Ascon tecnologic TLB 55 Operating Instruction

TLB 55
DIGITAL ELECTRONIC
REFRIGERATION UNITS
CONTROLLER
OPERATING INSTRUCTIONS
Vr. 04 (ENG) - 02/12- cod.: ISTR-MTLB55ENG04
ASCON TECNOLOGIC S.r.l.
VIA INDIPENDENZA 56
27029 VIGEVANO (PV) ITALY
TEL.: +39 0381 69871
FAX: +39 0381 698730
http:\\www.ascontecnologic.com
e-mail: info@ascontecnologic.com
FOREWORD
This manual
necessary for the product to be installed
correctly
maintenance and use; we therefore recommend
that the utmost attention is paid to the following
instructions and to save it.
This document is the
TECNOLOGIC which forbids any reproduction and divulgation
, even in part, of the document, unless expressly authorized.
ASCONT ECNOLOGIC reserves the right to make any formal or
functional changes at any moment and without any notice.
Whenever a failure or a malfunction of the device may cause
dangerous situations for persons, thing or animals, please
remember that the plant has to be equipped with additional
devices which will guarantee safety.
ASCON TECNOLOGIC and its legal representatives do not
assume any responsibility for any damage to people, things or
animals deriving from violation, wrong or improper use or in
any case not in compliance with the instrument's features.
ASCON TECNOLOGIC - TLB55 - OPERATING INSTRUCTIONS - Vr. 04 - 02/12 - ISTR-MTLB55ENG04 - PAG. 1
contains the
and also instructions
exclusive property
INDEX
1 INSTRUMENT DESCRIPTION
1.1 GENERAL DESCRIPTION
1.2 FRONT PANEL DESCRIPTION
2 PROGRAMMING
2.1 PROGRAMMING OF SET POINT
2.2 PARAMETERS PROGRAMMING
2.3 PARAMETER PROTECTION USING THE PASSWORD
2.4 PARAMETERS PROGRAMMING LEVEL
2.5 ACTIVE SET POINT SELECTION
2.6 ON / STAND-BY FUNCTION
2.7 KEYBOARD LOCK FUNCTION
3 INFORMATION ON INSTALLATION AND USE
3.1 PERMITTED USE
3.2 MECHANICAL MOUNTING
3.3 ELECTRICAL CONNECTIONS
3.4 ELECTRICAL WIRING DIAGRAM
4 FUNCTIONS
4.1 MEASURING AND VISUALIZATION
4.2 OUTPUTS CONFIGURATION
4.3 TEMPERATURE CONTROL
4.4 CONTINUOUS CYCLE FUNCTION
4.5 COMPRESSOR PROTECTION FUNCTION AND DELAY
AT POWER-ON
4.6 DEFROST CONTROL
4.7 MANUAL DEFROST
4.8 EVAPORATOR FANS CONTROL
4.9 ALARM FUNCTIONS
4.9.1 TEMPERATURE ALARMS
4.9.2 EXTERNAL ALARM
4.9.3 OPEN DOOR ALARM
4.9.4 MAIN VOLTAGE ALARMS
4.9.5 ALARM MEMORY
4.10 DIGITAL INPUTS
4.11 AUXILIARY OUTPUT
4.12 FUNCTION OF KEYS "U" AND "DOWN/AUX"
4.13 PARAMETERS CONFIGURATION BY "A01"
5 PROGRAMMABLE PARAMETERS TABLE
6 PROBLEMS , MAINTENANCE AND GUARANTEE
6.1 SIGNALLING
6.2 CLEANING
6.3 GUARANTEE AND REPAIRS
7 TECHNICAL DATA
7.1 ELECTRICAL DATA
7.2 MECHANICAL DATA
7.3 MECHANICAL DIMENSIONS
7.4 FUNCTIONAL DATA
7.5 INSTRUMENT ORDERING CODE
1 - INSTRUMENT DESCRIPTION
1 .1 - GENERAL DESCRIPTION
information
The models TLB 55 (Display and control unit) and BSLB4 (Supply
and outputs
for its
microprocessor that is typically used in cooling applications that
have temperature control with ON/OFF regulation and defrosting
control with set time by means of electrical heating or hot
gas/reverse cycle.
of ASCON
The system has up to 4 relay outputs, 2 inputs for PTC or NTC
temperature probes and 2 digital inputs, that can all be configured.
The 4 outputs at main voltage (in BSL unit) can be used for
controlling the compressor or the temperature control device, the
defrosting device, the evaporation fan and an alarm or an auxiliary
device (light, second compressor etc.) .
The two inputs for the PTC and NTC temperature probes (which
can be selected by parameter) connected to TLB55 unit can be
used to measure the cell temperature (Pr1) and the evaporator
temperature (Pr2) while the digital inputs (DIG1,2) can be
programmed to carry out various functions such as defrosting
commands, selecting 2 or 4 different set of temperature
regulations, external alarm signals, activating a continuous cycle,
and activating an auxiliary output etc.
unit) are a digital controller system with
