EEI – 2285
OFFICE CHAIR
Thank you for purchasing the MODWAY OFFICE CHAIR！
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the office chair, we recommend that it is assembled by two adults, on a carpeted
or padded area, in the room that it is intended for. Approximate assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or instructions until you have checked all the components and
hardware and the furniture is fully assembled.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that have been provided.
6.Please keep all pieces out of reach of small children.
Component:
A
Chair Back
x1
E
Control Mechanism
Customer Service 908-368-1025︱www.modwayfurniture.com
B
E
H
H
B
Left Arm
F
x1
Cylinder
Hardware:
1
2
3
4
5
6
7
A
D
F
H
G
H
C
Right Arm
x1
G
x1
Chair Base
Bolt M6x20mm
Bolt M6x25mm
Bolt M6x30mm
Bolt M8x35mm
Flat Washer
Plastic Washer
Allen Wrench M6
C
H
x1
D
Chair Seat
H
Caster
x1
x2
x4
x2
x4
x4
x4
x1
x1
x5
Page 1 of 4
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for modway EEI-2285
Summary of Contents for modway EEI-2285
- Page 1 EEI – 2285 OFFICE CHAIR Thank you for purchasing the MODWAY OFFICE CHAIR！ Before you start, here is some helpful advice: 1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions.
- Page 2 EEI – 2285 OFFICE CHAIR STEP 1: Please put Chair Base (G) upside down on a carpeted or padded surface. Insert 1 piece of Castor (H) into the Chair Base (G) as shown by hand. Repeat the same steps for the remaining 4pcs of Castor (H). STEP 2: Flip the assembled Chair Base (G) with Castors (H) on the floor.
- Page 3 EEI – 2285 OFFICE CHAIR STEP 3: Place Chair Back (A) upside down on a carpeted or padded surface as shown. Attach Left Arm (B) to Chair Back (A) by using 2 pieces of Bolt (2) as shown. Tighten Bolt (2) by using Allen Wrench (7) clockwise until secure. Then insert 2 pieces of Plastic Cover (6) into pre-drilled holes as shown.
- Page 4 EEI – 2285 OFFICE CHAIR STEP 5: Place Control Mechanism (E) to the bottom of the Chair Seat (D). Attach the front of Control Mechanism (E) by using 2 pieces of Bolt (3), and the back of it by using 2 pieces of Bolt (1) as shown.
