Step 4 (Wired Connection):
Readthis stepif youare usingwiredconnection, otherwiseskip to Step5.
This steprequires the skillof making an Ethernet cable. Consult with the
electricianifyouarenotsurehowtodoit.
A weatherproof tube is needed for Ethernet cable to avoid leaking water
into Ethernet cable port. Cut off the Ethernet cable at the length you want.
Insert the cable into the weatherproof tube, and carefully attach RJ-45
connector to the cut ends. Test the cable is working before installing.
Thingsyouneed:
BarecopperEthernetcable
RJ45connector
RJ45crimpingtool
1
3
2
Bare copper Ethernet cable
RJ45connector
20
