and other  documentation.   Electric power is normally to be brought to disconnect (35) (if cooler is equipped with such), which feeds it to  the electrical box (36), that contains cooler power and control apparatuses.  Depending on fluid cooler specifics, location of electrical box may slightly differ; in some cases,  electrical box may be incorporated into pump package or located on the opposite side of the fluid  cooler.   ...
  • Page 17   D – Layout and Components    Fluid Coolers Pump Package.  Fluid Coolers, if equipped with such option, would have a pump package box. Pic.D.6 below shows general layout  of pump packages, used for NG‐V model fluid coolers. Note, that the package could be mounted onto the fluid  cooler directly (standard) or provided separately.       Pump (38) establishes glycol mixture circulation through  the fluid cooler and dehumidifier;   38  Expansion tank (39) compensates for temperature‐ based glycol volume fluctuation;   The pump package electrical sub‐panel (40) contains the  pump package electrical power and control apparatuses.   The pump package manifolds are usually equipped with  pressure gauges, automatic air venting valve, draining  and other valves.    40      39        Pic. D.6       D‐    ...
  • Page 18: Chapter E - Sequence Of Operation

      E – Sequence of Operation  Sequence of Operation  The dehumidifier’s ventilation system establishes the required airflow through the dehumidifier. The control  system compares air temperature and humidity to their desired values (set points) and proceeds to dehumidify,  cool or heat the recirculating air.  If the dehumidifier is equipped with the pool water heating option, the pool water temperature is compared to its  set point and pool heating is provided if required.  Set Points  The control system is constantly adjusting unit operation to achieve and maintain said parameters within couple  degrees/percent of the set point.  Refer to the dehumidifier’s main label for the design value of control parameters, as well as the following note.    Note:  To ensure the dehumidifier’s most economical operation, we recommend maintaining the following  relationship between pool water and room air temperatures:   Room Air T = Pool Water T + 2˚F    Ventilation.  The main blower runs continuously, establishing required. The main blower speed is pre‐set via adjustable variable  signal.  Minimum Exhaust Fan (EF), if dehumidifier is equipped with such option, directs portion of return air outdoors.  Like main blower, exhaust fan(s) speed is also controlled via adjustable (pre‐set) variable signal, that varies based  on scheduled ventilation mode (Occupied, Non‐Occupied and Spectator) or call for Economiser Mode (as part of  Air Conditioning and/or Dehumidification operation).  Minimum Outdoor Air (OA) damper, if dehumidifier is equipped with such option, opens to introduce fresh  outdoor air into the premise. OA damper could be equipped with ON/OFF (simple fully open – fully closed) or  modulating‐controlled actuator; latter one would be controlled same way as minimum exhaust fan.  Purge (Additional Exhaust) Option.   Along with Min Exhaust Fan and Min Outdoor Air damper, dehumidifier could have additional set of exhaust  (purge) fan(s) (PF) and purge outdoor air damper (POA), commonly referred as Purge. Purge fan(s) and OA  damper(s) function is to allow for higher exhaust and fresh air amount, up to complete (100%) air changeover  (when all exhaust fans and OA dampers are at their max capacities).   Purge Fan(s) and Purge Outdoor Air damper(s) are controlled in the same fashion as min exhaust fans and min  outdoor air. Some dehumidifiers may be equipped with additional Return Air damper: it closes in event of  complete air changeover, separating return air side of dehumidifier from supply side (refer to Layout and  Components chapter, as needed, for respective devices’ location).  Complete air changeover, triggered manually, is known as Purge Mode.    Note. Externally installed Exhaust Fan(s) and Outdoor Air damper(s) could be also controlled by the ...
  • Page 19: Heat Recovery Option E

      E – Sequence of Operation  Heat Recovery Option.   Dehumidifiers, packaged with Minimum Exhaust Fan and Minimum Outdoor Air damper, could also have  additional Heat Recovery (HR) closed‐loop glycol system.    Heat Recovery loop (see Pic. E.1 below) consists of two coils (air‐to‐glycol heat exchangers) and a pump,  establishing glycol circulation between them. One coil, installed at exhaust air opening, recovers portion of  exhausted air energy, another coil, installed at outdoor air intake, transfers this captured energy to entering  outdoor air.         Pic. E.1 Space Heating  When premise air temperature drops below the set point, the dehumidifier control system issues a call for Space  Heating Mode and engages space heater (electric heater, hot water coil with valve, gas boiler etc.) by sending space  heating signal, respective to space heater control type ‐ on/off, variable (0‐10VDC), etc.     Air Conditioning, Dehumidification and Pool Heating.  When premise air temperature goes over (exceeds) its set point, the dehumidifier control system issues a call for  Air Conditioning Mode. Respectively, when premise air humidity goes over (exceeds) its set point, the dehumidifier  control system issues a call for Dehumidification Mode. In some instances, these calls may co‐exist.    To execute Dehumidification or Air Conditioning (Cooling) mode, control system, depending on current conditions,  would resort to available means of cooling or dehumidification.    Economiser Mode Option.    Note. Economiser Mode requires dehumidifier to be equipped with full (min and additional) exhaust and  outdoor air options!   If outdoor air is dry and/or cool, it could be used to dehumidify and/or cool the premise. In this case, on call for  Dehumidification or Air Conditioning mode(s), control system would simply increase exhaust fan(s) speed signal to  direct more stale return air outside and bring in more outdoor (dry/cool) air in, thus reducing supply air humidity  and/or temperature (as needed).     E‐    ...
  • Page 20   E – Sequence of Operation  Compressor(s)   Whenever the compressor operates, the evaporator is always dehumidifying and cooling the return air. The heat  removed from the air at the evaporator, as well as the heat from the compressor's action, must be rejected to one  of three heat sinks: room (premise) air, pool water (if applicable) or outdoors. The control system will direct the  heat to where it is needed based on room (air and pool water temperature) conditions:   If room air is needed to be warmed up – more heat is diverted towards reheat coil;   If pool water is needed to be warmed up – more heat is diverted towards pool heating coaxial heat exchanger  (if dehumidifier is equipped with this option).   Rest of the heat (if any) is diverted towards outdoors (outdoor fluid cooler, external heat sinks etc.)    Compressor Circuit Operation  Piping schematic for compressor circuit is shown on Pic. E.2.   Schematic shows single compressor circuit (second compressor circuit schematic is the same) and common to  both compressor circuits’ glycol cooling circuit.   Circuit operation below applies to both compressors; compressors are staged – if first compressor’s capacity is  not enough to satisfy the call, second compressor will be engaged after certain time delay.    When a demand requires the compressor to operate, the following sequence occurs:    Once blower operation, related safeties and timers are confirmed by the control system, following occurs:  Compressor glycol pump starts, establishing cooling glycol/water flow through the compressor fluid  circuit ‐ plate heat exchanger(s) and fluid cooling coils (reheat and/or fluid cooler or external cooling  source).  Pump down solenoid valve opens and once pressure stabilizes, the compressor starts.   Based on the premise air temperature, the Reheat and AC valves would adjust their opening position (open  more/close more), reducing or increasing fluid flow to and through the respective fluid coils:   Reheat and AC valves are controlled in the same manner with opposite effect: for example,  when AC valve opens 10% more, Reheat valve closes 10% more etc.   if more heat is required by the room air, the Reheat valve opens more, and AC valve closes more, thus  diverting more fluid to the reheat coils (heat is rejected to the premise);   if more cooling is required by the room air, the AC valve opens more, and Reheat valve closes more, ...
  • Page 21   E – Sequence of Operation      Pic. E.2          E‐    ...
  • Page 22: Chapter F - Interface And Communication

      F – Interface and Communication  Interface and Communication  Touch Display Operator Panel   The Touch Display Operator Panel (OP), shown on Pic. F.1, is used as a main interface between the dehumidifier  and operator. The same OP can be located in the dehumidifier main electric panel (default; used as a local OP) or  installed remotely from the dehumidifier    NOTE: length of CAT5 or CAT6 cable, between remote OP and the dehumidifier MUST NOT exceed 1000’!   Touch Display OP allows to:     Access Touch Display Menus  View dehumidifier current operational  statuses (Touch Display Communication,  Alarms, dehumidifier operational calls, etc.)  View controlled parameters’ values (premise  air temperature, humidity and, if applicable,  pool water temperature) and current date  and time.    Pic. F.1   Touch Display Menus:   Home  Opens/returns to the home page  Logs  Access to dehumidifier logs and log‐related features (Alarms, etc.)  User  Access to user settings (Setpoints) and commands (Stop/Restart Dehumidifier, etc.)  Advanced  Access to advanced settings and features  Help  Context sensitive help presenting information related to the viewed page  Most common/basic maintenance tasks performed using Touch Display OP   Adjust Setpoint – in User menu: press the User button, then press the Setpoints button; select desired  parameter (room air temperature etc.) and enter the desired value. Press the Enter button to confirm the  entered value.   Stop/Restart Dehumidifier –– in User menu: press the User button, then press the System Restart button;  To stop and restart dehumidifier, press the System Restart button ...
  • Page 23: Alarms F

      F – Interface and Communication    Alarms   If the dehumidifier control system detects abnormal or unsafe for further operation situation, it issues Alarm  (notification of such situation accompanied by respective component or entire dehumidifier stoppage and/or  lockout) or Alert (notification of minor abnormal situation without any devices’ stoppage or lockout).  All alarms and alerts are recorded and can be viewed/cleared via the Touch Display OP:    Viewed: to facilitate troubleshooting and addressing abnormal situation   Cleared: to unlock stopped device or entire dehumidifier and allow for further operation  The table F.1 below lists the basic alarms with their descriptions and recommended initial troubleshooting.   Table F.1. Most Common Alarms/Alerts  Alarm  Alarm Description  Check  No Air  No air flow (air flow switch fault – if air flow  Check main blower operation and air flow  switch is installed)  switch  Blower OL  Main Blower overload/safety fault   Check main blower operation and its LED  light blinking pattern.  Fire  Fire/smoke detector fault – if detector is installed  Check external fire/smoke  externally and connected to control board  detector/system  Freeze  Supply Air temperature is lower than Freezestat  Check SA temperature readout, space  Setting (default: 45 F)  heating system operation  Filter  Alert, indicating that filter change timer has  Clear the Filter alarm and cancel filter  lapsed – if timer is activated  scheduler if not in use. ...
  • Page 24: Remote Communication

      F – Interface and Communication  Remote Communication     Although dehumidifier is designed to operate as a self‐controlled device (not requiring any external control),    communication between the dehumidifier and external control and monitoring systems is possible. WebSentry  WebSentry is an online tool (also referred to as Web Monitor), that allows for remote communication to the  dehumidifier for various purposes such as monitoring, data collection, parameters adjustment, and notifications.  This feature is included with all dehumidifiers and is useful for maintenance teams and service providers (HVACR  technicians).  To establish Web Monitor communication, the dehumidifier must communicate with the factory server via the  Internet:  ‐ Connect the dehumidifier to a local network switch, router or wireless AP device (providing connection to a  local network):  Plug an Ethernet cable into the sub‐board Ethernet RJ‐45 jack (sub‐board, called Core Module, is  located on the main control board in the main electric panel) – see Pic. F.2.    Note: separate RJ‐45 jack (plastic, black) is mounted on the control board directly, for  TouchDisplay connection. Make sure to use the proper jack (metal‐surface one, located on  the sub‐board) for Web Monitor connection.  ‐ Configure, as needed, local server and dehumidifier network settings.    BMS (Building Management System)  Communication to BMS can also be supported, depending on the  type of communication protocol said BMS utilizes.   The equipment control software supports most common of them   ‐ different control software variation might be required to  support different BMS communication protocols. Contact  factory if necessary.    BACnet (Internet, IP). Communication is established via the  Ethernet cable (same method as Web Monitor).   BACnet and Web Monitor communication can be used  simultaneously.    ...
  • Page 25   F – Interface and Communication            This page is left blank              F‐    ...
  • Page 26: Chapter M - Basic Maintenance

      M – Basic Maintenance  Basic Maintenance   Although Seresco equipment is built for minimal service downtime, periodic preventative maintenance is required  to ensure maximum reliability, safety, and operating efficiency.    WARNING!  To ensure equipment longevity and proper and efficient operation, the dehumidifier and its  auxiliary systems and devices (outdoor condenser, fluid cooler, boiler package, etc.) must be maintained properly  and regularly. It is recommended to create a facility‐specific Routine Maintenance Program.   Failure to maintain the equipment properly and regularly could result in personal injury, equipment damage or  malfunction and will void the equipment warranty.  Maintenance and Safety  Only qualified/properly trained personnel should attempt to perform respective maintenance tasks.    When it is necessary to work with live electrical components, have a licensed electrician or other qualified  professional perform the required task.    Be properly trained and equipped. Some maintenance tasks may involve usage of power tools, chemicals, etc.  Refer to such tools and materials data (manuals, MSDS, etc.). Personnel performing such maintenance tasks  should be:  Properly trained to handle such tools and materials safely  Equipped with proper personal protective equipment   Turn the power off. Before performing any maintenance, disconnect all electrical power, including remote  disconnect, and discharge all energy storing devices (VFDs, etc.) before servicing. Follow proper lockout  procedures to ensure that power cannot be accidentally restored. Failure to follow provided safety warnings  and labels could result in serious injury or death.   Be aware of potential hazards. The equipment contains moving mechanical parts, components under high  refrigerant pressures and surfaces with high temperatures. Before entering the dehumidifier and/or  performing any equipment maintenance work, make sure that all moving parts are stopped, and it is safe to  perform required task.    Maintenance Key Points  Here are some basic/key maintenance considerations, pertinent to all dehumidifiers and their auxiliary systems:   Dehumidifier in mechanical room. No chemicals should be stored in the same mechanical room where the  dehumidifier is installed. Chemical fumes/off‐gas can cause premature deterioration of the equipment.  Store chemicals in a separate, well‐ventilated room.  ...
  • Page 27: Routine Maintenance Program M

      M – Basic Maintenance     Pool Water Chemistry. Incorrect pool water chemistry (improper pH level or high concentration of chlorine,  sea salt or other corrosive additives etc.) can result in equipment premature wear or malfunction (let alone  poor air quality in the pool and potential health issues) and will void the equipment warranty. Refer to pool  water quality standards; contact factory as needed.    Routine Maintenance Program  Creating facility‐specific routine maintenance program and following it is vital to equipment longevity and efficient  operation.  The suggested general maintenance operations and their frequency/intervals, listed in the table M‐1 below, can be  used to create such a program. For more detailed maintenance recommendations related to specific components,  refer to the respective component manufacturer’s manual.    Table M.1.  Recommended Maintenance Tasks and Intervals  Interval  Maintenance Task  Weekly  Observe the equipment for any changes in running conditions and unusual noise  Clean or replace air filters if clogged or dirty  Quarterly  Verify that all set‐points are correctly programmed as specified by the facility operator  Inspect and clean the drain pan(s)  Tighten electrical connections, if required  Check and tighten, if required, pool water hose clamps and sensor mounts  Inspect all airside coils (outdoor condenser, fluid cooler, dehumidifier coils – evaporator, etc.) for  Semi‐ dirt, cobweb build‐up, etc.; clean as needed  Annually  Check that the P‐trap is primed (filled with water). It is good practice to pour some water into the  drain pan to ensure that the P‐trap is primed and operational  Check the outdoor air louvres and dampers for accumulation of dust and clean as required  Inspect the equipment’s cabinet for corrosion. If any damage is found, clean and repaint the  affected surface with a rust‐resistant primer  Clean the fan wheel(s)  Check dampers operation (linkage/actuator is not loose, damper opens/closes properly etc.)  Inspect electrical components, wiring and insulation  Annually  Rotate the fan wheel(s) and check for obstructions and rubbing ...
  • Page 28: Specific Components Maintenance M

      M – Basic Maintenance  Specific Components Maintenance  Actual maintenance plan may vary from installation to installation, yet there are several key components from  maintenance prospective.  If needed, contact respective component manufacturer for additional maintenance information.    Filters   Ensure air filters are clean. Dirty air filters will negatively affect dehumidifier performance and lifetime   Frequency of filters replacement will vary based on air quality, dehumidifier usage, facility type, etc. Make  sure to replace filters regularly   Replace with filters of equivalent size and rating – refer to dehumidifier details (compartment stickers, etc.)       Insulation  Inspect  dehumidifier  insulation,  exposed  to  airstream  for  microbial  growth  (i.e.,  mold).  If  there  is  evidence  of  microbial growth on the interior insulation, the insulation should be removed and replaced prior to operating the  dehumidifier.    Air‐Side Coils    Warning: Hazardous chemicals! Cleaning agents can be highly acidic or alkaline. Handle all chemicals carefully  and use appropriate personal protective equipment (PPE). Refer to the cleaning agent manufacturer's Materials ...
  • Page 29   M – Basic Maintenance    Special Maintenance Tasks. Fluid Cooler Winterization.  Normally fluid coolers are used in the systems, filled with glycol mixture to prevent the system and the fluid cooler  from freezing and, potentially, rupturing, when exposed to temperatures below freezing point.  When fluid cooler is used with media that, when exposed to low temperatures, could freeze (water or lower‐ percentage glycol mixture), one way to protect the equipment is to drain it (also known as “winterization” of the  equipment).  Though fluid cooler itself is normally equipped with means to be drained properly/fully, it is recommended to have  same means in place for entire system (fluid cooler – piping – dehumidifier etc.):   Have each local high point of the system equipped with means to bleed the air (air bleeding valve etc.)   Have each local low point of the system equipped with means to drain the fluid.     CAUTION.  Draining and re‐filling the fluid cooler must be performed by trained personnel, according to  proper field practice and system layout. Improper draining or re‐filling the system could lead to equipment  damage, malfunction, premature tear and ware and may void equipment warranty.     CAUTION.    Ensuring that the fluid cooler and associated system(s) equipped with proper means of  draining, creating draining and re‐filling procedures as well as determining whether draining is warranted to  protect the equipment is outside of manufacturer’s scope and is a responsibility of installing contractor and local  maintenance team.                      M‐    ...
  • Page 30: Chapter W - Warranty

      W – Warranty  Warranty    General Policy  This warranty applies to the original equipment owner and is not transferable. Seresco Technologies Inc. warrants  as set forth and for the time periods shown below that it will furnish, through a Seresco Technologies Inc.  authorized installing contractor or service organization, a new or rebuilt part for a factory installed part which has  failed because of defect in workmanship or material.  Warranty Void Unless Registered  Warranty is void unless, upon start‐up of the equipment, the “Warranty Registration and Start‐up Report” is  completed and sent to the factory within one week of initial start‐up. This report will also register the compressor  warranty with the compressor manufacturer.  Initial 90‐day Warranty  During the first 90 days from initial start‐up and prior to the completion of the 24  month from date of shipment,  whichever comes first and subject to prior written approval from the factory, Seresco Technologies Inc. will  provide and/or reimburse the required labour, materials, and shipping and handling costs incurred in the  replacement or repair of a factory installed defective part. Only the labour required to replace the defective part is  warrantied – travel time, diagnostic time, per diems, truck charges, etc. are not covered under this warranty.  WebSentry Conditional One Year Extended Labour Warranty  The initial 90‐day labour warranty shall be extended for a total of 12 months from initial start‐up and prior to the  completion of the 24  month from date of shipment, whichever comes first and subject to prior written approval  from the factory. The provided equipment must be connected and communicating to Seresco's WebSentry online  control and monitoring service for the entire term of the warranty extension. Seresco Technologies Inc. will  provide and/or reimburse the required labour, materials, and shipping and handling costs incurred in the  replacement or repair of a factory installed defective part. Only the labour required to replace the defective part is  under warranty – travel time, diagnostic time, per diems, truck charges, etc. are not covered under this warranty.  Two Year Parts Warranty  If any factory installed part supplied by Seresco Technologies Inc. fails because of a defect in workmanship or  material prior to the completion of the 24  month from date of shipment, Seresco Technologies Inc. will furnish a  new or rebuilt part F.O.B. factory. No labour reimbursement will be made for expenses incurred in making field  adjustments or parts replacement outside the Initial 90‐day Warranty. Seresco Technologies Inc. reserves the right  to have the defective part returned to the factory in order to determine the warranty applicability. Parts shipping  and handling costs (to and from the factory) are not covered outside of the Initial 90‐day Warranty.       ...
  • Page 31   Applicability  This warranty is applicable only to products that are purchased and installed in the United States and Canada. This  warranty is NOT applicable to:  1. Products that have become defective or damaged as a result of the use of a contaminated water circuit or  operation at abnormal water temperatures and/or flow rates  2. Parts that wear out due to normal usage, such as air filters, belts and fuses. Refrigerant lost during the  parts warranty will be reimbursed in accordance to the current market price of refrigerant at the time of  repair and upon discretion of Customer Support team. Seresco Technologies Inc. will not be responsible  for refrigerant lost from the system due to improperly installed contractor piping to the remote outdoor  air‐cooled condenser.  3. Refrigerant coils that corrode due to improperly balanced pool chemistry or corrosive air/poor air quality.  4. Components that have been relocated from their original placement at the factory.  5. Any portion of the system not supplied by Seresco Technologies Inc.  6. Products on which the model and/or serial number plates have been removed or defaced.  7. Products which have become defective or damaged as a result of unauthorized opening of refrigeration  circuit, improper wiring, electrical supply characteristics, poor maintenance, accidents, transportation,  misuse, abuse, fire, flood, alteration and/or misapplication of the product.  8. Products not installed, operated and maintained as per respective Seresco Technologies Inc. Manual.   9. Products on which payment is in default.    This warranty is contingent to the proper maintenance of pool water chemistry including a pH of between 7.2 and  7.6 free chlorine not exceeding 2.0 ppm and combined chlorine maintained at less than 0.3 ppm.  These  parameters are to be measured and recorded daily and be available for review upon request.    Limitations  This warranty is given in lieu of all other warranties.  Anything in the warranty notwithstanding, any implied  warranties of fitness for particular purpose and merchantability shall be limited to the duration of the express  warranty.  Manufacturer expressly disclaims and excludes any liability for consequential or incidental damage for ...
  • Page 32   W – Warranty  Force Majeure  Seresco Technologies Inc. will not be liable for delay or failure to provide warranty service due to government  restrictions or restraints, war, strikes, material shortages, acts of God or other causes beyond Seresco Technologies  Inc. control.    Optional Five Year Compressor Warranty  This extended warranty must be purchased before the shipment of the equipment.  Seresco Technologies Inc. will provide a replacement compressor for 60 months from the date of shipment  provided the factory installed compressor fails as a result of manufacturing defect and is returned to the factory  with transportation prepaid.  This extended compressor warranty is subject to all the terms of the standard  Seresco Technologies Inc. warranty but applied to the compressor only.    No charges attributed to the replacement of a component, except as detailed in above Initial 90‐day Warranty, will  be allowed unless specifically granted in writing beforehand by Seresco Technologies Inc.    Optional Five Year Airside Coil Warranty  This extended warranty must be purchased before the shipment of the equipment.  Seresco Technologies Inc. will provide a replacement Airside Coil for 60 months from the date of shipment  provided the failed coil is returned to the factory with transportation prepaid.  This extended coil warranty is  subject to all the terms of the standard Seresco Technologies Inc. warranty but applied to the airside coils only.  No charges attributed to the replacement of a component, except as detailed in above Initial 90‐day Warranty, will  be allowed unless specifically granted in writing beforehand by Seresco Technologies Inc.    Optional 10 Year Airside Coil Warranty  This extended warranty must be purchased before the shipment of the equipment.  Seresco Technologies Inc. will provide a replacement Airside Coil for 120 months from the date of shipment  provided the failed coil is returned to the factory with transportation prepaid.  This extended coil warranty is  subject to all the terms of the standard Seresco Technologies Inc. warranty but applied to the airside coils only.  No charges attributed to the replacement of a component, except as detailed in above Initial 90‐day Warranty, will  be allowed unless specifically granted in writing beforehand by Seresco Technologies Inc.              W‐   March  ...
  • Page 33   W – Warranty    Optional Five Year Driveline Warranty  This extended warranty must be purchased before the shipment of the equipment.  Seresco Technologies Inc. will provide a replacement of driveline components (listed below as Driveline  Components) for 60 months from the date of shipment provided the factory installed component fails as a result  of manufacturing defect and is returned to the factory with transportation prepaid.  This extended component  warranty is subject to all the terms of the standard Seresco Technologies Inc. warranty but applied to the driveline  components only.   Driveline Components:   Supply fan motor   Exhaust fan motor (including MinExhaust and PurgeExhaust motors)   Heat recovery loop pump   Compressor glycol/water pump   Dry cooler/outdoor condenser fan(s)   Dry cooler pump(s)  No charges attributed to the replacement of a component, except as detailed in above Initial 90‐day Warranty, will  be allowed unless specifically granted in writing beforehand by Seresco Technologies Inc.      W‐    ...
