USB 2.0 RG2204
4-port USB 2.0 100m Cat 5e Extender System
Quick
Start
Guide
Before you get started, ensure that all the drivers required for your USB device(s) are installed.
Place extenders where desired and
1
1
connect the Cat 5e extension link cable
to the Link ports (RJ45) on the local and
remote extender.
Local Extender (back view)
Remote Extender (back view)
Link
Max 100m
(Cat 5e cable not included)
Connect the remote extender to the AC
3
adapter and plug it into a power source.
Link
Includes the ExtremeUSB® suite of features:
Connect the local extender to the
2
computer using the included
USB cable.
Computer
Link
Note: Power adapter is not required
at local extender for normal operation.
Attach USB device(s) to the remote
4
extender.
Remote Extender (front view)
Transparent USB extension
True plug and play; no software drivers required
Works with all major operating systems: Windows®,
Mac OS X®, and Linux®
Link
90-01004-A03
