Feature
To use the system when you are also
Econo
using other power-consuming
appliances.
To save energy.
To provide a comfortable airflow that
Comfort
does NOT come in direct contact with
people.
To cool down or heat up the room
Powerful
quickly.
To automatically turn ON or OFF the
ON timer + OFF
system.
timer
4.3 Operation mode and temperature
setpoint
When. Adjust the system operation mode and set the temperature
when you want to:
▪ Heat up or cool down a room
▪ Blow air in a room without heating or cooling
▪ Decrease the humidity in a room
What. The system operates differently, depending on the user
selection.
Setting
The system cools down or heats up a
Automatic
room to the temperature setpoint. It
automatically switches between cooling
and heating if necessary.
The system decreases the humidity in a
Drying
room without changing the temperature.
The system heats up a room to the
Heating
temperature setpoint.
The system cools down a room to the
Cooling
temperature setpoint.
The system only controls the airflow
Fan
(airflow rate and airflow direction).
The system does NOT control the

temperature.

Additional info:
▪ Outside temperature. The system's cooling or heating effect
decreases when the outside temperature is too high or too low.
▪ Defrost operation. During heating operation, frost might occur on
the outdoor unit and decrease the heating capacity. In that case,
the system automatically switches to defrosting operation to
remove the frost. During defrosting operation, hot air is NOT
blown from the indoor unit.
FTXF20~35A5V1B + FTXF20~25B5V1B
Daikin room air conditioner
3P520336-3E – 2019.09
4.3.1
Tasks
1 Press
2 Press
Description
3 Press
Note: When using drying or fan only mode, you cannot adjust the
temperature.
4 Press
4.3.2
1 Press
To adjust the airflow rate
1 Press
To start/stop operation mode and to set
the temperature
: Unit is operating.
: Operation mode = Automatic
: Operation mode = Drying
: Operation mode = Heating
: Operation mode = Cooling
: Operation mode = Fan only
: Shows the set temperature.
one or more times to select the operation mode.
Result: The mode will be set in the following sequence:
to start operation.
Result: is displayed on the LCD.
Result: The operation lamp lights up.
or on the button one or more times to lower or
raise the temperature.
to stop operation.
Result: disappears from the LCD.
Result: The operation lamp goes off.

Airflow rate

to choose:
5 airflow rate levels, from "
Automatic operation
Indoor unit quiet operation. When the airflow is set to
" ", the noise from the unit will be reduced.
INFORMATION
▪ If the unit reach the temperature setpoint in cooling,
heating or automatic mode. Fan will stop operating.
▪ When using drying operation mode, you CANNOT
adjust the airflow rate setting.
to change the airflow setting as follows:
4 Operation
" to " "
