- Page 1 Instruction Manual T3110 T3110L T3110Ex Programmable transmitter of temperature, relative humidity and other calculated humidity values with 4 - 20 mA outputs...
- Page 2 It is prohibited to copy and make any changes in this manual, without explicit agreement of company COMET System, Ltd. All rights reserved. COMET System, Ltd. makes constant development and improvement of their products. Manufacturer reserves the right to make technical changes to the device without previous notice.
-
Page 3: Table Of Contents
ERROR STATES OF THE DEVICE ............10 TECHNICAL SUPPORT AND SERVICE ..........11 TECHNICAL DATA .................. 12 MEASURED VALUES ................12 CALCULATED HUMIDITY VALUES ............12 GENERAL ....................14 OPERATING CONDITIONS ..............15 END OF OPERATION ................15 DIMENSIONS..................16 TYPICAL APPLICATION WIRING ............17 IE-SNC-T3110-09... -
Page 4: General Description
General description The transmitters T3110 are designed for measurement of ambient temperature and relative humidity of air without aggressive substances. Measured values are converted to other humidity interpretation: dew point temperature, absolute humidity, specific humidity, mixing ratio, specific enthalpy. Measured and computed values are displayed on a two-line LCD display. -
Page 5: T3110Ex Transmitter
European Standards EN 60079-0:2018 and EN 60079-11:2012. Transmitter is suitable for use in potentially explosive atmospheres (Apparatus Groups llC) in applications requiring devices category 3G. Type Examination Certificate number FTZÚ 13 ATEX 0189X is available at www.cometsystem.com. IE-SNC-T3110-09... -
Page 6: Factory Settings
I1: relative humidity range 4-20 mA corresponds 0 to 100 %RH value at output I2: temperature range 4-20 mA corresponds -30 to +80 ºC display: switched ON °C temperature unit: value displayed at line 2: relative humidity IE-SNC-T3110-09... -
Page 7: Device Installation
“Typical application wiring”. For device connection it is recommended to use a shielded cable with a maximum length of 1200m. External diameter of the cable for T3110 and T3110Ex connection is 4 to 8 mm. For T3311L connection use cable with respect to female connector parameters (do not connect shielding at connector side). -
Page 8: Info Mode
During info mode no measurement and no output current generation proceed. The transmitter stays at info mode 15 s and then automatically goes back to measuring cycle. The verifying of settings of the T3110Ex transmitter is permitted only in non-hazardous area. IE-SNC-T3110-09... -
Page 9: Modification Of Device Adjustment
Warning Modification of adjustment of the T3110Ex transmitter using a cable SP003 is permitted only in non-hazardous area. IE-SNC-T3110-09... -
Page 10: Error States Of The Device
Error 3 - there is a reading „Err3“ on LCD display upper line. Error of internal A/D converter appeared (converter does not respond, probably damage of A/D converter). No measurement and calculations of values are proceeded. It is a serious error, contact distributor of the instrument. IE-SNC-T3110-09... -
Page 11: Technical Support And Service
Technical support and service Technical support and service is provided by distributor. For contact see warranty certificate. You can use discussion forum at web address www.forum.cometsystem.cz. IE-SNC-T3110-09... -
Page 12: Technical Data
< 30 s (humidity step 65 %RH, constant temperature Calculated humidity values Dew point temperature:: ±1.5°C at ambient temperature T < 25 °C and Accuracy: RH > 30 %, for more details see graphs -60 to +80 ºC Measuring range: IE-SNC-T3110-09... - Page 13 ±4 kJ/kg at ambient temperature T < 35 °C Accuracy: Measuring range: 0 to 995 kJ/kg The values computed from ambient temperature and relative humidity including their accuracy you can exactly determine by the program Conversions. It is free to download at www.cometsystem.com. IE-SNC-T3110-09...
-
Page 14: General
The equipment shall only be cleaned with a damp cloth. Electromagnetic compatibility: EN 61326-1 Weight: approximately 150 g Housing material: IE-SNC-T3110-09... -
Page 15: Operating Conditions
Operating conditions Temperature operating range of the housing with electronics: -30 to +80 ºC T3110 -30 to +80 ºC T3110L Ambient temperature range of the housing with electronics: -30 to +60 ºC T3110Ex Temperature operating range of the measuring end of stem: -30 to +80 ºC... -
Page 16: Dimensions
Dimensions T3110 T3110Ex T3110L IE-SNC-T3110-09... -
Page 17: Typical Application Wiring
Typical application wiring T3110 Loop resistance value Rc = Rm + resistance of wires shall fulfill the condition Rc[Ω] < 40 x Uss[V] – 360. T3110Ex Loop resistance value Rc = Rm + Rs + resistance of wires shall fulfill the condition Rc[Ω] < 40 x Uss[V] – 360. - Page 18 T3110L Loop resistance value Rc = Rm + resistance of wires shall fulfill the condition Rc[Ω] < 40 x Uss[V] – 360. IE-SNC-T3110-09...
