EEI – 2285
OFFICE CHAIR
STEP 5:
Place Control Mechanism (E) to the bottom of the Chair Seat (D).
Attach the front of Control Mechanism (E) by using 2 pieces of Bolt (3), and the back of it by using 2 pieces of
Bolt (1) as shown.
Tighten Bolt (1&3) by using Allen Wrench (7) clockwise until secure.
1x2pcs 3x2pcs
STEP 6:
Carefully turn over the assembled Chair Back (A), Arm (B&C), Chair Seat (D) and Control Mechanism (E).
Please insert the bottom holes of Control Mechanism (E) into the top end of assembled Cylinder (F) as shown.
Seat on Chair Seat (D) to fully tighten the office chair.
Customer Service 908-368-1025︱www.modwayfurniture.com
3
1
B
7x1pc
A
B
E
F
Assembly is complete. The office chair is ready to be enjoyed now!
FRONT
7
3
1
E
D
BOTTOM
C
A
C
D
G
Hardware & Tool required
Page 4 of 4
