OPERATING MANUAL (AS)
ROUGH TERRAIN SCISSORS
MODEL
SJ6832 RTE
159178AD-A January 2018

Advertisement

Table of Contents
loading

Related Manuals for Skyjack SJ6832 RTE

Summary of Contents for Skyjack SJ6832 RTE

  • Page 1 OPERATING MANUAL (AS) ROUGH TERRAIN SCISSORS MODEL SJ6832 RTE 159178AD-A January 2018...
  • Page 2 This manual is based on Serial Number(s): SJ6832 RTE 37 300 001 - 370 300 174 Please refer to the website (www.skyjack.com) for older Serial Numbers. Skyjack Service Center Parts & Service (Europe) Unit 1 Maes Y Clawdd 3451 Swenson Ave. St. Charles,...
  • Page 3 The Safety Alert Symbol identifies important safety messages on MEWP , safety signs in This Safety Alert Symbol means attention! manuals or elsewhere. When you see this symbol, be alert to the possibility of personal Become alert! Your safety is involved. injury or death.

  • Page 4: Table Of Contents

    Table of Contents Section 1 - About Your MEWP ........................ 5 Read and Heed ..............................5 Safety Rules ................................6 Section 2 - Familiarization ........................11 Familiarization of SJ68RTE Series ......................11 Component Identification ..........................12 Visual & Daily Maintenance Inspections ....................16 Function Tests ............................23 Winching and Towing Procedure ......................33 Emergency Lowering Procedure ......................34 Section 3 - Operation ...........................

  • Page 5: Section 1 - About Your Mewp

    SKYJACK warrants each new SJRT Compact Electric Series MEWP to be free of defective parts and workmanship for the first 24 months. Any defective part will be replaced or repaired by your local SKYJACK dealer at no charge for parts or labor. Contact the SKYJACK Service Department for warranty statement extensions or exclusions.

  • Page 6: Safety Rules

    Common sense dictates the use of protective clothing when working on or near machinery. Use appropriate safety devices to protect your eyes, ears, hands, feet and body. Any modifications from the original design are strictly forbidden without written permission from SKYJACK. Electrocution Hazard This MEWP is not electrically insulated.
  • Page 7 Section 1 - About Your Aerial Platform Safety Rules Safety Precautions Know and understand the safety precautions before going on to next section. WARNING Failure to heed the following safety increase the lateral • DO NOT precautions could result in tip over, surface area of the platform.
  • Page 8 Safety Rules Section 1 - About Your Aerial Platform Safety Precautions (Continued) Know and understand the safety precautions before going on to next section. operate on surfaces not capable of • AVOID overhead obstructions. • DO NOT holding the weight of the MEWP including the aware overhead rated load, e.g.
  • Page 9 • DO NOT place materials on the guardrails or materials that exceed the confines of the guardrails unless approved by Skyjack. • DO NOT use the MEWP without guardrails, locking pins and the driving and horseplay are prohibited.
  • Page 10 Safety Rules Section 1 - About Your Aerial Platform Safety Precautions (Continued) Know and understand the safety precautions before going on to next section. WARNING Entering and exiting the MEWP should only be done using the three points of contact. •...

  • Page 11: Section 2- Familiarization

    Section 2- Familiarization SJRT Series 2.1 Familiarization of SJ68RTE Series WARNING MEWP Familiarization should be given only to individuals who are COMPETENT and TRAINED to operate an MEWP . Do not operate this MEWP without proper authorization and training. Failure to avoid this hazard could result in death or serious injury.

  • Page 12: Component Identification

    Control Functions Section 2 - Familiarization 2.2 Component Identification 2.2-4 Load Sensing System This system is a safety device that prevents any normal The following descriptions are for identification, movement of the MEWP from a stationary working explanation and locating purposes only. condition after the rated load is reached and exceeded.
  • Page 13 Section 2 - Familiarization Control Functions 2.2-5 Emergency Lowering System 2.2-7 Free-wheeling Valve The emergency lowering system allows platform lowering in the event of an emergency or an electrical system failure. Refer to Section 2.6 for the emergency lowering procedure. The system contains the following controls: Figure 2-3.
  • Page 14 Control Functions Section 2 - Familiarization 2.2-8 Base Control Console Power Indicator Light - When the emergency The control console is located on the left side of the stop button on the base control console and on battery/electrical compartment. It contains the following the platform control console are both pulled out, controls: this light glows.
  • Page 15 Section 2 - Familiarization Control Functions 2.2-9 Platform Control Console Horn Push Button - This “ ” push button This removable control console is mounted at the right sounds an automotive-type horn. front of the platform. It contains the following controls: Inclined Drive/Level Drive Switch - This switch selects “...

  • Page 16: Visual & Daily Maintenance Inspections

    Visual & Maintenance Inspection Section 2 - Familiarization Platform Control Console Scissor Assembly Platform Assembly Limit Switch Limit Switch Outriggers Outriggers Base 2.3 Visual & Daily Maintenance 2.3-2 Electrical Maintaining the electrical components is essential to Inspections good performance and service life of the MEWP . Begin the visual and daily maintenance inspections by checking each item in sequence for the conditions Inspect the following areas for chafed, corroded and...
  • Page 17 Section 2 - Familiarization Visual & Maintenance Inspection Base Control Console Tilt Sensor Main Power Disconnect Switch Battery 2.3-5 Battery/Electrical Compartment WARNING Ensure compartment latch is secure and Battery acid is extremely corrosive - Wear in proper working order. proper eye and facial protection as well as •...
  • Page 18 Visual & Maintenance Inspection Section 2 - Familiarization Gear Type Hydraulic Flow Divider Oil Filter Oil Level Gauge Main Manifold Hydraulic Tank • Hydraulic Pump • Main Manifold Ensure there are no loose or missing Ensure all fittings and hoses are properly tightened and there is no evidence of parts and there is no visible damage.
  • Page 19 Section 2 - Familiarization Visual & Maintenance Inspection Manuals Platform Control Console Platform Railing Platform Assembly 2.3-7 Platform Assembly • Manuals Ensure a copy of operating manual is enclosed in manual storage box. WARNING Ensure that you maintain three points Check to be sure manual storage box is of contact to mount/dismount platform.
  • Page 20 Visual & Maintenance Inspection Section 2 - Familiarization Lift Cylinder Maintenance Support Scissor Assembly Scissor Bumper Roller 2.3-8 Lifting Mechanism • Rollers Ensure rollers are secure and there is no 1. Raise the platform (refer to Section 3.8-2) until visible damage. there is adequate clearance to swing down the Ensure rollers’...
  • Page 21 Therefore, replace tires only with the exact Skyjack- • Wheel/Tire Assembly approved type. Failure to operate with The MEWP is equipped with foam-filled tires. Tire...
  • Page 22 Visual & Maintenance Inspection Section 2 - Familiarization Overhead View Steer Cylinder Assembly Base Weldment Splitter Manifold Wheel/Tire Assembly Tie Rod Emergency Lowering Access Rod Steer Cylinder Assembly • Ladder Ensure steer cylinder assembly is Ensure there are no loose or missing properly secured, there are no loose parts and there is no visible damage.

  • Page 23: Function Tests

    Section 2 - Familiarization Function Tests Emergency Stop Button Platform/Off/Base Key Switch Main Power Disconnect Switch 2.4 Function Tests 2.4-2 Base Control Console Function tests are designed to discover any malfunctions before MEWP is put into service. The operator must WARNING understand and follow step-by-step instructions to test Ensure that you maintain three points of...
  • Page 24 Function Tests Section 2 - Familiarization Emergency Stop Button Free-wheeling Platform/Off/Base Key Valve Switch Brake Hand Pump Brake Auto Reset Valve Emergency Lowering Valve Main Power Disconnect Switch Base Control Console Main Manifold • Test Platform/Off/Base Key Switch • Test Emergency Stop 1.
  • Page 25 Section 2 - Familiarization Function Tests Emergency Stop Button Free-wheeling Platform/Off/Base Key Valve Switch Brake Hand Pump Brake Auto Reset Valve Emergency Lowering Valve Main Power Disconnect Switch Base Control Console Main Manifold • Test Emergency Lowering • Test Free-wheeling 1.
  • Page 26 Function Tests Section 2 - Familiarization Rocker Switch Lift/Drive/Steer Lift/Drive/Steer Enable Trigger Switch Controller Inclined Drive/Level Drive Switch Emergency Stop Lift/Drive Switch Button Horn Pushbutton 2.4-3 Platform Control Console • Test Enable Trigger Switch 1. Ensure base “ ” emergency stop button is 1.
  • Page 27 Section 2 - Familiarization Function Tests Rocker Switch Lift/Drive/Steer Lift/Drive/Steer Enable Trigger Switch Controller Inclined Drive/Level Drive Switch Emergency Stop Lift/Drive Switch Button Horn Pushbutton • Test Lowering Warning 2. On platform control console, select lift/ drive switch to “ ”...
  • Page 28 Function Tests Section 2 - Familiarization Rocker Switch Lift/Drive/Steer Lift/Drive/Steer Enable Trigger Switch Controller Inclined Drive/Level Drive Switch Emergency Stop Lift/Drive Switch Button Horn Pushbutton • Test Brakes • Test Horn 1. Push “ ” horn pushbutton. WARNING Result: Horn should sound. Brakes will engage instantly when you release the controller handle, causing MEWP to stop immediately.
  • Page 29 Section 2 - Familiarization Function Tests Rocker Switch Lift/Drive/Steer Lift/Drive/Steer Enable Trigger Switch Controller Inclined Drive/Level Drive Switch Emergency Stop Lift/Drive Switch Button Horn Pushbutton • Test Load Sensing Activate and hold “ ” enable trigger switch. WARNING Pull controller handle and attempt Be aware of overhead obstructions to lower the platform.
  • Page 30 Function Tests Section 2 - Familiarization Left-Rear Left-Front Outrigger Control Console Platform Control Console Right-Rear Right-Front • Test Hydraulic Outriggers (If Equipped) 7. Drive the MEWP to maximum speed. (For Hydraulic Outrigger Operation, refer to Result: MEWP drives at high speed. Section 3.8-9) WARNING 1.
  • Page 31 Section 2 - Familiarization Function Tests Left-Rear Left-Front Outrigger Control Console Platform Control Console Right-Rear Right-Front Attempt to partially extend Right-Rear Result: Lift function will not operate. Outrigger (approximately 4”). Result: Outrigger will not extend. With Left-Rear Outrigger partially extended, attempt to lift the platform. Attempt to partially extend Left-Rear Result: Lift function will not operate.
  • Page 32 Function Tests Section 2 - Familiarization Left-Rear Left-Front Outrigger Control Console Platform Control Console Right-Rear Right-Front 16. Platform at stowed position. Lower the platform from raised height Extend each outrigger until it raises the (12 feet). tires up approximately 2”. Result: Lower function will operate.

  • Page 33: Winching And Towing Procedure

    Section 2 - Familiarization Procedures 2.5 Winching and Towing Procedure Free-wheeling Valve - Turning the valve knob counterclockwise (item 1) to a fully opened This section provides the operator with the Winching position allows fluid to flow through the wheel and Towing procedure, which includes instructions on motors, thus providing “free-wheeling”.

  • Page 34: Emergency Lowering Procedure

    Procedures Section 2 - Familiarization 2.6 Emergency Lowering Procedure Remove wheel chocks or blocks, then push, winch or tow MEWP to desired location. This section guides the operator on how to use emergency lowering system. This system allows platform lowering in the event of an emergency. WARNING Brakes must be reengaged immediately WARNING...

  • Page 35: Section 3 - Operation

    MEWP . NOTE Refer to Skyjack’s website www.skyjack.com • The operator must be familiar with employer’s for latest service bulletins prior to performing work rules and related government regulations frequent or yearly inspections.

  • Page 36: Major Components

    Section 3 - Operation 3.2 Major Components Manual Storage Box Entry Gate Platform Control Console Main Platform Extension Lifting Platform Mechanism Maintenance Battery/Electrical Support Compartment Outriggers Base SKYJACK Model SJ 6832RTE MEWP Rough Terrain Electric Scissors Page 36 December 2007...

  • Page 37: Major Assemblies

    Section 3 - Operation Major Assemblies 3.3 Major Assemblies 3.4 Serial Number Nameplate The MEWP consists of three major assemblies: base, The serial number nameplate, located at the rear of the lifting mechanism and platform. MEWP , lists the following: •...

  • Page 38: Component Identification

    Component Identification Section 3 - Operation 3.5 Component Identification WARNING The following descriptions are for identification, The maintenance support must be used explanation and locating purposes only. when inspection and/or maintenance or repairs are to be performed within the 3.5-1 Manual Storage Box lifting mechanism.
  • Page 39 Section 3 - Operation Component Identification 3.5-3 Folding Guardrail System WARNING This system, when folded down, reduces the height Before operating this MEWP check the of the retracted MEWP for transporting and traveling guardrail system for loose or missing through doorways only. Refer to Section 3.9 for guardrail locking pins.

  • Page 40: Component Identification (Optional Equipment/Attachments)

    Component Identification (Special Options) Section 3 - Operation 3.6 Component Identification Leveling Indicator Light - This light illuminates to display the status of the outriggers when the (Optional Equipment/Attachments) auto and manual level functions are in use. The This section describes the components that are optional indicator light has the following states: to MEWPs.
  • Page 41 Notes Rough Terrain Electric Scissors December 2007 Page 41...
  • Page 42 Component Identification (Special Options) Section 3 - Operation 3.6-2 Hybrid Power Pack (HPP) (If Equipped) The sole purpose of this HPP is to charge the battery. : Red LED light indicates low oil level. It runs either automatically or manually. In automatic mode, the HPP automatically starts when the battery : In case of power overload, push to reset level drops to a 50% charge level and automatically...
  • Page 43 Section 3 - Operation Component Identification (Special Options) Return HPP to operating position and insert On the base control console, turn HPP on/off locking pin. switch to “ ” on position. Automatic Mode Turn HPP automatic/manual switch to “M” Ensure main power disconnect is in “ ” on position (manual) position.
  • Page 44 Component Identification (Special Options) Section 3 - Operation HPP Refueling Procedure Protection of Environment from Chemical Dangers This section provides the operator with the procedure on how to refuel the HPP with gasoline. WARNING Gasoline and engine oil are chemicals, WARNING which can contaminate the environment.

  • Page 45: Operator's Responsibility

    Section 3 - Operation Operator’s Responsibility 3.7 Operator’s Responsibility Repairs to the MEWP may only be made by a qualified service technician. After repairs are completed, the It is the responsibility of the operator, prior to each work operator must perform visual and daily maintenance shift, to perform the following: inspections &...

  • Page 46: Start Operation

    Start Operation Section 3 - Operation 3.8 Start Operation WARNING Carefully read and completely understand the operating An operator should not use any MEWP manual and all warnings and instruction labels (refer to that: Section 5 - Labels) on the MEWP . •...
  • Page 47 Section 3 - Operation Start Operation 3.8-1 To Activate Base Control Console 3.8-2 To Raise or Lower Platform Using Base Control Console WARNING WARNING Ensure that you maintain three points of contact when using the ladder to mount/ Be aware of overhead obstructions or dismount platform.
  • Page 48 Start Operation Section 3 - Operation 3.8-3 To Activate Platform Control Console 3.8-4 To Raise or Lower Platform Using Platform Control Console Turn main power disconnect switch to “ ”on position. WARNING Be aware of overhead obstructions or On the base control console, pull out the “ ”...
  • Page 49 Section 3 - Operation Start Operation 3.8-5 To Drive Forward or Backward 3.8-6 To Steer Activate platform control console (refer to WARNING Section 3.8-3). Be aware of blind spots when operating the MEWP . On the platform control console, turn lift/drive switch to “...
  • Page 50 Start Operation Section 3 - Operation 3.8-7 To Select Drive Torque 3.8-8 To Extend or Retract Manual Extension Platform High Torque: Select high torque when climbing grades, traveling on rough terrain or when loading or unloading MEWP . To activate high torque, select torque switch to “...
  • Page 51 Section 3 - Operation Start Operation 3.8-9 Hydraulic Outriggers (If Equipped) Ensure each outrigger pad is in firm contact over These devices are mounted to four corners of the base. its entire surface area, with a suitable supporting When properly positioned, they increase the stability of surface! Make adjustments if necessary using the MEWP .
  • Page 52 Start Operation Section 3 - Operation 3.8-10 Shutdown Procedure Completely lower the platform. On the platform control console, push in “ ” emergency stop button. WARNING Ensure that you maintain three points of contact when using the ladder to mount/ dismount platform.
  • Page 53 Notes Rough Terrain Electric Scissors December 2007 Page 53...

  • Page 54: Guardrail Folding Procedure

    Guardrail Folding Procedure Section 3 - Operation 3.9 Guardrail Folding Procedure To fold the guardrail system down: When folded down, the folding guardrail system reduces Ensure MEWP is on level ground. the height of the retracted MEWP for transporting only. WARNING Ensure extension platform is fully retracted.
  • Page 55 Section 3 - Operation Guardrail Folding Procedure Remove all the locking pins on the left side WARNING guardrail and fold it down. Any lowered guardrail will create a fall hazard. Remain away from the sides of With the gate closed, remove all the locking the platform while raising or lowering the pins on the entrance side guardrail and fold the guardrails to avoid falling.

  • Page 56: Loading/Unloading

    The transport vehicle must be parked on a level surface and must be secured to prevent rolling while MEWP is being loaded/unloaded. 3.10-1 Lifting When it is necessary to lift the Skyjack MEWP the following conditions must be met: • The platform must be fully lowered.
  • Page 57 Section 3 - Operation Loading/Unloading NOTE The MEWP can be lifted with a forklift from the sides but Skyjack does not recommend this use. Lift with forks in designated pockets as illustrated in Figure 3-15. Forklift pocket Forklift pocket (MEWPs with no outriggers) Figure 3-15.

  • Page 58: Moving The Mewp Through A Doorway

    Moving the Aerial Platform Through a Doorway Section 3 - Operation 3.11 Moving the MEWP Through a Ensure there are no personnel in the intended path of travel. Doorway Notify those around the pathway that you will be WARNING moving the MEWP . This procedure is suitable for level Use a spotter to guide movement.
  • Page 59 Section 3 - Operation Moving the Aerial Platform Through a Doorway WARNING Before operating this MEWP check the guardrail system for loose or missing locking pins. The guardrail system must be upright and all pins must be locked in place. Death or serious injury could result if the guardrail system is not upright or properly locked.

  • Page 60: Maintenance Support Procedure

    Maintenance Support Procedure Section 3 - Operation 3.12 Maintenance Support Procedure To Store the Maintenance Support Turn main power disconnect switch to “ ”on position. Raise platform until there is adequate clearance to swing up the maintenance support. Swing bar up into storage bracket. Lower the platform.

  • Page 61: Battery Maintenance

    Section 3 - Operation Battery Maintenance 3.13 Battery Maintenance 3.13-2 Battery Charging Operation This section provides the operator with procedures on how to service and charge the battery. This also provides charger operation instructions. 3.13-1 Battery Service Procedure WARNING Explosion Hazard - Keep flames and sparks away.
  • Page 62 Battery Maintenance Section 3 - Operation Display Parameters WARNING Do not disconnect the DC output wires • BATTERY VOLTAGE: two-tone red upper LED near the batteries when the charger is ON. The resulting arcing could cause the • CURRENT (provided by the charger): two- batteries to explode.

  • Page 63: Section 4 - Tables

    Section 4 Tables Table 4.1 Standard and Optional Features MODEL 6832RTE S T A N D A R D E Q U I P M E N T Platform controls Base controls Four-wheel drive Easy operation 152 cm roll out extension platform Load sensing system Tilt sensing system Multiple wet disc–spring applied hydraulic release brakes...
  • Page 64 Tables Section 4 Table 4.2 Specifications and Features Model 6832RTE No Outriggers 4026 kg With Outriggers 4026 kg Width 1.73 m No Outriggers 2.72 m With Outriggers 3.35 m Platform Size 1.4 m x 2.4 m Working 11.7 m Platform Elevated 9.8 m Platform Lowered 2.51 m...
  • Page 65 Section 4 Tables Table 4.3 Owner’s Annual Inspection Record Model Number: _________________ Serial Number:__________________ 20__ 20__ 20__ 20__ 20__ 20__ 20__ 20__ 20__ 1000AB This decal is located on the scissor assembly. It must be completed after an annual inspection has been completed. Do not use the aerial platform if an inspection has not been recorded in the last 13 months.
  • Page 66 Tables Section 4 Table 4.4 Maximum Platform Capacities (Evenly Distributed) Tilt Tilt Cutout Total Extension Maximum Maximum Cutout Setting MODEL Wind Side Force Setting (Outriggers) Number of Number of Speed Capacity Capacity (Degrees) (Degrees) Occupants Occupants 12.5 m/s One Extension 6832RTE 454 kg 136 kg...
  • Page 67 Section 4 Tables Table 4.5 Floor Loading Pressure Total Aerial Platform Load Gross Aerial Wheel/ Platform MODEL Outrigger LCP** OUP** Weight kg/m min* 4480 1810 1450 6832RTE on Tires max* 4675 1860 1490 1000 min* 4480 1810 6832RTE on Outrigger Pads max* 4675 1860...
  • Page 68 Intermixing tires of different types or using tires of types other than those originally supplied with this equipment can adversely affect stability. Therefore, replace tires only with the exact Skyjack- approved type. Failure to operate with matched approved tires in good condition may result in death or serious injury.
  • Page 69 Hourmeter Reading: Operator's Name (Printed): Date: Time: Operator's Signature: Each item shall be inspected using the appropriate section of the Skyjack operating manual. As each item is inspected, check the appropriate box. - PASS - FAIL - REPAIRED - NOT APPLICABLE...
  • Page 70 Notes Rough Terrain Electric Scissors Page 70 December 2007...

  • Page 71: Section 5 - Labels

    Section 5 - Labels Label Legend Label Legend Safety Red Safety Red indicates DANGER. Safety Orange Safety Orange indicates WARNING. Safety Yellow Safety Yellow indicates CAUTION. Safety Green Safety Green indicates emergency lowering. Safety Blue Safety Blue indicates safety information. Rough Terrain Electric Scissors December 2007 Page 71...
  • Page 72 Labels Section 5 Labels - Model 6832RTE Battery/Electrical Compartment Label Pictorial Description Base Control Console : Accumulated operating time. : Battery level. : Error codes. Refer to Service manual for error codes. Select “ ” on position to start HPP (if equipped). Select “...
  • Page 73 Section 5 Labels Labels - Model 6832RTE Battery/Electrical Compartment Label Pictorial Description Warning - Electrical Shock Stay away. High voltage (48V). No Pressure Washer Do not use pressure washer. Battery Cover Lock Turn knob “ ” to the left to unlock battery tray cover. Turn knob “...
  • Page 74 Labels Section 5 Labels - Model 6832RTE Right Side Label Pictorial Description Skyjack Logo Skyjack Annual Inspection Ensure that work platform has received annual inspection prior to operation. Keep Clear Keep clear. Stay away from MEWP when in operation. Caution Tape Stripe...
  • Page 75 Section 5 Labels Labels - Model 6832RTE Right Side Top View Label Pictorial Description Wheel Specifications Refer to manual for wheel type, offset, pressure and torque. Forklift Pocket Insert fork fully into pocket to lift MEWP . Model Number* Product Identifier *Model number will vary, may not be as shown.
  • Page 76 Labels Section 5 Labels - Model 6832RTE Right Side Label Pictorial Description Manual Storage Box Indicates location of operating manual. Hazard Identification Refer to Section 1: Safety Rules. Read and understand the outlined risks associated with this work platform prior to operation.
  • Page 77 Section 5 Labels Labels - Model 6832RTE Front Side Label Pictorial Description Skyjack Logo Skyjack Caution Tape Stripe Caution stripe Harness Anchorage Anchor safety belt/harness tethers here. Maintenance Support Deploy maintenance support here. Rough Terrain Electric Scissors December 2007 Page 77...
  • Page 78 Labels Section 5 Labels - Model 6832RTE Front Side Top View Label Pictorial Description Forklift Pocket Insert fork fully into pocket to lift MEWP . Lift and Tie Down Points Only use these points for lifting or tying down. Serial Plate Product identification and specifications Rough Terrain Electric Scissors Page 78...
  • Page 79 Section 5 Labels Labels - Model 6832RTE Front Side Top View Label Pictorial Description How to engage maintenance support for inspection or maintenance. Refer to Operating manual. 1. Remove all material from platform. 2. Raise platform until there is adequate clearance to swing down maintenance support.
  • Page 80 Labels Section 5 Labels - Model 6832RTE Left Side Label Pictorial Description Skyjack Logo Skyjack Keep Clear Keep clear. Stay away from MEWP when in operation. Caution Tape Stripe Caution stripe Foam-filled Tire Indicates foam-filled tire only. Rough Terrain Electric Scissors...
  • Page 81 Section 5 Labels Labels - Model 6832RTE Left Side Top View Label Pictorial Description Wheel Load Indicates rated wheel load. Wheel Specifications Refer to manual for wheel type, offset, pressure and torque. Forklift Pocket Insert fork fully into pocket to lift MEWP . Emergency Lowering Procedure Refer to Operating manual.
  • Page 82 Labels Section 5 Labels - Model 6832RTE Left Side Label Pictorial Description Model Number* Product Identifier *Model number will vary, may not be as shown. Winching/Towing/Pushing Procedure Refer to Operating manual. 1. Block or chock wheels to prevent aerial platform from rolling. 2.
  • Page 83 Section 5 Labels Labels - Model 6832RTE Left Side Label Pictorial Description Model Number* Product Identifier *Model number will vary, may not be as shown. Railing Pins (Vertical) WARNING! Falling Hazard. Ensure hinged railing is pinned. Connect Air Supply Connect platform air supply here. Rough Terrain Electric Scissors December 2007 Page 83...
  • Page 84 Labels Section 5 Labels - Model 6832RTE Left Side Label Pictorial Description Emergency Lowering Access Rod Secure emergency lowering access rod in place. Rough Terrain Electric Scissors Page 84 December 2007...
  • Page 85 Section 5 Labels Labels - Model 6832RTE Motor/Hydraulic Compartment TF DEXRON III TF DEXRON III ( GM 6137-M ) ( GM 6137-M ) Label Pictorial Description Hydraulic Oil ATF Dexron III Replace hydraulic fluid with ATF Dexron III only. Rough Terrain Electric Scissors December 2007 Page 85...
  • Page 86 Labels Section 5 Labels - Model 6832RTE Back Side Label Pictorial Description Horizontal Load Rating Apply no more than the indicated side load. Operate below indicated wind speed only. Connect Air Supply Connect platform air supply here. Operator’s Daily Inspection Refer to the Operating manual.
  • Page 87 Section 5 Labels Labels - Model 6832RTE Back Side 102896AC 102896AC 124767AB Label Pictorial Description Warning - Do Not Alter Do not alter or disable limit switches or other safety devices. Forklift Pocket Insert fork fully into pocket to lift MEWP . Lift and Tie Down Points Only use these points for lifting or tying down.
  • Page 88 Labels Section 5 Labels - Model 6832RTE Outriggers (If Equipped) Label Pictorial Description Crushing Hazard Danger - Crushing hazard Warning - Do Not Alter Do not alter or disable limit switches or other safety devices. Outrigger Load Indicates rated outrigger load. Rough Terrain Electric Scissors Page 88 December 2007...
  • Page 89 Section 5 Labels Labels - Model 6832RTE Cylinder Main Platform and Extension Platform Label Pictorial Description Orifice Installed Orifice installation warning Harness Anchorage Anchor safety belt/harness tethers here. Rough Terrain Electric Scissors December 2007 Page 89...
  • Page 90 Labels Section 5 Labels - Model 6832RTE Platform Control Console Label Pictorial Description Platform Control Console Squeeze “ ” trigger to enable controller. Operate “ ” rocker switch to steer. Move controller forward “ ” to raise or backward “ ”...
  • Page 91 Section 5 Labels Labels - Model 6832RTE Outrigger Control Console (If Equipped) Label Pictorial Description Manual Outrigger Control Console Select “ ” retract or “ ” extend for each outrigger. Indicates leveling system status: Off: The outriggers are fully retracted. Flashing Rapidly: The outriggers are extending but the platform is not level.
  • Page 92 Labels Section 5 Labels - Model 6832RTE Hybrid Power Pack (HPP) Top View Front View Label Pictorial Description Unleaded Gasoline Use only unleaded gasoline with an octane rating of 87. No Smoking Do not smoke near this location. Lock Pin In Place Ensure HPP is locked in place by inserting the locking pin.
  • Page 93 Notes Rough Terrain Electric Scissors December 2007 Page 93...
  • Page 94 Notes Rough Terrain Electric Scissors Page 94 December 2007...
