F Data Sheet - Electrical Connection
The motor must be connected only by an authorized electrician: The relevant local regulations must
be observed when laying the cables and connecting the motor. The installation of motor protection
equipment is mandatory. Refer to the Machine Data Sheet for the electrical values. The motor turns
in the correct direction with a clockwise rotary field.
The insulation resistance must not fall below 20 MOhm on commissioning. The insulation resis-
tance must be >= 2 MOhm for further tests. The direct measuring voltage is 1000 V.
Monitoring device identificat
Motor monitoring
Bimetal sensor
(1st temperature 20/21
circuit)
Bimetal sensor
(2nd temperature 20/21/22
circuit)
PTC sensor
(1st temperature 10/11
circuit)
PTC sensor
(2nd temperature 10/11/12
circuit)
PT-100 winding
1/2
temperature sensor
PT-100 bearing
T1/T2
temperature sensor
Pressure switch D20/D21
Thermo float switch 20/21
Leak monitoring
Seal chamber / motor
chamber / terminal DK/DK
chamber monitoring
Seal chamber
DK/DK
monitoring for Ex
Table F-1: * Limit temperature: insulation class F = 140°, insulation class H = 160°, for oil motors = 110°,
PVC wire = 80°, PE2 wire = 90°
E:\shares\Baprod\BA\subtec_m\e_plan\us\electric.fm
Wire Recommended
analyzing
ion device
-
-
CM-MSS
CM-MSS
DGW 2.01G
DGW 2.01G
-
-
NIV 101
ER 143
Data Sheet - Electrical Connection
Triggered
Threshold
condition
- Switch off
Low temperature:
early warning
-
High temperature:
switch off
Preset Switch off
Low temperature:
early warning
Preset
High temperature:
switch off
Depending
Switch off
on winding*
100°C Switch off
- Switch off
- Switch off
Warning or switch
30 KOhm
off
30 KOhm Switch off
Safety notes
Insulation resistance
Monitoring equipment
F-1
