Note: For the YOUVI installation, please pay special attention to the YOUVI quick reference
guide and the information on KNX project preparation to enable the automatic reading of the
project. This quick reference guide is included in the delivery.
Further information about YOUVI can be found in the YOUVI Help, which can be opened in
the program YOUVI Dashboard > ? > Help. Here you will also find the current range of func-
tions of the software under: YOUVI Visu > Scope of functions.

3.1.3 Operation with third-party software

The Windows 10 LTSC operating system pre-installed on the panel allows the use of other
Windows-based software for e.g. visualizations and door intercoms. Depending on the
software used, the functional scope of the panel can be expanded considerably. A list of
compatible software can be found in the FAQs:
www.peaknx.com/FAQ, topic "compatibility".
Note:
PEAKnx does not guarantee the function of third-party software on the panel.
Further instructions for setting up the panel can be found in the download area:
www.peaknx.com/downloads#controlmini

3.2 Product features

■
LED Backlit full color TFT display, 1920 x 1080 pixels
■
Touchscreen, projected capacitive (PCAP)
■
Integrated speakers and microphone
■
Integrated camera
■
Fieldbus connection for KNX
■
100 Mbit-Ethernet connection, suitable standard for cabling: Cat-5 or better
■
Operating system: Windows 10 IoT Enterprise LTSC
■
No fan, thus silent
■
24 V DC supply; 2,5 A
■
Maximum power consumption under full load: 15 W
■
Power consumption, no load: 10 W, Server operation without LCD: 5W
■
Ambient temperature 0 to 35 °C
■
flush-mounted or surface-mounted wall installation, in landscape orientation, parallel
to the wall
■
Protection class IP20
