- Page 1 OPERATION AND MAINTENANCE MANUAL NE SERIES DEHUMIDIFIERS NE-008 to NE-016 NE-216 to NE-232 Classic Indoor Model serescodehumidifiers.com...
-
Page 2: Table Of Contents
B –Table of Content Table of Content Chapter C ‐ General Information C – 1 C – 1 Operating Safety C – 2 Reference and Additional Information Contact Us C – 2 C – 3 Basic Information Dehumidifier View and Options C – 3 Dehumidifier External Systems Connection C – 5 Dehumidifier Optional Arrangement C – 6 Air Conditioning Options – Outdoor Air Condensers and Fluid Coolers C – 6 Equipment Specific Data C – 8 Chapter D ‐ Layout and Components D – 1 D – 1 Dehumidifier Main Components D – 3 Control System D – 5 Outdoor Air Condensers and Fluid Coolers Layout and Components Chapter E ‐ Sequence of Operation E – 1 E – 1 Set Points ... - Page 3 B –Table of Content This page is left blank B‐ ...
-
Page 4: Chapter C - General Information
C – General Information General Information This manual provides basic information about the applicable Seresco dehumidifier and its operation. Important information regarding installation, maintenance, and start up as well as additional and auxiliary systems and devices (outdoor condenser, communication interfaces, etc.) is normally provided with the dehumidifier and can also be obtained from the manufacturer (see Contact Us below). Operating Safety (Warnings, Cautions, and Notes) FOR YOUR SAFETY: READ BEFORE PERFORMING ANY OPERATIONS, MAINTENANCE OR SERVICE TASKS! Only qualified technicians should install, operate, maintain or service mechanical equipment including current dehumidification system. Make sure to read this manual before performing any tasks to familiarize yourself with the equipment as well as with any potential hazards. Always exercise caution! Beware of electrical power and high electrical voltage! • Follow proper safety procedures – lockout, tagout, and other respective procedures • Failure to follow safety procedures can result in serious injury or death Beware of moving parts and hot surfaces! • Make sure to stop all moving parts (fans, blowers, etc.) before accessing the equipment’s internal space • Be aware of hot surfaces (hot refrigeration, space heating pipes, coils, heaters, etc.) Beware of high pressures and chemicals! • Dehumidifiers, equipped with compressors, contain refrigerant under high pressure; oil is also contained in the compressor and refrigeration circuit(s) • Some dehumidifiers may also contain other liquids such as glycol mixtures and pool water ... -
Page 5: Reference And Additional Information C
Attention: Maintenance Team CAUTION. To ensure equipment longevity and proper and efficient operation, the dehumidifier and its auxiliary systems and devices (outdoor condenser, fluid cooler, boiler package, etc.) should be maintained properly and regularly. Failure to do so could negatively affect premise comfort levels and people’s health. It could also lead to equipment damage, malfunction, premature tear and ware and may void equipment warranty. Contact Us For immediate assistance: 1‐833‐DAS‐POOL (327‐7665) Seresco 1071 Ages Drive Start‐up Requests: Start‐ups@dehumidifiedairservices.com Ottawa, ON K1G 6L3 Miscellaneous Inquiries: Support@dehumidifiedairservices.com Canada Parts Requests: Parts@dehumidifiedairservices.com http://serescodehumidifiers.com Warranty: Warranty@dehumidifiedairservices.com ... -
Page 6: Basic Information
C – General Information Basic Information Dehumidifier View and Options Standard NE008 – NE016 dehumidifiers come in horizontal (Pic.C.1‐A) or vertical (Pic.C.1‐B) composition: Horizontal Composition Return Air (RA) ductwork connection ‐ horizontal. Supply Air (SA) ductwork connection options – top, bottom, horizontal side (left or right). Outdoor Air (OA) intake ductwork connection options – top, horizontal side (left or right). Piping Connections ① Condensate Drain ② AC – Air‐Cooled (refrigeration) ③ AC – Water‐Cooled (water/glycol) ... - Page 7 C – General Information Vertical Composition Return Air (RA) ductwork connection ‐ horizontal. Supply Air (SA) ductwork connection options – top, horizontal side (left or right). Outdoor Air (OA) intake – top, horizontal side (left or right). Piping Connections ① Condensate Drain ② AC – Air‐Cooled (refrigeration) ③ AC – Water‐Cooled (water/glycol) ④ Pool Heating Water ⑤ Space Heating Hot Water Electrical connection Pic. C.1‐B Dehumidifier Options (applicable to both, vertical and horizontal, configurations): Indoor, single‐compressor dehumidifiers, 8 to 16 ton cooling capacity (apprx.) ‐ models NE008 to NE016*. Two‐compressor dehumidifier option (see Dehumidifier Optional Arrangement below for details): 16 to 32 ton cooling capacity (appx.) ‐ models NE216 to NE232; Airflow and ductwork connection options (Return Air (RA), Supply Air (SA) Outdoor Air (OA)) * ‐ as shown on Pic. C.1‐A and C.1 – B. Optional Pool Water Heating **. ...
-
Page 8: Dehumidifier External Systems Connection C
C – General Information ** The pool water heating option relies on compressor‐created excess heat and is used as an additional heating source. It does not eliminate the need for a main pool water heater. *** For specific details on space heating (hot water, gas, electric) option, refer to the submittal and other documentation: Gas‐fired duct heater can be provided for field installation (to be fitted in the supply air ductwork). Electric heater or hot water coil, depending on capacity, model, size, etc., can be installed externally (mounted on the top of SA opening or fitted in the supply air ductwork) or internally. Refer to your dehumidifier’s submittal documentation. Attention! Equipment Clearances and Dimensions! CAUTION! For equipment proper operation, maintenance and service, respective clearances should be maintained. Generally, 30” clearances to the equipment must be kept for the maintenance and service purposes. For the specific required clearances information, as well as dehumidifier overall dimensions, distances to pipe connections, duct connections etc., refer to the submittal documentation. Dehumidifier External Systems Connection Pic. C.1 – A and B show provisions for external systems connections, including ductwork, electric power and control wires and various piping connections. CAUTION! Current manual shows general/default connections’ location. For details regarding specific dehumidifier’s connections (actual location, piping sizes and position dimensions, circuit type and flow direction etc.), refer to the dehumidifier’s submittal documentation as well as dehumidifier’s labels and stickers. Except for the condensate, all other piping systems are optional and may not be present in each dehumidifier. NOTE. Dehumidifier MUST be equipped with a P‐trap at the condensate connection for proper operation! If dehumidifier is requested/provided from the factory without P‐trap, one MUST be installed on site prior to dehumidifier being commissioned. Refer to the dehumidifier stickers and Installation Manual for details. Air Conditioning (AC) Connection. Normally, the dehumidifier has only one AC option – air‐cooled (requiring connection to the outdoor air condenser) or water‐cooled (requiring connection to the fluid cooler or other external water‐cooled system such as geothermal, cooling tower, etc.). Therefore, only one of these options ... - Page 9 C – General Information Dehumidifier Optional Arrangement Two‐Compressor Arrangement Standard NE series dehumidifier has one compressor, however two‐compressor arrangement is available also. Note, that all options and details, provided above, apply to both, standard and two‐compressor arrangement: “Double‐Decker” dehumidifier is shown on Pic. C.3. It is composed of two identical dehumidifiers, one installed on top of another and controlled as a single Pic. C.3 dehumidifier (each deck is equipped with one compressor/refrigeration circuit). Single and Two‐Compressor Arrangement – Dehumidifier Model Dehumidifier typical arrangement, total capacity, and number of compressors are reflected in its model (for specific dehumidifier model refer to its Main Label – see Specific Data Info below), as illustrated in examples below: NE008 – single‐deck single‐compressor dehumidifier. Two ‐compressor NE series dehumidifier: NE216 ‐ double‐deck two‐compressor dehumidifier (composed of two identical dehumidifiers NE008). Most often, “Double‐Decker” comes as two horizontal dehumidifiers, one “stacked” on the top of another, however it could also be composed of two dehumidifiers (horizontal OR vertical) installed side by side or separately, still being controlled as one. Air Conditioning Options ‐ Outdoor Air Condensers (OACC) and Fluid Coolers (OAFC). Basic views of standard air conditioning options are shown on Pic.C.4 (below); standard combinations of the dehumidifier and respective air conditioning option (based on their capacities) are shown in Table C.1. * Table C.1 shows standard dehumidifier and Table C.1. Dehumidifier‐AC Combination* condenser/cooler combination; depending on number of Dehumidifier – Outdoor Condenser** Fig.# factors, dehumidifier may have different condenser/cooler ...
- Page 10 C – General Information Attention! Equipment Clearances! Proper clearances should be maintained for adequate airflow and heat rejection! Generally, up to 36” side and 96” top clearances are required. For more information on clearances as well as equipment dimensions and other details, refer to the submittal documentation. Pic. C.4 C‐ February OMM.C.S.BI.01 2020...
-
Page 11: Equipment Specific Data C
C – General Information Equipment Specific Data Specific information for individual dehumidifiers is provided in the following methods: Main Label (Pic. C.5): the manufacturer tag attached to the front of the dehumidifier includes the dehumidifier’s most critical data: General data including: Serial number Dehumidifier model (nomenclature) Design room conditions (air temperature and humidity) Operational data, including: Refrigeration (refrigerant type, charge, etc.) Electrical/airflow (dehumidifier voltage, CFM, etc.) Other applicable data (pool heating, space/auxiliary heating features, etc.) Labels and Stickers: attached when applicable to the exterior and interior of the dehumidifier to show: External systems connections location/direction (pool/space heating, cooling circuits, condensate) Air filter locations, quantity, and size. Pic. C.5 Additional Info (warning, caution stickers, etc.) Wiring Diagrams: attached to the interior side of the Note: The main label shown above is just an example. ... -
Page 12: Chapter D - Layout And Components
D – Layout and Components Layout and Components The general layout and components location is the same for all dehumidifiers of current type, however some may vary, based on the dehumidifier’s specific options – refer to submittal documentation. Pic. D.1A (vertical) and D.1B (horizontal) below show all/most available options, some of which may not be present on your dehumidifier. Dehumidifier Main Components 11 4 5 16 18 17 1 13a 2 3 14 10a 13 ... - Page 13 D – Layout and Components 7 11 8 10a 9 4 5 10 16 15 1 13a 3 14 13 2 17 18 Pic. D.1B Main Blower (1) is in the main blower compartment next to the Main Electric Panel (2) and Compressor Compartment (3). Some models could be equipped with two main blowers. Min Outdoor Air (OA) Opening (4) is optionally equipped with a motorized damper and filter(s). The Manual OA Damper (5) is usually used to set proper amount of outdoor air intake. Refrigeration coils ‐ Evaporator (7) and Reheat (internal condenser) (8) ‐ are located directly downstream of the Main Filter Rack (9). Evaporator Bypass Damper (10) is located next to the evaporator coil. It helps to control compressor suction pressure by adjusting the amount of air, bypassing the evaporator. Main manual by‐pass damper (10a) is used to adjust airflow across air coils (evaporator, reheat and space heating coils). Space heater (11) location, if the dehumidifier is equipped with one, may vary: ...
-
Page 14: Control System D
D – Layout and Components Compressor (13), Receiver (14) and other components are located within the Compressor Compartment (3). If the dehumidifier has the standard pool water heating option, the compressor circuit additionally includes the coaxial pool water heat exchanger (15) and refrigeration pool water heating valve. If the dehumidifier has the water‐cooled air conditioning option (equipped with fluid cooler or connected to external water‐cooling source), the compressor circuit also includes the plate heat exchanger (16). Some models may have refrigeration suction accumulator (13a). Main Electric Panel contains Main Control Board (17), Operator Panel (18) and other electrical components. Control System The dehumidifier control system is composed of sensors, spread throughout the dehumidifier, Main Control Board, Operator Panel and other electric components, located in the Main Electric Panel. Temperature Sensors (Pic. D.2): a) Temperature sensors (thermistors) are used to monitor a b various temperatures (air, water, compressor, etc.); Combo sensor is used to monitor air temperature and humidity. d Pic. D.2 Compressor operation is monitored with pressure sensors (Pic. D.3): c Pressure Transducers (as main operational control and safety) and Pressure Switches (fast‐reacting backup safety). - Page 15 D – Layout and Components As an option, the pool water heat exchanger piping/manifold may have water flow switch also. The compressor’s discharge line (high pressure side) is equipped with Temperature and Pressure sensors set ‐ Discharge Temperature Sensor, High Pressure Transducer and High Pressure Switch (27) ‐ to protect the compressor and control its operation. A similar function is performed by Suction Temperature Sensor, Low Pressure Transducer and Low Pressure Switch (28) located at compressor’s suction line (low pressure side). Main Electric Panel, apart from devices listed above (control board, OP, etc.) also contains Voltage Monitor; some optional control sensors and devices such as an air pressure differential sensor, current sensor(s). It may also be located in main electrical panel or in the dehumidifier in general. 24 22 21 22 23 24 27 28 26 25 21 27 28 23 Pic. D.4 ...
-
Page 16: Outdoor Air Condensers And Fluid Coolers Layout And Components
D – Layout and Components Outdoor Air Condensers and Fluid Coolers Layout and Components . The general layout of AC options (air‐and water‐cooled) is shown on Pic.D.5 below with the outdoor air condenser NC‐Z‐1 (left) and fluid cooler NG‐V‐11 (right) as an example. While layout and main components are similar for all applicable AC options, there are some deviations (number of fans, coil sizes, composition, etc.). Refer to AC Options Basic View (Basic Information chapter) for additional information. NG‐V‐11 32 NC‐Z‐1 36 33 31 31 37 35 34 Pic. D.5 Cooling (AC) coil(s) (31) (where heat from refrigerant in the outdoor condenser or glycol mixture in fluid cooler is rejected to the ambient air) is mounted onto metal frame/air box upstream (before) the fan (32), that pulls the air through the coil to absorb the heat. Condenser/cooler piping connections (33) are identified respectively (IN – OUT, Hot gas – Liquid etc.); In some cases, fluid cooler piping connection(s) may be located within pump package box (37), if fluid cooler is provided with one. Piping connection location may vary – refer to particular cooler/condenser labels, stickers, submittal and other documentation. Depending on the type, size and installation, outdoor condensers may be provided with different set of legs/supports (34), which are required assembly on‐site – refer to the Installation manual. Depending on the size and capacity, condenser or cooler may have multiple fans or coils. Electric power is normally to be brought to disconnect (35) (if cooler/condenser is equipped with such), which feeds it to the electrical box (36), that contains condenser or cooler power and control apparatuses. ... - Page 17 D – Layout and Components Fluid Coolers Pump Package. Fluid Coolers, if equipped with such option, would have a pump package box. Pic.D.6 below shows general layout of pump packages, used for NG‐V model fluid coolers. Note, that the package could be mounted onto the fluid cooler directly (standard) or provided separately. Pump (38) establishes glycol mixture circulation through the fluid cooler and dehumidifier; 38 Expansion tank (39) compensates for temperature‐ based glycol volume fluctuation; The pump package electrical sub‐panel (40) contains the pump package electrical power and control apparatuses. The pump package manifolds are usually equipped with pressure gauges, automatic air venting valve, draining and other valves. 40 39 Pic. D.6 D‐ ...
-
Page 18: Chapter E - Sequence Of Operation
E – Sequence of Operation Sequence of Operation The dehumidifier’s ventilation system establishes the required airflow through the dehumidifier. The control system compares air temperature and humidity to their desired values (set points) and proceeds to dehumidify, cool or heat the recirculating air. If the dehumidifier is equipped with the pool water heating option, the pool water temperature is compared to its set point and pool heating is provided if required. Set Points The control system is constantly adjusting unit operation to achieve and maintain said parameters within couple degrees/percent of the set point. Refer to the dehumidifier’s main label for the design value of control parameters, as well as the following note. Note: To ensure the dehumidifier’s most economical operation, we recommend maintaining the following relationship between pool water and room air temperatures: Room Air T = Pool Water T + 2˚F Ventilation. The main blower runs continuously, establishing required airflow and pulling fresh outdoor air onto the premise through the minimum outdoor air intake (OA1) damper. The main blower speed is pre‐set via adjustable variable signal. Dehumidifier, though usually does not have it built‐in, can control the external minimum exhaust fan (EF1), to directs portion of return air outdoors. Like the main blower, exhaust fan speed is controlled via adjustable (pre‐set) variable signals: the exhaust fan speed may vary depending on scheduled ventilation mode (Occupied, Non‐ Occupied and Spectator) or call for Economiser Mode (as part of Air Conditioning or Dehumidification operation). Note. Externally installed Exhaust Fan(s) and Outdoor Air damper(s) could be also controlled by the dehumidifier control system. This applies to both, Minimum and Purge/Additional, fans and dampers. Space Heating When premise air temperature drops below the set point, the dehumidifier control system issues a call for Space Heating Mode and engages space heater (electric heater, hot water coil with valve, gas boiler etc.) by sending space heating signal, respective to space heater control type ‐ on/off, variable (0‐10VDC), etc. Air Conditioning, Dehumidification and Pool Heating. Compressor(s) Whenever the compressor operates, the evaporator is always dehumidifying and cooling the return air. The heat removed from the air at the evaporator, as well as the heat from the compressor's action, must be rejected to one of three heat sinks: room (premise) air, pool water (if applicable) or outdoors. The control system will direct the heat to where it is needed based on room (air and pool water temperature) conditions: ... - Page 19 E – Sequence of Operation Rest of the heat (if any) is diverted towards outdoors (outdoor condenser, fluid cooler, etc.) Compressor Circuit Operation Piping schematic for compressor circuit is shown on Pic. E.1. When a demand requires the compressor to operate, the following sequence occurs: Once blower operation, related safeties and timers are confirmed by the control system, the pump down solenoid valve opens and once pressure stabilizes, the compressor starts. Based on the premise air temperature, the refrigeration reheat and/or AC solenoid valve opens, allowing refrigerant to flow through the respective condenser: ...
-
Page 20: Chapter F - Interface And Communication
F – Interface and Communication Interface and Communication Touch Display Operator Panel The Touch Display Operator Panel (OP), shown on Pic. F.1, is used as a main interface between the dehumidifier and operator. The same OP can be located in the dehumidifier main electric panel (default; used as a local OP) or installed remotely from the dehumidifier NOTE: length of CAT5 or CAT6 cable, between remote OP and the dehumidifier MUST NOT exceed 1000’! Touch Display OP allows to: Access Touch Display Menus View dehumidifier current operational statuses (Touch Display Communication, Alarms, dehumidifier operational calls, etc.) View controlled parameters’ values (premise air temperature, humidity and, if applicable, pool water temperature) and current date and time. Pic. F.1 Touch Display Menus: Home Opens/returns to the home page Logs Access to dehumidifier logs and log‐related features (Alarms, etc.) User Access to user settings (Setpoints) and commands (Stop/Restart Dehumidifier, etc.) Advanced Access to advanced settings and features Help Context sensitive help presenting information related to the viewed page Most common/basic maintenance tasks performed using Touch Display OP Adjust Setpoint – in User menu: press the User button, then press the Setpoints button; select desired parameter (room air temperature etc.) and enter the desired value. Press the Enter button to confirm the entered value. Stop/Restart Dehumidifier –– in User menu: press the User button, then press the System Restart button; To stop and restart dehumidifier, press the System Restart button ... -
Page 21: Alarms F
F – Interface and Communication Alarms If the dehumidifier control system detects abnormal or unsafe for further operation situation, it issues Alarm (notification of such situation accompanied by respective component or entire dehumidifier stoppage and/or lockout) or Alert (notification of minor abnormal situation without any devices’ stoppage or lockout). All alarms and alerts are recorded and can be viewed/cleared via the Touch Display OP: Viewed: to facilitate troubleshooting and addressing abnormal situation Cleared: to unlock stopped device or entire dehumidifier and allow for further operation The table F.1 below lists the basic alarms with their descriptions and recommended initial troubleshooting. Table F.1. Most Common Alarms/Alerts Alarm Alarm Description Check No Air No air flow (air flow switch fault – if air flow Check main blower operation and air flow switch is installed) switch Blower OL Main Blower overload/safety fault Check main blower operation and its LED light blinking pattern. Fire Fire/smoke detector fault – if detector is installed Check external fire/smoke externally and connected to control board detector/system Freeze Supply Air temperature is lower than Freezestat Check SA temperature readout, space Setting (default: 45 F) heating system operation Filter Alert, indicating that filter change timer has Clear the Filter alarm and cancel filter lapsed – if timer is activated scheduler if not in use. ... -
Page 22: Remote Communication
F – Interface and Communication Remote Communication Although dehumidifier is designed to operate as a self‐controlled device (not requiring any external control), communication between the dehumidifier and external control and monitoring systems is possible. WebSentry WebSentry is an online tool (also referred to as Web Monitor), that allows for remote communication to the dehumidifier for various purposes such as monitoring, data collection, parameters adjustment, and notifications. This feature is included with all dehumidifiers and is useful for maintenance teams and service providers (HVACR technicians). To establish Web Monitor communication, the dehumidifier must communicate with the factory server via the Internet: ‐ Connect the dehumidifier to a local network switch, router or wireless AP device (providing connection to a local network): Plug an Ethernet cable into the sub‐board Ethernet RJ‐45 jack (sub‐board, called Core Module, is located on the main control board in the main electric panel) – see Pic. F.2. Note: separate RJ‐45 jack (plastic, black) is mounted on the control board directly, for TouchDisplay connection. Make sure to use the proper jack (metal‐surface one, located on the sub‐board) for Web Monitor connection. ‐ Configure, as needed, local server and dehumidifier network settings. BMS (Building Management System) Communication to BMS can also be supported, depending on the type of communication protocol said BMS utilizes. The equipment control software supports most common of them ‐ different control software variation might be required to support different BMS communication protocols. Contact factory if necessary. BACnet (Internet, IP). Communication is established via the Ethernet cable (same method as Web Monitor). BACnet and Web Monitor communication can be used simultaneously. ... - Page 23 F – Interface and Communication This page is left blank F‐ ...
-
Page 24: Chapter M - Basic Maintenance
M – Basic Maintenance Basic Maintenance Although Seresco equipment is built for minimal service downtime, periodic preventative maintenance is required to ensure maximum reliability, safety, and operating efficiency. WARNING! To ensure equipment longevity and proper and efficient operation, the dehumidifier and its auxiliary systems and devices (outdoor condenser, fluid cooler, boiler package, etc.) must be maintained properly and regularly. It is recommended to create a facility‐specific Routine Maintenance Program. Failure to maintain the equipment properly and regularly could result in personal injury, equipment damage or malfunction and will void the equipment warranty. Maintenance and Safety Only qualified/properly trained personnel should attempt to perform respective maintenance tasks. When it is necessary to work with live electrical components, have a licensed electrician or other qualified professional perform the required task. Be properly trained and equipped. Some maintenance tasks may involve usage of power tools, chemicals, etc. Refer to such tools and materials data (manuals, MSDS, etc.). Personnel performing such maintenance tasks should be: Properly trained to handle such tools and materials safely Equipped with proper personal protective equipment Turn the power off. Before performing any maintenance, disconnect all electrical power, including remote disconnect, and discharge all energy storing devices (VFDs, etc.) before servicing. Follow proper lockout procedures to ensure that power cannot be accidentally restored. Failure to follow provided safety warnings and labels could result in serious injury or death. Be aware of potential hazards. The equipment contains moving mechanical parts, components under high refrigerant pressures and surfaces with high temperatures. Before entering the dehumidifier and/or performing any equipment maintenance work, make sure that all moving parts are stopped, and it is safe to perform required task. Maintenance Key Points Here are some basic/key maintenance considerations, pertinent to all dehumidifiers and their auxiliary systems: Dehumidifier in mechanical room. No chemicals should be stored in the same mechanical room where the dehumidifier is installed. Chemical fumes/off‐gas can cause premature deterioration of the equipment. Store chemicals in a separate, well‐ventilated room. ... -
Page 25: Routine Maintenance Program M
M – Basic Maintenance Pool Water Chemistry. Incorrect pool water chemistry (improper pH level or high concentration of chlorine, sea salt or other corrosive additives etc.) can result in equipment premature wear or malfunction (let alone poor air quality in the pool and potential health issues) and will void the equipment warranty. Refer to pool water quality standards; contact factory as needed. Routine Maintenance Program Creating facility‐specific routine maintenance program and following it is vital to equipment longevity and efficient operation. The suggested general maintenance operations and their frequency/intervals, listed in the table M‐1 below, can be used to create such a program. For more detailed maintenance recommendations related to specific components, refer to the respective component manufacturer’s manual. Table M.1. Recommended Maintenance Tasks and Intervals Interval Maintenance Task Weekly Observe the equipment for any changes in running conditions and unusual noise Clean or replace air filters if clogged or dirty Quarterly Verify that all set‐points are correctly programmed as specified by the facility operator Inspect and clean the drain pan(s) Tighten electrical connections, if required Check and tighten, if required, pool water hose clamps and sensor mounts Inspect all airside coils (outdoor condenser, fluid cooler, dehumidifier coils – evaporator, etc.) for Semi‐ dirt, cobweb build‐up, etc.; clean as needed Annually Check that the P‐trap is primed (filled with water). It is good practice to pour some water into the drain pan to ensure that the P‐trap is primed and operational Check the outdoor air louvres and dampers for accumulation of dust and clean as required Inspect the equipment’s cabinet for corrosion. If any damage is found, clean and repaint the affected surface with a rust‐resistant primer Clean the fan wheel(s) Check dampers operation (linkage/actuator is not loose, damper opens/closes properly etc.) Inspect electrical components, wiring and insulation Annually Rotate the fan wheel(s) and check for obstructions and rubbing ... -
Page 26: Specific Components Maintenance M
M – Basic Maintenance Specific Components Maintenance Actual maintenance plan may vary from installation to installation, yet there are several key components from maintenance prospective. If needed, contact respective component manufacturer for additional maintenance information. Filters Ensure air filters are clean. Dirty air filters will negatively affect dehumidifier performance and lifetime Frequency of filters replacement will vary based on air quality, dehumidifier usage, facility type, etc. Make sure to replace filters regularly Replace with filters of equivalent size and rating – refer to dehumidifier details (compartment stickers, etc.) Insulation Inspect dehumidifier insulation, exposed to airstream for microbial growth (i.e., mold). If there is evidence of microbial growth on the interior insulation, the insulation should be removed and replaced prior to operating the dehumidifier. Air‐Side Coils Warning: Hazardous chemicals! Cleaning agents can be highly acidic or alkaline. Handle all chemicals carefully and use appropriate personal protective equipment (PPE). Refer to the cleaning agent manufacturer's Materials ... - Page 27 M – Basic Maintenance Special Maintenance Tasks. Fluid Cooler Winterization. Normally fluid coolers are used in the systems, filled with glycol mixture to prevent the system and the fluid cooler from freezing and, potentially, rupturing, when exposed to temperatures below freezing point. When fluid cooler is used with media that, when exposed to low temperatures, could freeze (water or lower‐ percentage glycol mixture), one way to protect the equipment is to drain it (also known as “winterization” of the equipment). Though fluid cooler itself is normally equipped with means to be drained properly/fully, it is recommended to have same means in place for entire system (fluid cooler – piping – dehumidifier etc.): Have each local high point of the system equipped with means to bleed the air (air bleeding valve etc.) Have each local low point of the system equipped with means to drain the fluid. CAUTION. Draining and re‐filling the fluid cooler must be performed by trained personnel, according to proper field practice and system layout. Improper draining or re‐filling the system could lead to equipment damage, malfunction, premature tear and ware and may void equipment warranty. CAUTION. Ensuring that the fluid cooler and associated system(s) equipped with proper means of draining, creating draining and re‐filling procedures as well as determining whether draining is warranted to protect the equipment is outside of manufacturer’s scope and is a responsibility of installing contractor and local maintenance team. M‐ ...
-
Page 28: Chapter W - Warranty
W – Warranty Warranty General Policy This warranty applies to the original equipment owner and is not transferable. Seresco Technologies Inc. warrants as set forth and for the time periods shown below that it will furnish, through a Seresco Technologies Inc. authorized installing contractor or service organization, a new or rebuilt part for a factory installed part which has failed because of defect in workmanship or material. Warranty Void Unless Registered Warranty is void unless, upon start‐up of the equipment, the “Warranty Registration and Start‐up Report” is completed and sent to the factory within one week of initial start‐up. This report will also register the compressor warranty with the compressor manufacturer. Initial 90‐day Warranty During the first 90 days from initial start‐up and prior to the completion of the 24 month from date of shipment, whichever comes first and subject to prior written approval from the factory, Seresco Technologies Inc. will provide and/or reimburse the required labour, materials, and shipping and handling costs incurred in the replacement or repair of a factory installed defective part. Only the labour required to replace the defective part is warrantied – travel time, diagnostic time, per diems, truck charges, etc. are not covered under this warranty. WebSentry Conditional One Year Extended Labour Warranty The initial 90‐day labour warranty shall be extended for a total of 12 months from initial start‐up and prior to the completion of the 24 month from date of shipment, whichever comes first and subject to prior written approval from the factory. The provided equipment must be connected and communicating to Seresco's WebSentry online control and monitoring service for the entire term of the warranty extension. Seresco Technologies Inc. will provide and/or reimburse the required labour, materials, and shipping and handling costs incurred in the replacement or repair of a factory installed defective part. Only the labour required to replace the defective part is under warranty – travel time, diagnostic time, per diems, truck charges, etc. are not covered under this warranty. Two Year Parts Warranty If any factory installed part supplied by Seresco Technologies Inc. fails because of a defect in workmanship or material prior to the completion of the 24 month from date of shipment, Seresco Technologies Inc. will furnish a new or rebuilt part F.O.B. factory. No labour reimbursement will be made for expenses incurred in making field adjustments or parts replacement outside the Initial 90‐day Warranty. Seresco Technologies Inc. reserves the right to have the defective part returned to the factory in order to determine the warranty applicability. Parts shipping and handling costs (to and from the factory) are not covered outside of the Initial 90‐day Warranty. ... - Page 29 Applicability This warranty is applicable only to products that are purchased and installed in the United States and Canada. This warranty is NOT applicable to: 1. Products that have become defective or damaged as a result of the use of a contaminated water circuit or operation at abnormal water temperatures and/or flow rates 2. Parts that wear out due to normal usage, such as air filters, belts and fuses. Refrigerant lost during the parts warranty will be reimbursed in accordance to the current market price of refrigerant at the time of repair and upon discretion of Customer Support team. Seresco Technologies Inc. will not be responsible for refrigerant lost from the system due to improperly installed contractor piping to the remote outdoor air‐cooled condenser. 3. Refrigerant coils that corrode due to improperly balanced pool chemistry or corrosive air/poor air quality. 4. Components that have been relocated from their original placement at the factory. 5. Any portion of the system not supplied by Seresco Technologies Inc. 6. Products on which the model and/or serial number plates have been removed or defaced. 7. Products which have become defective or damaged as a result of unauthorized opening of refrigeration circuit, improper wiring, electrical supply characteristics, poor maintenance, accidents, transportation, misuse, abuse, fire, flood, alteration and/or misapplication of the product. 8. Products not installed, operated and maintained as per respective Seresco Technologies Inc. Manual. 9. Products on which payment is in default. This warranty is contingent to the proper maintenance of pool water chemistry including a pH of between 7.2 and 7.6 free chlorine not exceeding 2.0 ppm and combined chlorine maintained at less than 0.3 ppm. These parameters are to be measured and recorded daily and be available for review upon request. Limitations This warranty is given in lieu of all other warranties. Anything in the warranty notwithstanding, any implied warranties of fitness for particular purpose and merchantability shall be limited to the duration of the express warranty. Manufacturer expressly disclaims and excludes any liability for consequential or incidental damage for ...
- Page 30 W – Warranty Force Majeure Seresco Technologies Inc. will not be liable for delay or failure to provide warranty service due to government restrictions or restraints, war, strikes, material shortages, acts of God or other causes beyond Seresco Technologies Inc. control. Optional Five Year Compressor Warranty This extended warranty must be purchased before the shipment of the equipment. Seresco Technologies Inc. will provide a replacement compressor for 60 months from the date of shipment provided the factory installed compressor fails as a result of manufacturing defect and is returned to the factory with transportation prepaid. This extended compressor warranty is subject to all the terms of the standard Seresco Technologies Inc. warranty but applied to the compressor only. No charges attributed to the replacement of a component, except as detailed in above Initial 90‐day Warranty, will be allowed unless specifically granted in writing beforehand by Seresco Technologies Inc. Optional Five Year Airside Coil Warranty This extended warranty must be purchased before the shipment of the equipment. Seresco Technologies Inc. will provide a replacement Airside Coil for 60 months from the date of shipment provided the failed coil is returned to the factory with transportation prepaid. This extended coil warranty is subject to all the terms of the standard Seresco Technologies Inc. warranty but applied to the airside coils only. No charges attributed to the replacement of a component, except as detailed in above Initial 90‐day Warranty, will be allowed unless specifically granted in writing beforehand by Seresco Technologies Inc. Optional 10 Year Airside Coil Warranty This extended warranty must be purchased before the shipment of the equipment. Seresco Technologies Inc. will provide a replacement Airside Coil for 120 months from the date of shipment provided the failed coil is returned to the factory with transportation prepaid. This extended coil warranty is subject to all the terms of the standard Seresco Technologies Inc. warranty but applied to the airside coils only. No charges attributed to the replacement of a component, except as detailed in above Initial 90‐day Warranty, will be allowed unless specifically granted in writing beforehand by Seresco Technologies Inc. W‐ March ...
- Page 31 W – Warranty Optional Five Year Driveline Warranty This extended warranty must be purchased before the shipment of the equipment. Seresco Technologies Inc. will provide a replacement of driveline components (listed below as Driveline Components) for 60 months from the date of shipment provided the factory installed component fails as a result of manufacturing defect and is returned to the factory with transportation prepaid. This extended component warranty is subject to all the terms of the standard Seresco Technologies Inc. warranty but applied to the driveline components only. Driveline Components: Supply fan motor Exhaust fan motor (including MinExhaust and PurgeExhaust motors) Heat recovery loop pump Compressor glycol/water pump Dry cooler/outdoor condenser fan(s) Dry cooler pump(s) No charges attributed to the replacement of a component, except as detailed in above Initial 90‐day Warranty, will be allowed unless specifically granted in writing beforehand by Seresco Technologies Inc. W‐ ...
