MAX VEHICLE ROOF LOAD RATING: 68 KG
TOTAL LOAD EQUALS WEIGHT OF ROOF RACKS + ACCESSORIES + CARGO
•
Please read instructions carefully before installation.
•
Check the contents of kit. Contact your YAKIMA dealer if any parts appear missing or damaged.
•
Clean your roof thoroughly prior to fitting the LockNLoad Heavy Duty Roof Rack System.
•
Place these instructions in the vehicle's glove box after installation is complete.
TOOLS REQUIRED:
•
13 mm Socket Wrench
•
13 mm Spanner
•
10 mm Open Ended Spanner
•
#2 Phillips Head Screwdriver
• Torque Wrench (Optional)
•
Rubber Mallet (Optional)
• Tape Measure
•
Scissors
•
Spirit Level
ITEM COMPONENT
1.
M6 Set Screw 30 mm
2.
M6 Washer
3.
M8 Hex Bolt 25 mm
4.
M8 Hex Bolt 40 mm
5.
M8 Washer
6.
Foam Adhesive
7.
M6 Set Screw 20 mm
LEG AND BAR COMPONENTS SOLD SEPARATELY
1
2
3
28-13-013-Rev5
®
3 BAR FIXED POINT HEAVY DUTY ROOF RACK SYSTEM
FIRST TIME INSTALLATION
KIT CONTENTS
QTY ITEM
x4
x6
x4
x8
x12 12.
x12
x2
9
10
13
LockNLoad Mounting Kit
TOYOTA FJ CRUISER 2011+
COMPONENT
8.
Front Left Pad (2804031)
9.
Middle Left Pad (2803081)
10.
Rear Left Pad (2804035)
11.
Front Right Pad (2804032)
Middle Right Pad (2803082)
13.
Rear Right Pad (2804036)
8
12
™
4
5
11
6
7
QTY
x1
x1
x1
x1
x1
x1
1/8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Yakima LockNLoad
Summary of Contents for Yakima LockNLoad
- Page 1 • Please read instructions carefully before installation. • Check the contents of kit. Contact your YAKIMA dealer if any parts appear missing or damaged. • Clean your roof thoroughly prior to fitting the LockNLoad Heavy Duty Roof Rack System. •...
- Page 2 INSTALLATION IF PLANNING TO INSTALL LockNLoad PLATFORM, FOLLOW THE PLATFORM SUPPLEMENT INSTRUCTIONS 28-13-371. REMOVE FIXED POINT HARDWARE AFFIX FOAM ADHESIVE Place Foam Adhesive over plastic Remove fixed-point tubes in the vehicle’s fixed points, covers. with adhesive side to vehicle. Remove bolts,...
- Page 3 Pads REMOVE END CAPS FROM BARS From the LockNLoad Bar Kit (sold separately), remove Plastite Screw from each Bar end using a #2 Phillips Head Screwdriver and pull out End Caps from Bars. Keep all parts aside for later installation.
- Page 4 Leg Covers. If Leg assemblies will not slide in, loosen Screws to increase gap. BAR SLOT COVERS From the LockNLoad Bar Kit, cut BAR SLOT COVER CUT MEASUREMENTS Bar Slot Covers as per the table Front Bar Middle Bar Rear Bar...
- Page 5 Bar end as shown. -20 mm Secure using Plastite Screw SECURE END CAPS TO BARS (from LockNLoad Bar kit). Insert the End Caps as shown. A Rubber Tighten using a #2 Phillips Mallet can be used to assist installation.
- Page 6 SECURE BARS TO PADS Tighten all M6 set screws to 7 Nm using 10 mm From the LOCKN’LOAD Mounting kit, Open Ended Spanner. assemble 1 x M6 Washer onto each M6 Set Screw (30 mm and 20 mm) Do not over tighten. as shown.
- Page 7 Covers supplied in the store with the spare vehicle key. LockNLoad Leg Kit, fit and lock all Leg Covers. Write the key number (which is stamped on the key) in the box provided.
- Page 8 YAKIMA AUSTRALIA PTY. LTD 17 Hinkler Court Brendale, QLD 4500 Australia 1800 143 548 YAKIMA PRODUCTS, INC. 4101 Kruse Way Lake Oswego, OR 97035-2541 888 925 4621 28-13-013-Rev5...
