Ascon tecnologic TLK41 Operating Instructions Manual

TLK41
MICROPROCESSOR-BASED
DIGITAL ELECTRONIC
CONTROLLER
OPERATING INSTRUCTIONS
Vr. 04 (ENG) - 11/05 - cod.: ISTR-MTLK41ENG4
Ascon Tecnologic S.r.l.
Via Indipendenza 56
27029 Vigevano (PV) - ITALY
Tel.: +39 0381 69871
FAX: +39 0381 698730
internet: http://www.ascontecnologic.com
e-mail: info@ascontecnologic.com
PREFACE
This manual contains the information necessary for
the product to be installed correctly and also in-
structions for its maintenance and use; we there-
fore recommend that the utmost attention is paid to
the following instructions and to save it.
This document is the exclusive property of Ascon Tecnologic S.r.l.
which forbids any reproduction and divulgation, even in part, of the
document, unless expressly authorized.
Ascon Tecnologic S.r.l. reserves the right to make any formal or
functional changes at any moment and without any notice.
Whenever a failure or a malfunction of the device may cause dan-
gerous situations for persons, things or animals, please remember
that the plant has to be equipped with additional devices which will
guarantee safety.
Ascon Tecnologic S.r.l. and its legal representatives do not assume
any responsibility for any damage to people, things or animals deriv-
ing from violation, wrong or improper use or in any case not in com-
pliance with the instrument features.
Ascon Tecnologic S.r.l. - TLK 41 - OPERATING INSTRUCTIONS - Vr. 04 - 11/05 - ISTR-MTLK41ENG4 - Pag. 1
INDEX
1 INSTRUMENT DESCRIPTION
1.1 GENERAL DESCRIPTION
1.2 FRONT PANEL DESCRIPTION
2 PROGRAMMING
2.1 FAST PROGRAMMING OF SET POINT
SELECTION OF CONTROL STATE AND PARAMETER
2.2
PROGRAMMING
2.3 PARAMETER PROGRAMMING LEVELS
2.4 CONTROL STATES
2.5 ACTIVE SET POINT SELECTION
3 INFORMATION ON INSTALLATION AND USE
3.1 PERMITTED USE
3.2 MECHANICAL MOUNTING
3.3 ELECTRICAL CONNECTIONS
3.4 ELECTRICAL WIRING DIAGRAM
4 FUNCTIONS
4.1 MEASURING AND VISUALIZATION
4.2 OUTPUTS CONFIGURATION
4.3 ON/OFF CONTROL
4.4 NEUTRAL ZONE ON/OFF CONTROL
4.5 SINGLE ACTION PID CONTROL
4.6 DOUBLE ACTION PID CONTROL
4.7 AUTO-TUNING AND SELF-TUNING FUNCTIONS
REACHING OF SET POINT AT CONTROLLED SPEED AND
4.8
AUTOMATIC COMMUTATION BETWEEN TWO SET POINTS
4.9 SOFT-START FUNCTION
4.10 ALARM FUNCTIONS
4.11 HEATER BREAK ALARM FUNCTION
4.12 LOOP BREAK ALARM FUNCTION
4.13 FUNCTION OF KEY
4.14 RS 485 SERIAL INTERFACE
4.15 PARAMETERS CONFIGURATION BY KEY0
5 PROGRAMMABLE PARAMETERS
6 PROBLEMS, MAINTENANCE AND WARRANTY
6.1 ERROR SIGNALLING
6.2 CLEANING
6.3 WARRANTY AND REPAIRS
7 TECHNICAL DATA
7.1 ELECTRICAL DATA
7.2 MECHANICAL DATA
MECHANICAL DIMENSIONS, PANEL CUT-OUT AND
7.3
MOUNTING
7.4 FUNCTIONAL DATA
7.5 MEASUREMENT RANGE TABLE
7.6 INSTRUMENT ORDERING CODE
1 - INSTRUMENT DESCRIPTION
1.1 - GENERAL DESCRIPTION
TLK 41 is a "single loop" digital microprocessor-based controller,
with ON/OFF, Neutral Zone ON/OFF, PID single action, PID dual ac-
tion (direct and reverse) control and with AUTO-TUNING FAST
function, SELF-TUNING function and automatic calculation of the
FUZZY OVERSHOOT CONTROL parameter for PID control.
The PID control has a particular algorithm with TWO DEGREES OF
FREEDOM that optimises the instrument features independently in
the event of process disturbance and Set Point variations.
Furthermore, the instrument allows for RS485 serial communication
using MODBUS-RTU communication protocol and a transmission
speed up to 38.400 baud.
The process value is visualized on 4 red displays, while the output
status is displayed by 4 LED indicators. The instrument has also a
programmable 3 LED shift index.
The instrument can store 4 Set Points and can have up to 4 outputs:
relay type or Voltage type to drive solid state relays (SSR).
