USB2/USB3: Front panel USB connectors
The mainboard has two USB ports installed on the rear edge I/O port array.
Additionally, some computer cases have USB ports at the front of the case. If
you have this kind of case, use auxiliary USB connectors USB2 and USB3 to
connect the front-mounted ports to the mainboard.
Pin Signal Name
1 VREG_FP_USBPWR0
2 VREG_FP_USBPWR0
3 USB_FP_P0-
4 USB_FP_P1-
5 USB_FP_P0+
6 USB_FP_P1+
7 GND
8 GND
9 KEY
10 USB_FP_OC0
Note: Please make sure that the USB cable has the same pin assignment as indi-
cated above. A different pin assignment may cause damage or system
hang-up.
WOL1: Wake On LAN
If you have installed a LAN card, use the cable provided with the card to plug
into the mainboard WOL1 connector. This enables the Wake On LAN (WOL)
feature. When your system is in a power-saving mode, any LAN signal auto-
matically resumes the system. You must enable this item using the Power
Management page of the Setup Utility.
Pin Signal Name
1 5VSB
2 GND
3 Ring#
WOM1: Wake On Modem
If you have installed a modem, use the cable provided with the modem to plug
into the mainboard WOM1 connector. This enables the Wake On Modem
(WOM1 feature. When your system is in a power-saving mode, any modem
signal automatically resumes the system. You must enable this item using the
Power Management page of the Setup Utility. See Chapter 3 for more infor-
mation.
Pin Signal Name
1 5VSB
2 GND
3 Ring#
Function
Front Panel USB Power
Front Panel USB Power
USB Port 0 Negative Signal
USB Port 1 Negative Signal
USB Port 0 Positive Signal
USB Port 1 Positive Signal
Ground
Ground
No pin
Overcurrent signal
Function
+5V stand by power
Ground
Wake up signal (high active)
Function
+5V stand by power
Ground
Wake up signal (low active)
