SERVICE
MANUAL
SJ6832 RTE
ROUGH TERRAIN SCISSORS
167576AFA
February 2019
AS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SJ6832 RTE and is the answer not in the manual?

Questions and answers

Related Manuals for Skyjack SJ6832 RTE

Summary of Contents for Skyjack SJ6832 RTE

  • Page 1 SERVICE MANUAL SJ6832 RTE ROUGH TERRAIN SCISSORS 167576AFA February 2019...
  • Page 2 This manual is based on Serial Numbers: SJ6832 RTE : 37 300 001 & 37 399 999 Please refer to the website (www.skyjack.com) for contact information, other Serial Numbers, the most recent Technical Manuals and USB software. Original instructions in English.
  • Page 3 It may also be used to alert against unsafe practices. IMPORTANT IMPORTANT indicates a procedure essential for safe operation and which, if not followed, may result in a malfunction or damage to the MEWP . SJ6832 RTE 167576AFA...
  • Page 4 Notes 167576AFA SJ6832 RTE...

  • Page 5: Table Of Contents

    Specifications and Features ............32 SJ6832 RTE...
  • Page 6 Drive and Steer Inoperative (Machines without outriggers option) ......73 4.2-5 Drive and Steer Inoperative (Machines without outriggers option) ......74 167576AFA SJ6832 RTE...
  • Page 7 Reverse Drive Inoperative ............94 SJ6832 RTE...
  • Page 8 4.4-29 Flash Code F32:Reject Curve ........... . . 99 167576AFA SJ6832 RTE...
  • Page 9 Load Sensing System ............. 142 SJ6832 RTE...
  • Page 10 Gate Springe Hinge Adjustment ..........158 167576AFA SJ6832 RTE...

  • Page 11: Section 1 - Scheduled Maintenance

    24 months. Any without notice. defective part will be replaced or repaired by your local SKYJACK dealer at no charge for parts or labor. Contact the SKYJACK Service Department for 1.1-1 Mobile Elevating Work Platform...

  • Page 12: 10 Maintenance And Service Safety Tips

    A very small amount of fine particles is or combustible materials. normal. • Properly dispose of all waste material such as lubricants, rags, and old parts according to the local law provisions in the country of operation. 167576AFA SJ6832 RTE...

  • Page 13: 12 Maintenance Hints

    Air in the system can cause damage to the components and noisy or erratic system operation. SJ6832 RTE 167576AFA...

  • Page 14: 13 Railing Maintenance And Repair

    Section 1 – Scheduled Maintenance Hydraulic System & Component Maintenance and Repair 1.3-2 Railing Maintenance and Repair Skyjack MEWPs have been designed to ensure compliance with the relevant design standards applicable for that particular unit at the time of manufacture. As such, any repairs made to the...
  • Page 15 Notes SJ6832 RTE 167576AFA...

  • Page 16: Service And Maintenance

    Before performing any scheduled maintenance inspection procedure, check for any service bulletins Frequent Perform Frequent Inspection related to service and maintenance of this aerial every 3 months or 150 hours. platform at: www.skyjack.com. Annual Perform Scheduled Maintenance Inspections every year. 1.4-3 Maintenance and Inspection...

  • Page 17: Owner's Annual Inspection Record

    Figure 01 This decal is located on the scissor assembly. It must be completed after an annual inspection has been completed. Do not use the MEWP if an inspection has not been recorded in the last 13 months. Description Label Pictorial Description Label Pictorial Inspector Inspection Date Signature SJ6832 RTE 167576AFA...
  • Page 18 Owner: ________________________________________________ / _____________________________________________ / ______________________________________________________ Print Name Signature Date (DD/MM/YY) User: _________________________________________________ / _____________________________________________ / _______________________________________________________ Print Name Signature Date (DD/MM/YY) 167830AC Note: Visit skyjack.com for a printable copy of this form. 167576AFA SJ6832 RTE...

  • Page 19: Service And Maintenance Inspections

    Hydraulic Refer to the labels section in the operating manual Maintaining the hydraulic components is essential to and determine that all labels are in place and are good performance and service life of the MEWP legible. SJ6832 RTE 167576AFA...

  • Page 20: Limit Switches (B)

    2. Clean battery terminals and cable ends Base Control Switches thoroughly with a terminal cleaning tool or wire Ensure there are no signs of visible damage ▪ brush. and all switches are in their neutral positions. 3. Ensure all battery connections are tight. 167576AFA SJ6832 RTE...
  • Page 21 Ensure there are no loose wire connections or ▪ WARNING missing fasteners. Use original or manufacturer-approved parts and components for the aerial platform. • Load Sensor Ensure load sensor is properly secured and there is no visible damage. SJ6832 RTE 167576AFA...

  • Page 22: Compartment

    Ensure there are no loose or missing parts ▪ Component Maintenance and Repair. and there is no visible damage. Hydraulic Return Filter Ensure filter element is secure. ▪ Ensure there are no signs of leakage or visible ▪ damage. 167576AFA SJ6832 RTE...

  • Page 23: Platform Assembly

    ▪ visible damage. AC Outlet on Platform Ensure outlet has no visible damage and free ▪ from dirt or obstructions. Platform Control Console Ensure all switches and controller are returned ▪ to neutral and are properly secured. SJ6832 RTE 167576AFA...

  • Page 24: Lifting Mechanism

    Ensure all pins are properly secured. ▪ Ensure cables and wires are properly routed ▪ and shows no signs of wear and/or physical damage. Scissor Bumpers Ensure bumpers are secure and shows no sign ▪ of visible damage. 167576AFA SJ6832 RTE...
  • Page 25 Retainer bolts / pin retainer are in place ▪ Center pin pivot – Outer Pin retainer in place Center pin pivot – Middle No rust. Pin has not rotated. Area is clean of dust/metal shavings Center pin pivot – Inner SJ6832 RTE 167576AFA...
  • Page 26 Any units with structural damage to any pin connection or scissor arm must be immediately removed from service and repaired by a qualified technician. Contact Skyjack Service for repair instructions. Lift Cylinders Ensure each lift cylinder is properly secured, ▪...

  • Page 27: Base

    Replace tires with the exact, tipping over. Component damage may also result if Skyjack-approved types only. problems are not discovered and repaired in a timely fashion. Axles Check all tire treads and sidewalls for cuts, ▪...
  • Page 28 Ensure there are no loose wire connections or missing fasteners. Tie Rod Ensure there are no loose or missing parts, tie rod end studs are locked and there is no visible damage. 167576AFA SJ6832 RTE...

  • Page 29: 10 Function Tests

    For function test that are to be run, please refer to the operating manual that corresponds to the correct serial number. Found there will be detailed instructions for which tests to perform, as well as how to properly and successfully perform them. SJ6832 RTE 167576AFA...
  • Page 30 Notes 167576AFA SJ6832 RTE...

  • Page 31: Section 2 - Maintenance Tables And Diagrams

    Section 2 – Maintenance Tables and Diagrams SJ6832 RTE 167576AFA...

  • Page 32: Specifications And Features

    Elevated Drive 0.63 km/h Lift (Rated Load) 39 sec Lower (Rated Load) 36 sec Foam-filled OTR Outrigger - 30.5 x 66 cm Gradeability (Torque Equivalent To) 1125AB_AS Weights are approximate; refer to serial nameplate for specific weight. 167576AFA SJ6832 RTE...

  • Page 33: Floor Loading Calculation

    Do not use tires other than those specified for this machine. Do not mix different types of tires. Tires other than those specified can adversely affect stability. Failure to operate with matched, approved tires in good condition can result in death or serious injury. Replace tires with the exact, Skyjack-approved types only.w SJ6832 RTE 167576AFA...

  • Page 34: Floor Loading Pressure

    (beams, etc.) must be able to withstand more than the indicated values above. NOTE: The LCP or OUP that an individual surface can withstand varies from structure to structure and is generally determined by the engineer or architect for that particular structure. 167576AFA SJ6832 RTE...

  • Page 35: Maximum Platform Capacities (Evenly Distributed)

    Refer to capacity label for additional information and for models equipped with options. 2.1-4 Fluids Table Hydraulic Oil Type Model Capacity (Liters) Capacity Gallons)   III ATF  Dexron SJ68XXRT 86.88 22.95 Shell Naturelle HF-E 32 (Bio oil) 60662AB SJ6832 RTE 167576AFA...

  • Page 36: Torque Specifications

    110 - 115 (242 Loctite) 149 -156 bolts Hydraulic drive motor mounting bolts (Front) Hydraulic drive motor mounting bolts (Rear) Positive battery post cable/fuse nut 7.5 (90 in-lb) 10.2 Newton-meter = Nm Foot-Pound Force = ft-lb Inch-Pound Force = in-lb 1504AA 167576AFA SJ6832 RTE...

  • Page 37: Torque Specifications For Fasteners (Imperial)

    1460 3160 2360 1 1/2-6 ft-lb 1180 2630 1979 4284 3200 1/2-20 ft-lb 2200 1640 3560 2660 1 1/2-12 1329 2983 2224 4827 3606 NOTE: Lubed includes lubricants such as lubrizing, oil, grease, or uncured Loctite. 1374AA SJ6832 RTE 167576AFA...

  • Page 38: Torque Specifications For Fasteners (Metric)

    1468 1101 2101 1576 M33 x 3.50 1990 1493 2849 2137 ft-lb 1886 1415 2699 2024 M36 x 4.00 2557 1918 3659 2744 NOTE: Lubed includes lubricants such as lubrizing, oil, grease, or uncured Loctite. 1375AA 167576AFA SJ6832 RTE...

  • Page 39: Torque Specifications For Hydraulic Couplings & Hoses

    Min. Max. Min. Max. Min. Max. Min. Max. 1/4" 6.75 1/4" 3/8" 3/8" 1/2" 27.66 1/2" 5/8" 46.33 5/8" 3/4" 72.33 3/4" 1" 100.5 1" 1 1/4" 101.5 1 1/4" 1 1/2 1 1/2 2" 2" 1276AA SJ6832 RTE 167576AFA...
  • Page 40 Notes 167576AFA SJ6832 RTE...

  • Page 41: Section 3 - System Component Identification And Schematics

    Section 3 – System Component Identification and Schematics SJ6832 RTE 167576AFA...

  • Page 42: Hydraulic Symbol Chart

    THREE POSITION THREE POSITION TWO POSITION TWO POSITION FOUR WAY FOUR WAY TWO WAY THREE WAY CLOSED CENTER PROPORTIONAL NORMALLY CLOSED PORT OPEN VARIABLE PRESSURE DISPLACEMENT PILOT LINES Dashed MAIN LINES Solid TRANSDUCER HYDRAULIC MOTOR QUICK SERVO DISCONNECT 167576AFA SJ6832 RTE...

  • Page 43: Electrical Symbol Chart

    SINGLE POLE POTENTIOMETER SINGLE THROWN LEVEL SENSOR TRANSISTOR RELAY DOUBLE POLE SINGLE POLE DOUBLE POLE DOUBLE THROW DOUBLE THROW SINGLE THROW TRANSISTOR RELAY RELAY RELAY PRESSURE/ TRIPLE POLE TRANSISTOR VACUUM DIODE DOUBLE THROW SWITCH RELAY TEMPERATURE SWITCH SJ6832 RTE 167576AFA...

  • Page 44: Ac Cord Color Code

    (Battery Charger & Platform AC Outlet) Standard Definition NEC Colors IEC Colors Protective Ground/ Protective Earth Green Green-Yellow Neutral White Blue Line, Single Phase Black Black or Brown or Grey Note: Standard colors referenced from IEC 60445:2010, Annex A: Table A.1 167576AFA SJ6832 RTE...

  • Page 45: Hydraulic Schematic Parts List

    VALVE, Check 104624 VALVE, Check 104624 VALVE, Pilot check 104624 VALVE, Pilot check 104624 VALVE, Pilot check 104624 VALVE, Pilot check 104115 VALVE, Pilot check 104115 VALVE, Pilot check 104115 VALVE, Pilot check CV10 104115 VALVE, Pilot check SJ6832 RTE 167576AFA...
  • Page 46 TRANSDUCER, Pressure (3000 psi) 104534 VALVE, Relief (system) 104534 VALVE, Relief (lift) 106557 VALVE, Relief (lift cylinder) 106557 VALVE, Relief (lift cylinder) 139683 VALVE, Relief (drive) 107271 VALVE, Pull (emergency lowering) 137182 VALVE, Freewheel 113752 VALVE, Auto reset (brake) 167576AFA SJ6832 RTE...

  • Page 47: Electrical Parts List

    RELAY, 12 Volt (40 Amp) (Outrigger lift enable) 106CR 127035 RELAY, 12 Volt (40 Amp) (Generator running) 2H-13 104410 COIL, 12 Volt (Lowering valve) 2H-13-1 104410 COIL, 12 Volt (Lower lift cylinder holding valve) 2H-13-2 103613 COIL, 12 Volt (Upper lift cylinder holding valve) SJ6832 RTE 167576AFA...
  • Page 48 LIMIT SWITCH (Rear right outrigger retracted) LS64 138060 LIMIT SWITCH (Rear left outrigger retracted) LS65 138059 LIMIT SWITCH (Front left outrigger extended) LS66 138059 LIMIT SWITCH (Front right outrigger extended) LS67 138059 LIMIT SWITCH (Rear right outrigger extended) 167576AFA SJ6832 RTE...
  • Page 49 SWITCH, Toggle (Rear right outrigger up/down) S22A 127132 SWITCH, Rear right outrigger rocker 102853 SWITCH, Toggle (Rear left outrigger up/down) S23A 127132 SWITCH, Rear left outrigger rocker 102853 SWITCH, Auto-level outrigger 146661 TILT SWITCH 167234 DISPLAY, Hour/error 167415 VOLTMETER (Control box) SJ6832 RTE 167576AFA...

  • Page 50: Hydraulic Schematic

    3.6 Hydraulic Schematic M167693AD SJ6832 RTE 167576AFA...

  • Page 51: Main Manifold Component And Port Identification

    RELIEF PUMP CYLINDER CYLINDER VALVE AUTO 2H-18B (ANSI/CSA) RESET 2H-18C (CE) VALVE SMALL PUMP DUMP VALVE TANK DRAIN CHECK SYSTEM 3H-14A EMERGENCY 4H-23 VALVE RELIEF LOWERING LIFT RIGHT STEER VALVE VALVE PULL VALVE VALVE MAIN MANIFOLD M138189AP_3C SJ6832 RTE 167576AFA...

  • Page 52: Splitter And Outrigger Manifolds Component And Port Identification

    OUTRIGGER RIGHT REAR 4H-75A RETRACT OUTRIGGER LEFT FRONT EXTEND 2H-17C OUTRIGGER HOLDING 4H-76A VALVE OUTRIGGER 4H-77A RIGHT FRONT OUTRIGGER RIGHT REAR EXTEND EXTEND CHECK VALVE CHECK VALVE CHECK VALVE SPLITTER MANIFOLD OUTRIGGER OUTRIGGER MANIFOLD CYLINDER M138075AE, M138045AB_1 SJ6832 RTE 167576AFA...

  • Page 53: Control Box Wiring Diagram

    PIN 5 - JOYSTICK VS+ 08 BLUE GREY PIN 6 - REV/DOWN PURPLE/WHITE BLUE PIN 7 - PWM 59 ORANGE/BLACK BLACK PIN 8 - GND 02 WHITE JOYSTICK HARNESS 8A BLUE WHITE/ BLUE PIN 9 - ENABLE VS+ CRD1 M167350AA SJ6832 RTE 167576AFA...

  • Page 54: Beeper Assembly Wiring Diagram

    3.10 Beeper Assembly Wiring Diagram Light / Beeper Harness Transducer Harness M208726AA SJ6832 RTE 167576AFA...

  • Page 55: Outrigger Control Box Wiring Diagram

    PIN 13 - 79 GREEN OUTR LIGHT BLUE/WHITE & GREEN/WHITE) PIN 14 - 35C BLUE/WHITE 70A RED/WHITE PIN 3 - 35D PURPLE/WHITE PIN 15 - 35C GREEN/WHITE 02 WHITE OUTRIGGER CTRL CABLE 10 11 13 14 M129300AB3 SJ6832 RTE 167576AFA...

  • Page 56: Scissor Arm Control Cable Writing Diagram

    PIN 19 - RED WHITE (85A) PIN 20 - GREEN BLACK (3B) PIN 21 - GREEN WHITE (B-) PIN 22 - GREEN (49) PIN 23 - ORANGE GREEN (60) PIN 24 - RED BLACK WHITE (85) M167365AA_1 SJ6832 RTE 167576AFA...

  • Page 57: Main Manifold Harness Writing Diagram

    20A - BLACK/RED/WHITE 02 - WHITE INSERT ORIENTATION BOTTOM VIEW HOLDING VALVE 13 - ORANGE (ANSI/CSA), 13B - ORANGE (CE) 02 - WHITE REVERSE VALVE GREY HIRSHMAN PIN 1 - 15 BLUE PIN 2 - 02 WHITE M167290AC SJ6832 RTE 167576AFA...

  • Page 58: Main Manifold Harness Wiring Diagram - Soft Stop

    02 - WHITE INSERT ORIENTATION BOTTOM VIEW HOLDING VALVE 13B - ORANGE 02 - WHITE REVERSE VALVE GREY HIRSHMAN PIN 1 - 15 BLUE PIN 2 - 02 WHITE SOFT STOP VALVE 13C - ORANGE 02 - WHITE M167290AC SJ6832 RTE 167576AFA...

  • Page 59: Outrigger Harness Wiring Diagram

    LEFT REAR OUTRIGGER: PIN 13 - 79 GREEN PIN 1 - BLACK (10A) PIN 2 - WHITE (68A) PIN 14 - 35C WHITE PIN 3 - GREEN (10A) PIN 4 - RED (64) PIN 15 - 35C GREEN M167639AA SJ6832 RTE 167576AFA...

  • Page 60: Motor Controller Electrical Schematic (With Gasoline Hpp)

    Red/Green INPUT AUX/COMMON 110V AC AC GND MOTOR AUX/N.O. AUX/N.C. Line Contactor DC/DC Converter 48V - 12V Common Negative PANEL CONNECTOR A PANEL CONNECTOR B PANEL CONNECTOR C PANEL CONNECTOR B PANEL CONNECTOR D CAN M.D.I M167787AB-2 SJ6832 RTE 167576AFA...

  • Page 61: Motor Controller Electrical Schematic (With Diesel Hpp)

    3.17 Motor Controller Electrical Schematic (with Diesel HPP) M170509AC-2 SJ6832 RTE 167576AFA...

  • Page 62: Hybrid Power Pack Wiring (With Gasoline Hpp)

    PIN 7: G1 - BLACK/WHITE PIN 6: G1 - BLACK PIN 8: L2 - WHITE PIN 7: G1 - BLACK/WHITE PIN 9: L2 - WHITE/BLACK PIN 8: L2 - WHITE PIN 9: L2 - WHITE/BLACK M167653AB, M168037AB, M168038AB, M168041AB_1, M169485/7_1 SJ6832 RTE 167576AFA...

  • Page 63: Hybrid Power Pack Wiring (With Diesel Hpp)

    3.19 Hybrid Power Pack Wiring (with Diesel HPP) (TO CHARGER RELAY - 3 WIRES) PIN 1: L1 - BROWN PIN 2: L2 - BLUE PIN 3: G - YELLOW/GREEN M170215AC SJ6832 RTE 167576AFA...

  • Page 64: Electrical Panel Wiring Diagram S/N 37300218 & Above

    3.20 Electrical Panel Wiring Diagram S/N 37300218 & above Serial Breakdown Reference Chart Model Serial Number SJ68RTE 37300218 & above M204732AB SJ6832 RTE 167576AFA...

  • Page 65: Electrical Panel Wiring Diagram S/N 37300217 & Below

    PIN 9 - N/U GREEN/WHITE (B-) (10) BLUE/RED PIN 10 - 35B RED/BLACK GREEN (49) (13) ORANGE PIN 11 - 02 WHITE ORANGE/GREEN (60) (14) BLACK PIN 12 - 10A BLUE/BLACK (15) BLUE RED/BLACK/WHITE (85) CRD3 M167283AD_1 SJ6832 RTE 167576AFA...

  • Page 66: Electrical Panel Wiring Diagram - Soft Stop

    PIN 9 - N/U (10) BLUE/RED GREEN/WHITE (B-) PIN 10 - 35B RED/BLACK (13) ORANGE GREEN (49) PIN 11 - 02 WHITE (14) BLACK ORANGE/GREEN (60) PIN 12 - 10A BLUE/BLACK (15) BLUE RED/BLACK/WHITE (85) CRD3 M210248AB SJ6832 RTE 167576AFA...

  • Page 67: Electrical Schematic - All Options (With Gasoline Hpp)

    3.23 Electrical Schematic – All Options (with Gasoline HPP) Refer to 3.16 Motor Controller Electrical Schematic (with Gasoline HPP). PANEL CONNECTOR A PANEL CONNECTOR B HPP+ HPP- HPP ENGINE START HPP BATT. 104A 104A HPP OFF HPP BATT. GND HPP 12V M167787AB-1 SJ6832 RTE 167576AFA...

  • Page 68: Electrical Schematic - All Options (With Diesel Hpp)

    PANEL CONNECTOR B D57E HPP ENGINE START D57L HPP BATT + D57H HPP KEY ON HPP BATT - D106 106C 106C HPP ALTERNATOR ALTERNATOR 4 ALTERNATOR 3 ALTERNATOR 2 ALTERNATOR 1 CHARGER PRIORITY RELAY 110/220V INPUT M170509AB-1 SJ6832 RTE 167576AFA...
  • Page 69 Notes 167576AFA SJ6832 RTE...

  • Page 70: Section 4 - Troubleshooting Information

    “probable cause.” The information in the right-hand column, in bold text, represents the “remedy” to the “probable cause” directly beside it. See the example below for clarification. 1. Probable cause Remedy SJ6832 RTE 167576AFA...

  • Page 71: Electrical System

    S6. 19. Defective base emergency stop switch S6. Check switch. Replace if defective. 20. Loose or broken wire #5 from base emergency Check continuity. Replace if defective. stop switch S6 to base terminal block TB-1. 167576AFA SJ6832 RTE...

  • Page 72: No Power To Platform

    TB-1. 3. Loose or broken wire #07 from base terminal Check continuity. Replace if defective. block TB-1 to platform emergency stop switch S4. 4. Open or defective platform emergency stop switch Check switch. Replace if defective. SJ6832 RTE 167576AFA...

  • Page 73: All Functions Inoperative From The Platform

    Check continuity. Replace if defective. S3 to steer switches S7-2 and S7-3. 7. Open diode D12B. Check diode. Replace if defective. 8. Loose or broken wire #10A from base terminal Check continuity. Replace if defective. block to tilt switch TS1. 167576AFA SJ6832 RTE...

  • Page 74: Drive And Steer Inoperative (Machines Without Outriggers Option)

    Check continuity. Replace if defective. pin #P3-4 to outrigger connector CN14 at pin #7. 11. Left rear outrigger limit switch LS64 is out of Check continuity through switch. Adjust switch if adjustment or defective. out of adjustment. Replace if defective. SJ6832 RTE 167576AFA...

  • Page 75: Brakes Does Not Release

    6. Open diode D23. Check diode. Replace if defective. 7. Loose or broken wire #30A from base terminal Check continuity. Replace if defective. block TB1 to relay 30CR. 8. Defective steer enable relay 30CR. Check relay. Replace if defective. 167576AFA SJ6832 RTE...

  • Page 76: Reverse Drive Inoperative

    Lift/Drive select switch between wire Check continuity. Replace if defective. #A and wire #15. 4. Loose or broken wire #15 from Lift/Drive select Check continuity. Replace if defective. switch S3 to reverse valve coil 4H-15. SJ6832 RTE 167576AFA...
  • Page 77 9. Loose or broken wire #02 from base terminal block TB1 to parallel forward valve coil 4H-16A (in Check continuity. Replace if defective. parallel drive only). 10. Defective parallel forward valve coil 4H-16A (in Check coil. Replace if defective. parallel drive only). 167576AFA SJ6832 RTE...

  • Page 78: 11 High Drive Speed Inoperative

    Check continuity. Replace if defective. block TB1 to enable relay 28BCR. 15. Loose or broken wire #02 from relay 28BCR to Check continuity. Replace if defective. base terminal block. 16. Defective relay 28BCR. Check relay. Replace if defective. SJ6832 RTE 167576AFA...

  • Page 79: 13 Up Circuit Inoperative From Base Control Console

    Check continuity. Replace if defective. outrigger limit switch LS63. 7. Defective outrigger limit switch LS63. Check continuity. Replace if defective. 8. Loose or broken wire #63 from outrigger limit Check continuity. Replace if defective. switch LS63 to outrigger board. 167576AFA SJ6832 RTE...

  • Page 80: 15 Platform Does Not Lift From Platform Or Base Control Console With Outriggers Retracted (Lift Operates Correctly With Outriggers Extended)

    Check continuity. Replace if defective. to outrigger limit switch LS67. 7. Defective outrigger limit switch LS67. Check switch. Replace if defective. 8. Loose or broken wire #67A from outrigger limit Check continuity. Replace if defective. switch LS67 to outrigger board. SJ6832 RTE 167576AFA...

  • Page 81: 16 Platform Does Not Lift From Platform Or Base Control Console With Outriggers Extended

    7. Loose or broken wire #36A from pin#10 on Check continuity. Replace if defective. connector CN14 to up relay 14CR. 8. Loose or broken wire #14A from up relay 14CR to Check continuity. Replace if defective. base terminal block TB1. 167576AFA SJ6832 RTE...

  • Page 82: Retracted

    6. Defective lowering valve coil 2H-13B or holding valve Check Coil. Replace if defective. 2H-13B-1 and 2H-13B-2. 7. Loose or broken wire #13 from base terminal block to Check continuity. Replace if defective. over load module CM1 at pin #P2-4. SJ6832 RTE 167576AFA...

  • Page 83: 18 Down Circuit Inoperative From Platform

    2. Loose or broken wire #35D from outrigger enable switch S9A to pin #5 on the outrigger control console Check for continuity. Replace if defective. plug. 3. Defective outrigger enable switch S9A. Check switch. Replace if defective. 167576AFA SJ6832 RTE...

  • Page 84: 22 All Outriggers Inoperative (Base Controls Only)

    Check for continuity. Replace if defective. module OCM1. 4. Loose or broken wire #02 at pin #3 of the tilt switch Check for continuity. Replace if defective. connector to base terminal block TB1. 5. Defective outrigger control module OCM1. Replace. SJ6832 RTE 167576AFA...

  • Page 85: 21 All Outriggers Inoperative (Auto-Level And Manual From Platform Controls)

    If problem persists, replace outrigger control module. Internal failure of OCM1. Turn off power to reset the outrigger control module. Turn power back on and see if the code has cleared. If problem persists, replace outrigger control module. 60416AB 167576AFA SJ6832 RTE...

  • Page 86: 24 All Outriggers Inoperative (Auto Level Only)

    S22A at base control console. 2. Loose or broken wire #73(up) from outrigger control console to pin #3 (up) on connector CN20 Check continuity. Replace if defective. at outrigger board, or wire #77 (down) to pin #4 (down). SJ6832 RTE 167576AFA...

  • Page 87: 25 Left Front Outrigger Inoperative Manually

    4.2-27 Auto-Level Inoperative 1. Loose or broken wire #35D from outrigger enable Check continuity. Replace if defective. switch S9A to auto mode outrigger switch S24. 2. Defective auto mode outrigger switch S24. Check switch. Replace if defective. 167576AFA SJ6832 RTE...

  • Page 88: 28 Left Rear Outrigger Inoperative Manually

    Turn switch to manual position. 3. Base HPP Manual/Auto switch S11 in the auto Turn switch to manual position. position. 4. No battery negative output on wire #85 from DC/DC Check continuity. Replace if defective. converter to platform HPP switch S13. SJ6832 RTE 167576AFA...

  • Page 89: 32 Hybrid Power Pack (Gasoline) Does Not Start - Manual Mode

    90% of charge. 1. No negative input on wire #86 from Manual/Auto Check continuity. Replace if defective. switch S11 to motor controller pin #A13. 2. Defective base Manual/Auto switch S11. Check switch. Replace if defective. 167576AFA SJ6832 RTE...

  • Page 90: 33 Hybrid Power Pack (Gasoline) Does Not Start - Auto Mode

    Check continuity. Replace if defective. converter to platform HPP switch S13. 5. Defective platform HPP switch S13. Check switch. Replace if defective. 6. Loose or broken wire #85A from switch S13 to base Check continuity. Replace if defective. HPP switch S12. SJ6832 RTE 167576AFA...

  • Page 91: 35 Hybrid Power Pack (Gasoline) Does Not Shut Off

    Check continuity. Replace if defective. panel. 24. Defective HPP circuit breaker CB3. Check circuit breaker. Replace if defective. 25. No fuel. Check fuel level. Add as required. 4.2-34 Hybrid Power Pack (Diesel) does not Shut Off – Auto mode 167576AFA SJ6832 RTE...

  • Page 92: 37 Hybrid Power Pack (Diesel) Does Not Shut Off - Auto Mode

    Auto mode to work. 1. Hydraulic oil level low. Refill tank to proper level. 2. Defective pump P1. Check pump. Repair or replace if defective. 3. Broken engine to pump coupler. Check coupler. Replace if defective. SJ6832 RTE 167576AFA...

  • Page 93: Hydarulic System

    Close valve. Repair or replace if defective. 6. Stuck or defective high speed valve 2H-20B. Check valve. Repair or replace if defective. 7. Cushion cylinder C8 bypassing internally. Check cylinder. Repair or replace if defective. 4.3-6 Drive Sluggish 167576AFA SJ6832 RTE...

  • Page 94: Reverse Drive Inoperative

    1. Stuck or defective lowering valve 2H-13. Check valve. Repair or replace if defective. 2. Stuck holding valve 2H13-1 or 2H13-2. Check valves. Repair or replace if defective. 3. Plugged lowering orifice O1. Clean or replace orifice. SJ6832 RTE 167576AFA...
  • Page 95 1. Defective check valve left front CV7, right front CV8, right Clean valve. Replace if defective. rear CV9 or left rear CV10. 2. Outriggers cylinder bypassing left front C9, right front Repack cylinder. Replace if defective. C10, right rear C11 or left rear C12. 167576AFA SJ6832 RTE...

  • Page 96: Load Sensing System

    4.0 V. Check DIAGNOSTICS / SENSORS to see P4-3 is out of range at the end of the DYNAMIC lift. the output. A reading of 0 V or 5 V is probably due to a wiring problem. SJ6832 RTE 167576AFA...
  • Page 97 (below 5%). Check CALIBRATIONS / HEIGHT CALS; the ElevUp value shows the recorded height where the switch opened. 4.4-16 Flash Code F17: High Elev.open 167576AFA SJ6832 RTE...
  • Page 98 4. This message occurs if the platform height is not The platform must be at 100% height when it is 100% before the platform is lowered during either fully raised. Check DIAGNOSTICS / SYSTEM to STATIC lift. check the height. SJ6832 RTE 167576AFA...
  • Page 99 There should be a lowest pressure about halfway through the lift (i.e.: near 50% height); 2. The DYNAMIC pressure curve is unacceptable. the lowest pressure measured is at too low a height.. Check the pressure sensor and lift cylinder hydraulics. 167576AFA SJ6832 RTE...

  • Page 100: 30 Flash Code F33:Reject Curve

    1. This message indicates that the pressure is too low sensor was disconnected, or if there were (0.5 V or less) at a STATIC measurement point. some other wiring error. Check DIAGNOSTICS / SENSORS to check the pressure. SJ6832 RTE 167576AFA...

  • Page 101: 36 Flash Code F45:High Pressure

    1. This message indicates that the elevation switch opened more than once during the DYNAMIC lift. 4.4-38 Flash Code F47:Check Elev 1. This message indicates that the elevation switch closed more than once during the DYNAMIC lower. 167576AFA SJ6832 RTE...

  • Page 102: Section 5 - Procedures

    2/sec. When pushing, towing or winching, do not exceed 2 mph (3.2 km/h). Do not push, tow or winch vehicle on to a slope, or brake the towing vehicle rapidly. Do not pull the aerial platform down an incline towards a winch.. SJ6832 RTE 167576AFA...

  • Page 103: Wheel Bolt / Nut Inspection And Torquing Procedure

    7. Position the machine on a firm and level surface. 8. Chock or block the wheels to prevent the aerial platform from rolling. 9. Re-engage the parking brakes by pulling out the black brake valve plunger. 5.2-2 Wheel Bolt / Nut Inspection and Torquing Procedure 167576AFA SJ6832 RTE...

  • Page 104: Wheel Reinstallation And Torquing Procedure

    90 ft·lb, repeat complete sequence until there is no change in torque values. If possible, drive the machine prior to checking torques. 8. Check torque values after 8 hours of operation and then at weekly intervals. SJ6832 RTE 167576AFA...

  • Page 105: Reconnecting The Platform Control Box For Use From The Ground

    7. Plug the control box control cable connector in its place. Push down the latch to lock them together. 4. Bring the control box down from the platform to the ground. 5. Locate the control cable connectors inside the electrical cabinet. 167576AFA SJ6832 RTE...

  • Page 106: Tightening And Torque Recommendations For Hydraulic Couplings And Hoses

    / crow’s foot tools. 2. Over-tightening a coupling may result in 2. Align the hose end or fitting to the mating overstressing and/or cracking, and may lead to component. leaking or failure. SJ6832 RTE 167576AFA...
  • Page 107 FFWR chart above). Apply a drop of torque seal to the connection. 6. Referencing the chart below, use a second box wrench to tighten the nut the appropriate number of flats past the mark. Do NOT over tighten. 167576AFA SJ6832 RTE...

  • Page 108: Checking The Holding Valve

    10. Remove the pressure gauge and reconnect relief valve disconnect fitting the control box to the platform. 4. With the engine on, use the control box joystick to steer fully left or right to produce pressure. Read the pressure on the gauge. SJ6832 RTE 167576AFA...

  • Page 109: Lift Pressure Setting

    11. Reconnect the lift hose to the main manifold lift port (refer to 5.2-5 Tightening and Torque Recommendations for Hydraulic Couplings and Hoses). 12. Remove the pressure gauge and reconnect the control box to the platform. 167576AFA SJ6832 RTE...

  • Page 110: Grease Points

    On each outrigger foot (1 fitting per 4. Disconnect the grease gun. outrigger, if equipped, 4 per unit). 5. Wipe off any excess grease from around the joint or bearing, and from the grease fitting. 6. Replace the grease fitting cap. SJ6832 RTE 167576AFA...

  • Page 111: 10 Electronic Tilt Switch Setup Procedure

    3. Chock or block wheels to keep the aerial stays on for 2 seconds indicating the switch is platform from rolling forward or backward. verifying the new zero position. 4. Push in emergency stop buttons and turn main power disconnect switch off. 167576AFA SJ6832 RTE...
  • Page 112 7. Verify switch is powered. The red and green LED indicator lights should be flashing. 8. On the back side of the switch, press and hold the Set-up button for 3 seconds. LED Indicator Lights Set-up Button M62332AA SJ6832 RTE 167576AFA...
  • Page 113 The switch does not function. Green and Red After a period of 5 seconds LEDs on or on power up, the switch attempts to return to normal operation. If the fault is still detected, both LEDs remain 167576AFA SJ6832 RTE...

  • Page 114: Electrical Cabinet

    Pin 13 - Platform/ Base select input. 2B active= Base mode. Test for continuity between pin 13 and battery negative while in base mode. ▪ Pin 14 - 12 volt input on wire 17B. Outrigger Enable signal. Test between pin 14 and 02 wire. ▪ SJ6832 RTE 167576AFA...

  • Page 115: Motor Controller Panel Pin Interface - Hybrid Power Pack (Gasoline)

    Wire 57B - 12 volt output from HPP to HPP start relay 10CR1. Wire 57A - 12 volt output from HPP start relay 10CR1 to HPP starter. Wire L2 - External VAC input. Wire G1 - External VAC input. 167576AFA SJ6832 RTE...
  • Page 116 Wire 57K - 12 volt input for start and run circuit. Wire 57B - 12 volt output from HPP to HPP start relay 10CR2. Wire 57A - 12 volt output from HPP start relay 10CR2 to HPP starter. SJ6832 RTE 167576AFA...
  • Page 117 The codes tables contain the flash codes, the probable cause and the recommended remedy. If the Alarm information suggests a serious problem that can not be addressed by the codes tables, contact Skyjack Service Department. 167576AFA...

  • Page 118: Mdi-Can Controller Master Codes

    ACE3. Troubleshooting of fault displayed during motor driving: - If the alarm happens during traction acceleration or driving hydraulic functions, check battery charge condition, power cable connection. SJ6832 RTE 167576AFA...

  • Page 119: Troubleshooting

    - Make sure motor windings/ motor cables do not have leakage to chassis - Make sure line contactor closes properly and is making good contact. If no problem is found in the connections/ cables or line contactor, it is a fault internal to the ACE3. Replace ACE3. 167576AFA SJ6832 RTE...
  • Page 120 - It could be a problem of the contacts in the Line Contactor that 05A38 CONTACTOR OPEN damaged are not working (does not pull-in), try replacing the Line Contactor. - If the contactors of Line Contactor are working correctly than the problem is in the controller, replace ACE3. SJ6832 RTE 167576AFA...
  • Page 121 2. Check battery and motor cables Cause: The output of the controller thermal sensor is out of range. 05A61 THERMIC SENS. KO ACE3 Controller Troubleshooting: This type of fault is not related to external components; replace the ACE3. 167576AFA SJ6832 RTE...
  • Page 122 This code is displayed when the coil of the line contactor is Check the Line Contactor shorted or the wiring to the coil is shorted. Check coil and wiring. 05A76 MC COIL SHOR. coil If error code remains it is an internal fault in the controller. Replace ACE3. SJ6832 RTE 167576AFA...
  • Page 123 1. Cycle keyswitch Internal ACE3 Controller 05A89 POWERMOS SHORTED 2. Factory reset (Clear Eeprom) check 3. Replace ACE3 1. Cycle keyswitch Internal ACE3 Controller 05A90 VDC OFF SHORTED 2. Factory reset (Clear Eeprom) check 3. Replace ACE3 167576AFA SJ6832 RTE...
  • Page 124 Factory reset, (Clear Eeprom) version 1. Cycle keyswitch 05A98 TORQUE PROFILE Wrong settings 2. Factory reset (Clear Eeprom) 3. Replace ACE3 Communication problem 1. Check the connections between MDI-CAN and controller. NO COMMUNICATION 16A06 with Traction Controller. 2. Replace MDI. SJ6832 RTE 167576AFA...
  • Page 125 Slave μC wrong setpoint. 05B21 SP MISMATCH XX ACE3 Internal check 1. Cycle keyswitch 2. Factory reset (Clear Eeprom) 3. Replace ACE3 1. Cycle keyswitch 05B22 INPUT MISMATCH ACE3 Internal check 2. Factory reset (Clear Eeprom) 3. Replace ACE3 167576AFA SJ6832 RTE...
  • Page 126 If the problem occurs permanently it is necessary to Replace ACE3. This fault is displayed when the controller 1. Cycle keyswitch detects a wrong value in CTRAP THRESHOLD 2. Factory reset (Clear Eeprom) 05B99 the feedback for 3. Replace ACE3 overcurrent protection circuit. SJ6832 RTE 167576AFA...

  • Page 127: Zivan Sg3 Battery Charger And Fault Codes

    Overcharging phase (IUla) Red and green alternated Wait phase (for equalization) (IUla) Green End charge Blinking green (4s ON – 1s OFF) Equalization pulse and floating Green and red blinking together Connection with CanConSolle or S/S HW- 167576AFA SJ6832 RTE...

  • Page 128: Sg3 Charger Setup

    This alarm has a in the Charger. Change the SG3. blocking behaviour in order to protect the battery from being charged improperly. When this alarm clears, the charger resumes the charge from the point it was interrupted. SJ6832 RTE 167576AFA...
  • Page 129 (or eventually the number of slave devices, if there are any). The battery supplied with the charger has an expected service life of 5 years. 167576AFA SJ6832 RTE...

  • Page 130: Outriggers

    Outriggers Section 5 – Procedures 5.4 Outriggers 5.4-1 Auto-Leveling Outrigger PC Board Layout CN14 CN21 CN20 9CR3 9CR2 61CR 17DCR 65CR ENABLE CN22 SJ6832 RTE 167576AFA...

  • Page 131: Outrigger Mechanical Limit Switch Wiring Diagram

    O.R. DOWN SWITCH (NC) - BLACK & BLACK / WHITE O.R. DOWN SWITCH (NC) - BLACK & BLACK / WHITE LEFT REAR OUTRIGGER SECTION VIEW RIGHT REAR OUTRIGGER SECTION VIEW (SHOWN IN THE RETRACTED STATE) (SHOWN IN THE RETRACTED STATE) 167576AFA SJ6832 RTE...

  • Page 132: Auto-Leveling Outrigger Settings And Error Codes

    B+ SUPPLY TOO LOW STARTUP! FAULT: BAD SLAVE MICRO FAULT: BAD TILT SENSOR FAULT: BAD HWFS FAULT: P2-5 FAULTY FAULT: P2-6 FAULTY FAULT: P2-8 STUCK ON FAULT: P2-8 ALWAYS ON FAULT: P2-8 ALWAYS OFF FAULT: HWFS STALLED! 1505AA SJ6832 RTE 167576AFA...

  • Page 133: Auto-Leveling Outrigger Error Code Breakdown

    FAULT: P2-6 FAULTY FAULT: P2-8 STUCK ON FAULT: P2-8 ALWAYS ON FAULT: P2-8 ALWAYS OFF These are internal faults. If the fault persists after the power has been reset, the outrigger control module may need to be replaced. 1506AA 167576AFA SJ6832 RTE...

  • Page 134: Hand Held Calibration/Diagnostic Tool Key Functions

    SYMBOL KEY FUNCTIONS ESC/ENTER BUTTONS To move back and forth between menu and sub-menu LEFT/RIGHT BUTTONS Select menus and setting to be adjusted UP/DOWN BUTTONS Adjust setting values M62172AA Outrigger Settings Model 6832RTE O.R. Settings SJ6832 RTE 167576AFA...

  • Page 135: Outrigger Control Module Instructions

    Outriggers Displays various status during the auto-level function Tilt Displays vehicle tilt in X and Y orientations measured by integral sensor Tilted Displays whether vehicle is tilted (YES or NO) Battery Displays battery supply voltage (on P2-12) 167576AFA SJ6832 RTE...
  • Page 136 Displays maximum recorded battery supply voltage OCM1 version Displays part number and software version of GP106 EZcal version Displays software version of EZcal Access Level Menu Options ACCESS LEVEL 3 (allows viewing only) CODE xxxx ACCESS LEVEL 2 (allows setup on OCM1) SJ6832 RTE 167576AFA...

  • Page 137: Calibrate Level

    If machine is tilted to 1.0° in the X and Y orientations, the auto-level function will attempt to level the X orientation (0.3+0.5<1.0) but does not attempt to level the Y orientation (0.7+0.5>1.0) RANGE: 0.0° to 1.0°, default 0.3° 167576AFA SJ6832 RTE...
  • Page 138 By using Left/Right buttons, select the Calibrate Level from the menu and press the ENTER. 15. The display will show Calibrate Level: Yes: Enter, No: ESC. Select the Yes from the menu by press the ENTER button. SJ6832 RTE 167576AFA...

  • Page 139: Auto-Leveling Outrigger Control Module Pin Reference Chart

    73 Blue Output used to retract the RIGHT REAR outrigger 72 Red Output used to retract the RIGHT FRONT outrigger 71 Orange Output used to retract the LEFT FRONT outrigger 35C White/Black Power input for outriggers 60401AC 167576AFA SJ6832 RTE...

  • Page 140: Outrigger Upper Limit Switch (Ls61, Ls62, Ls63, Ls64) Replacement And Adjustment

    Limit Switch Replacement 1. Mount the new limit switch (138060) loosely on the bracket, using the hardware removed previously. 2. Starting from the top, place the new limit switch cable in the split loom. SJ6832 RTE 167576AFA...

  • Page 141: Outrigger Lower Limit Switch (Ls65, Ls66, Ls67, Ls68) Replacement And Adjustment

    Retain the rubber grommet. Discard the old limit switch and cable. Limit Switch Replacement 167576AFA SJ6832 RTE...

  • Page 142: Load Sensing System

    17. Repeat Steps 6–14 as necessary. If test cannot 1. Ensure batteries are fully charged. be passed after 2 calibration attempts, contact Skyjack Customer Service. 2. Ensure you are familiar with the emergency lowering system and that it is fully functional.

  • Page 143: Control Module Pin Reference Chart

    Not Used Not Used Not Used Not Used 910 Black Positive Signal To Angle Transducer 900 White Negative Signal To Angle Transducer 902 White Negative Signal To Pressure Transducer 910A Black Positive Signal To Pressure Transducer 60645AB 167576AFA SJ6832 RTE...

  • Page 144: Led Error Codes - Quick Reference Chart

    4. A 4 second pause. Repeat Steps 1-4 Since the GP102 only reports one error, only one code can be read from the LED per instance. If the error is cleared and another error is present, it will then be presented. SJ6832 RTE 167576AFA...

  • Page 145: Chart

    Invalid Load – Check Sensors Check the voltage out of the pressure transducer, into P4-2. It should be be- tween 0.5 V (zero pressure) and 4.5 V (maximum pressure) and should vary as the platform load & position varies. 167576AFA SJ6832 RTE...
  • Page 146 – incorrect mounting can cause the Fault: Bad Slave Analogs bad tilt sensor diagnostic to occur. Otherwise there may be an internal problem with the Fault: Bad Strain Monitors GP102. Fault: Bad Slave Micro Fault HWFS Stalled! SJ6832 RTE 167576AFA...

  • Page 147: Control Module Load Calibration - Code Messages & Definitions

    A reading of 0V or 5V is probably due to a wiring problem. Code F11: Not Up This message occurs at the start of calibration if the operator selects a function other than UP . Select the UP function only. ▪ 167576AFA SJ6832 RTE...
  • Page 148 Check DIAGNOSTICS / SENSORS to see the output. A reading of 0V or 5V is probably due to a wiring ▪ problem. Code F42: Low Pressure This message indicates that the pressure transducer output (P4-2) is too low (0.5V or less) at the beginning of calibration. Check DIAGNOSTICS / SENSORS to read output. ▪ SJ6832 RTE 167576AFA...
  • Page 149 Press ENTER to confirm when the platform is fully lowered. Platform Empty? This message is prompting for confirmation that the platform is completely empty. Press ENTER to confirm if the platform is empty. 167576AFA SJ6832 RTE...
  • Page 150 Lower Loaded This message is displayed while the platform is being lowered to the next measurement height, when an EMPTY platform is being calibrated. Lowering This message is displayed while the platform is being lowered, during HEIGHT-only calibration. SJ6832 RTE 167576AFA...
  • Page 151 The last calibrate date can be viewed in DIAGNOSTICS / LOG. Press LEFT and RIGHT to select the flashing digits. Press UP and DOWN to change the flashing digits. Press ENTER when the entry is complete. IMPORTANT: The date 00/00/00 is not allowed! Finished This message confirms that calibration is complete and successful. 167576AFA SJ6832 RTE...

  • Page 152: Control Module Load Calibration Procedure

    8. The display will show “Help: Press Enter”. By using Left/Right buttons, select the “Access Level ( ? )” from the menu and press the ENTER button. Contact Skyjack Service Department at: (44) 1691-676 236 for your Access Level Code Number.
  • Page 153 24. The display will show “Calibrate: Loaded Empty? No”. Asking for confirmation that the platform is empty? ▪ Check that the platform is empty ▪ 25. By using the Up/Down buttons, enter the “Yes” followed by pressing the ENTER button. 167576AFA SJ6832 RTE...
  • Page 154 The current date must be entered using the LEFT/RIGHT and UP/DOWN buttons ▪ 39. .Press ENTER to complete date entry (the information is stored). 40. The display shows Calibrate Load option. 41. Press the ESC button to exit the Calibrate Load option. SJ6832 RTE 167576AFA...
  • Page 155 If the phase does not need to be repeated, just press ENTER to move on. ▪ If the phase does need to be repeated, press UP or DOWN to change NO to YES then press ENTER. ▪ 167576AFA SJ6832 RTE...
  • Page 156 Load Sensing System Section 5 – Procedures SJ6832 RTE 167576AFA...

  • Page 157: Curve/Group Codes Chart

    2 Manual Extension Deck 8841E 2 Powered Extension Deck 9250 None 9250 1 Powered Extension Deck 9250 2 Powered Extension Deck 6832RT 1 Manual Extension Deck 6826RT 1 Manual Extension Deck 9241 2 Powered Extension Deck 167AA_RT 167576AFA SJ6832 RTE...

  • Page 158: Scissors

    7 ft 6. Follow the cable into the electrical panel, and (2.13 m). disconnect the limit switch wires from the 2. Turn engine off. electrical panel. Discard the limit switch. 7. Limit Switch Replacement SJ6832 RTE 167576AFA...

  • Page 159: High Speed Cutout Limit Switch Testing

    (1.88 m), then stop softly when it fully lowers. 1. Turn the emergency main power disconnect 5.6-4 Test Functions switch to the ON position, and start the engine. Perform all of the function tests given in your unit’s Operating manual. 167576AFA SJ6832 RTE...

  • Page 160: Gate Springe Hinge Adjustment

    4. Adjust the tension on both hinges until the gate releases and latches from a half open position. 5. Reinstall the safety locking screws into the hinges when tension adjustment is complete. SJ6832 RTE 167576AFA...
  • Page 161 Notes 167576AFA SJ6832 RTE...
  • Page 162 Notes SJ6832 RTE 167576AFA...
  • Page 163 www.skyjack.com...
