Growatt MAX Series Installation & Operation Manual
  1. Manuals
  2. Brands
  3. Growatt Manuals
  4. Inverter
  5. MAX Series
  6. Installation & operation manual

Growatt MAX Series Installation & Operation Manual

Hide thumbs Also See for MAX Series:

Advertisement

Quick Links

Download this manual
Enlarged version
Growatt New Energy
Download
Manual
SHENZHEN GROWATT NEW ENERGY TECHNOLOGY CO.,LTD No.28
Guangming Road, Shiyan Street, Bao'an District, Shenzhen, P.R.China
T: +86 755 2747 1942
E :service@ginverter.com
W :www.ginverter.com
GR-UM-142-A-02
GR-UM-142-A-02
Installation
&
Operation Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the MAX Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Growatt MAX Series

Summary of Contents for Growatt MAX Series

  • Page 1 Installation & Growatt New Energy Operation Manual Download Manual SHENZHEN GROWATT NEW ENERGY TECHNOLOGY CO.,LTD No.28 Guangming Road, Shiyan Street, Bao'an District, Shenzhen, P.R.China T: +86 755 2747 1942 E :service@ginverter.com W :www.ginverter.com GR-UM-142-A-02 GR-UM-142-A-02...
  • Page 2 List 1 Overview 1.1 Product Overview 1.2 Applicable Personnel 2 Safety Precautions 2.1 Safety Overview 2.2 Symbol 2.3 Meaning of Symbol 3 Product Introduction 3.1 Appearance 3.2 Dimensions 3.3 Nameplate 3.4 Working Principle 3.5 Inverter Storage 3.6 Grid Types . AFCI Detection Function .
  • Page 3 6 Connecting Cables 11 Decommissioning 6.1 Connection on AC side 6.2 Connection on DC side 6.3 Connection of Communication Cables 6.4 Connecting the Ground Cables 12 Quality Assurance 7 System Commissioning 7.1 Inverter Commissioning 7.2 Modes 7.3 LED display 13 Contact Us 8 Monitoring 8.1 Remote Data Monitoring 8.2 Local Data Monitoring...
  • Page 4 WARNING environment,otherwise may affect the performance of the inverter. MAX Series solar inverters. Please read this manual carefully before using the MAX series •Please follow the installation procedures in this manual. inverters and store the manual in a reachable place for an authorized technician. No further notice if there is any change in this manual.
  • Page 5 2.3 Lable Description Other： Symbol Name Meaning • After you receiving the inverter please check the packing materials for damage,if there is any damage please contact your supplier. Inverter operating with high voltage,any High Voltage operation regarding inverter need to be done by •The Max PV input voltage should not exceed 1100V.
  • Page 6 USB_B port( optional RS 485 cable waterproofe head Made in China Note: Other models of MAX series share the same label design with MAX50KTL3 LV, DC switch Outside CT port( optional only with different model name and parameters, detail parameter please refer to specification in Chapter 10.
  • Page 7 The AFCI function of the MAX series inverter is optional, and the detection equipment is assembled inside the inverter. When an arc-drawing condition is detected on the PV Fig 3.4...
  • Page 8 Unpacking Installation Checking before installation • To prevent device damage and personal injury, keep balance when 1>Before unpacking the inverter, check the outer packing materials for damage. moving the inverter because it is heavy. 2>After unpacking the inverter, check that the contents are intact and complete. If any •Do not place the inverter with its wiring and signal terminals at the damage is found or any component is missing, contact your supplier.
  • Page 9 J. Do not install inverter close to strong electromagnetic signal. K. Install the inverter out of children's reach. 1000mm 1000 5.2 Installation Environment Requirements A. Although the inverter's protection level is IP 65, to extent inverter lifespan you still need to avoid rain and snow, please refer to following drawings. 1000mm 1000mm Fig 5.5...
  • Page 10 1>Use the wall mount plate as a template drill holes on the wall and put in expansion Plan 2(Optional): bolts. 1>As shown in Fig5.8, 4-6 persons lift the inverter out of package, swap the ring to moving handles. 2>When you are moving the inverter, please keep the balance. Notice: There will be front and bottom mark on the package.
  • Page 11 Connecting Cable Decisive Voltage Class (DVC) indicated for ports Port Name Class DRMS RS485&USB 6.1 Connection on AC side • Before electrical connection, please ensure the inverter DC switch is at "OFF” also disconnect AC switch, otherwise the high voltage from inverter Fig 5.12 may cause life risk.
  • Page 12 Cable specification: 2>Firstly, unscrew the waterproof cover, then put the cable through the cover, pile the cable base on terminal size(17mm recommended), use a wire stripper to connect Copper wire recom- Copper wire cross- Aluminum wire recom Inverter Model cable. and terminal, tighten all the terminal screws. mendation( mm²) sectional area(mm²)
  • Page 13 If the inverter was damaged 6.3 Connection Of Communication Cables by higher maximum open circuit voltage (higher than 1100Vdc) product warranty will be forfeited and Growatt will not take any responsibility. 6.3.1 RS485 port WARNING •The inverter shall be used with IEC 61730 Class A rating PV module.
  • Page 14 The Inverter Side The Inverter Side Fig 6.7 6.3.2 USB port MAX series inverter is configured with USB_A port (optional USB_B port) USB_A port can be connected to USB to WIFI module, Shine GPRS-X, Shine Wifi-X, Shine 4G-X, Shine Fig 6.8B Link-X, etc.
  • Page 15 6.4 Connecting The Ground Cables In this solar system all the unloaded metal components and cases should be connected Lightning protection device to the ground. Single inverter need grounding over a PE point, multiple inverters need connect all the Distribution Photovoltaic panel Inverter inverter PE cable and solar panels shelves to the same grounding point to achieve...
  • Page 16 Click "Reset password" to enter the OSS account number and password. The distributor and installer can apply for the OSS account from Growatt. Click "Sign in" to set the password. After the setting is successful, you can start using it.) 3>Click top item “COM Address”;...
  • Page 17 7.1.2 Set inverter time and date 7.2.3 Fault mode Inverter intelligent control system will continuously monitor and adjust system Method 1: status.When there is a fault detected, LED will show the fault message. Please refer to section 8.2.1 and login ShinePhone APP.Click "system time(45-50)"to set Note: Please refer to section 8.2 to check the fault message and take corrective measures.
  • Page 18 Monitoring 8.1 Remote Data Monitoring Description of LED status MAX series inverter remote monitoring ways include APP(ShinePhone) and server Web page, RS485,GPRS,4G,PLC(reserved) can satisfy both ways of monitoring. Position Type of LED 8.1.1 Mobile phone APP(ShinePhone) remote monitoring of LED...
  • Page 19 Device page: 2>User can add datalogger at the datalogger list page to add a datalogger, edit, delete, 1>Main page top middle is the name of current plant, user can click the "∨" button to configure etc. switch to other plants under this account. 3>User can add more plants with the add Plant function.
  • Page 20 1>Register account device will come online(our device is monitored by datalogger, so need to add the Open browser, input "server.growatt.com”, click “New User” at login page, input the datalogger here first). necessary information then go back to login page, input the registered username and password, click “Sign In”.
  • Page 21 shenzhen Fig 8.16 Fig 8.19 Fig 8.17 B. Plant data page can check device power, voltage curve by time, day, month or year. Fig 8.17 Fig 8.18 3> Data reading A.Basic production reading, Energy today, total production, revenue today and accumulative revenue are showing on this page.
  • Page 22 2> Flexible parameter setting, system information management, error prompting and recording, high-capacity storage. 3> Collect data and upload data to Growatt in real time over the network. Note: The smart meter and environmental monitor must be Growatt's designated manufacturer, otherwise monitoring will not be possible. When RS485 of multiple Fig 8.23...
  • Page 23 4G/GPRS B. Enter user name and password, default login username: admin password: admin. click login after filling in, enter growatt shinemaster system page. 3>ShineMaster Data collector status view Click on the status of the shinemaster data collector to view shinemaster"system state information", "serial number,"...
  • Page 24 2）Select the type of photovoltaic device monitored in the second drop-down list. Fig 8.28 Fig 8.26 3）Fill in the third drop-down list with the photovoltaic device correspondence address. 4>ShineMaster Data collector add or delete device ShineMaster Before monitoring photovoltaic devices, we need to enter the page of the built-in shinemaster data collector settings to add devices.
  • Page 25 Enter the domain name access page, as shown in figure 8.32 below. Chinese user server domain name：http://server-cn.growatt.com. The domain name of the international user server is：http://server.growatt.com. Fig 8.32 B. View monitoring data 1) After registration is complete, jump to the shineserver main interface automatically.
  • Page 26 2) By clicking on "power station" and "equipment management" in turn, the real-time data of "data collector", "inverter", "environment monitor", "intelligent meter" and "confluence box" MAX "can be viewed. 8.2 Local Data Monitoring MAX Inverter local data monitoring mode has a mobile phone app phone) and PC direct connection, udisk, details are as follows.
  • Page 27 Fig 8.36 C.Parameter configuration Fig 8.38 The parameter data of the equipment can be modified according to the usage ( 8.37). D.Intelligent detection E.Intelligent I-V curve scanning Detailed and accurate view of the device's detailed data and status (Fig 8.38). Can remotely scan each mppt (Fig 8.39).
  • Page 28 F.Fault recording detection H.One click diagnosis Remote, fast and accurate fault location (Fig 8.40). I-V curve diagnosis, grid waveform, THDV and cable impedance detection all at one click(Fig 8.42). I.High level setting According to the register address set parameters (professionals). J.Device information Check PV voltage/current, string voltage/current, ACvoltage/current/power/frequency, PID voltage/current, internal parameters and device detail information and parameters...
  • Page 29 2>Fault Recording Create the bconfig.txt file under the root of the U disk , write the following content, then insert the U disk that can be read fault information, then generates a form under the files in the root director y, A total of 60 fault recording information is stored, the latest Numbers is 0.
  • Page 30 •Do not use the air pump cleaning fan, which may cause fan damage. WARNING When the Growatt MAX series inverter work in high temperature environment, good ventilation and heat dissipation can effectively reduce the chance of load derating. Inverter equipped with internal cooling fans, when the internal temperature is too high, Fig 8.47...
  • Page 31 5>Install the fan, fan guard fixed and the inverter again. 9.2 Trouble Shooting •Work on the Growatt Max must be carried out by qualified personnel. •Normally grounded conductors may be ungrounded and energized when a PV isolation low is indicated.
  • Page 32 Error 124 No AC connection voltage and frequency are correct Check panel and line insulation to Notice：MAX series inverter has three external fans and one Internal fan. Error 125 PV isolation low ground is good If the suggestions do not work, please contact to Growatt.
  • Page 33 Specification Model Model 70KTL3 LV 50KTL3 LV 60KTL3 LV 80KTL3 LV 50KTL3 LV 60KTL3 LV 70KTL3 LV 80KTL3 LV Specifications Specifications Input Data(DC) THDi <3% Max. recommended PV AC grid 75000W 90000W 105000W 120000W 3W/N/PE power(for module STC) connection type AC overvoltage Max.
  • Page 34 Model Model 70KTL3 LV 50KTL3 LV 60KTL3 LV 80KTL3 LV 60KTL3 MV 70KTL3 MV 80KTL3 MV 90KTL3 MV 100KTL3 MV Specifications Specifications Input Data(DC) Weight 82kg 82kg 82/86kg 82/86kg Max. recommended Operating 120000W PV power(for 9000W 105000W 130000W 130000W -25℃ - +60℃（derating over 45℃） temperature range module STC) Noise emission...
  • Page 35 Model Model 60KTL3 MV 70KTL3 MV 80KTL3 MV 90KTL3 MV 100KTL3 MV 60KTL3 MV 70KTL3 MV 80KTL3 MV 90KTL3 MV 100KTL3 MV Specifications Specifications Operating AC grid 3W+PE -25℃ - +60℃（derating over 45℃） temperature connection type range AC overvoltage Category III Noise emission category ≤60dB(A)
  • Page 36 7>Disposing of the inverter. 11.1 Disposing Of The MAX Series Inverter Do not dispose of MAX series inverter together with household waste. Please accordance with the disposal regulations for electronic waste which apply at the installation site at that time.
