Spare parts

Spare parts Figure 138 4G
Pos. Description
10 Throughflow sensor
Shim ring
20
DIN 988 22x32x1 A2
30 Corrugated spring washer
Sealing ring
40
DIN 472 - 33x1.2 A2
Protective cap flowmeter
50
valve
Adhesive label for protec-
60
tive cap
Spare parts Figure 138 6G
Pos. Description
10 Throughflow sensor 4-20mA DN10: 121001386G110-00
Shim ring
20
DIN 988 22x32x1 A2
30 Corrugated spring washer
Sealing ring
40
DIN 472 - 33x1,2 A2
Protective cap flowmeter
50
valve
Adhesive label for protective
60
cap
© www.kemper-olpe.de – 07.2020 – K41001384G001-00 – 23/24
KEMPER product number
DN10: 121001384G110-00
DN15: 121001384G115-00
DN20: 121001384G120-00
DN25: 121001384G125-00
DN32: 121001384G132-00
DN40: 121001384G140-00
DN50: 121001384G150-00
KEMPER product number
DN15: 121001386G115-00
DN20: 121001386G120-00
DN25: 121001386G125-00
DN32: 121001386G132-00
DN40: 121001386G140-00
DN50: 121001386G150-00
DN 10
DN 15 - 32
DN 40 - 50 (without picture)
