IDE HDD Block Mode (Enabled)
Enable this field if your IDE hard drive supports block mode. Block mode en-
ables BIOS to automatically detect the optimal number of block read and
writes per sector that the drive can support. It also improves the speed of ac-
cess to IDE devices.
Init Display First (PCI Slot)
Use this item to specify whether your graphics adapter is installed in one of
the PCI slots or is integrated on the mainboard.

Power Management Setup Option

This option lets you control system power management. The system has vari-
ous power-saving modes including powering down the hard disk, turning off
the video, suspending to RAM, and software power down that allows the sys-
tem to be automatically resumed by certain events.
The power-saving modes can be controlled by timeouts. If the system is inac-
tive for a time, the timeouts begin counting. If the inactivity continues so that
the timeout period elapses, the system enters a power-saving mode. If any
item in the list of Reload Global Timer Events is Enabled, then any activity on
that item will reset the timeout counters to zero.
If the system is suspended or has been powered down by software, it can be
resumed by a wake up call that is generated by incoming traffic to a modem, a
LAN card, a PCI card, or a fixed alarm on the system realtime clock.
Phoenix – AwardBIOS CMOS Setup Utility
ACPI function
ACPI Suspend Type
Video Off Option
Video Off Method
Switch Function
MODEM Use IRQ
Hot Key Function as
Hot Key Power on Function
USB S33 Wakeup Function
HDD Off After
Power Button Override
Power State Resume Control
PM Wake Up Events
↑ ↓ → ← : Move
Enter : Select
F5:Previous Values
ACPI Function (Enabled)
This mainboard supports ACPI (Advanced Configuration and Power manage-
ment Interface). Use this item to enable or disable the ACPI feature.
Note: ACPI is a power management specification that makes hardware status
information available to the operating system. ACPI enables a PC to turn
its peripherals on and off for improved power management. It also allows
Power Management Setup
[Enabled]
[S1(POS)]
[Susp, Stby --> Off]
[DPMS Supported]
[Break/Wake]
[3]
[Power Off]
[Disabled]
[Disabled]
[Disabled]
[Instant-Off]
[Always Off]
[Press Enter]
+/-/PU/PD:Value: F10: Save ESC: Exit
F6:Fail-Safe Defaults
39
Item Help
Menu Level
F1:General Help
F7:Optimized Defaults
