Texsport 02901 Instructions

Thank you for purchasing this Texsport dining canopy. Please read and understand each step of the set-up instructions. We encourage you to set-
up this dining canopy at least once prior to your camping trip, ensuring that you have a satisfactory understanding of the set-up process. We hope
you enjoy your new dining canopy and that it will give you many years of camping pleasure.
PARTS LIST:
A ......1 Dining canopy skin
B ......4 Chain-corded legs
C ......2 Shock-corded roof
poles
D ......Guy ropes, clews and
stakes
NOTE:
Prepare your camp site by
removing all sharp stones, twigs,
etc. The site should be flat and
have no depressions that could
collect rain water.
STEP 1 - Spread out dining
canopy skin.
STEP 4 - Velcro poles to secure
to dining canopy skin.
STEP 7 - Assemble the 4 chain-
corded legs (B) and insert into
the large molded pole joint.
o not apply excessive force to this product.
A
STEP 2 - Assemble the 2 long
dining canopy poles (C), and in-
sert into the small molded pole
joints
STEP 5 - This is what your
canopy roof looks like at this
point.
STEP 8 - Attach the roof hooks
on the roof panel to the leg
tabs.
INSTRU TIONS
Item 02901
Dining
D
anopy
C
STEP 3 - Your poles should form
an X as shown above.
STEP 6 - Carefully flip the roof
over.
STEP 9 - Velcro roof panel to the
legs to secure.
B
