SPECIFICATIONS

TECHNICAL DATA

Functional Specification
Extension length
Width
Hardware Specification
Actuator material
Framework material
Mounting component material
Actuator placement
Roller configuration
Roller position
Canvas
Electrical Specification
Voltage
Amperage
Operating device
Controller type
Controller dimensions
Structural Specification
Maximum wind speed
Maximum weight displacement
Deflection
sureshade.com 877-333-8323
ATF STAGE
5', 6' or 7'
Up to 12'
Over 12' custom
316SS
316SS
316SS
Integrated w/in bridge or hardtop
Top surface-mount
Underside surface-mount
Straight or cambered spring-tension roller
Traveling or stationary
Marine-grade acrylic, Sunbrella
12V or 24V
3 amps
Toggle switch and remote control
Software-based synchronization
5" x 7" x 1.75"
50 mph
300 lbs across framework
Less than 3"
8
CCD-0003846
, any standard color
®
